Adafruit RP2350 22-pin FPC HSTX to DVI Adapter for HDMI Displays

Adafruit, MIT

You may have noticed that our RP2350 Feather has an FPC output connector on the end for accessing the HSTX (High Speed Transmission) peripheral.

3.3V
Output from the 3.3V regulator on the 22-pin port.
Type · powerVoltage · 3.3V
GND
Common ground for power and logic on the 22-pin port.
Type · ground
SCL/GPIO3
Main I2C1 clock pin on the 22-pin port.
Type · i2c
SDA/GPIO2
Main I2C1 data pin on the 22-pin port.
Type · i2c
D11/GPIO11
Digital I/O pin 11; also used for DVI hot plug detect through the DVI port/jumper.
Type · digital
D10/GPIO10
Digital I/O pin 10; also used for DVI CEC through the DVI port/jumper.

Start wiring

I2C · UART · 3.3V

Confirm the data interface matches your host board.

Module pins: 3.3V, GND, SCL/GPIO3, SDA/GPIO2. Schematik maps them to your board in the app.
