Include Arduino H // // Live Flight Scanner

#include <Arduino.h>
#include <M5Dial.h>
#include <WiFi.h>
#include <HTTPClient.h>
#include <ArduinoJson.h>
#include <Preferences.h>
#include <math.h>
#include <qrcode.h>

// ─── CONFIG ─────────────────────────────────────────────────────────────────
#define FALLBACK_LAT   51.5072f
#define FALLBACK_LON   -0.1276f
#define MAX_AC         60
#define MAX_HIST       5
#define MAX_AIRPORTS   20
#define MAX_SATS       10
#define MAX_LAUNCHES   8
#define FETCH_INTERVAL 15000
#define WEATHER_INTERVAL 300000

// ─── GLOBALS ────────────────────────────────────────────────────────────────


enum AppState {
  APP_BOOT,
  APP_WIFI_SETUP,
  APP_CONNECTING,
  APP_LOCATING,
  APP_HOME,
  APP_FLIGHT,
  APP_SPACE,
  APP_WEATHER_APP,
  APP_STATS_APP,
  APP_SETTINGS,
  APP_GAMES
};

struct AppIcon {
  const char* name;
  const char* icon;
  uint32_t color;
  AppState target;
};

enum FlightMode { FM_RADAR, FM_SELECT };

struct Aircraft {
  String callsign, icao24, airline, planeType;
  float lat, lon, alt, spd, hdg;
  bool onGround, emergency, rare, ufo;
  int squawk;
  float histLat[MAX_HIST], histLon[MAX_HIST];
  int histCount;
  float sweepBright;
  int sx, sy;
};

struct Airport {
  String icao, name;
  float lat, lon, elev;
  int type; // 0=small,1=med,2=large,3=heli
};

enum SpaceMode { SM_RADAR, SM_SELECT };

struct Satellite {
  String name, fullName;
  float lat, lon, alt, spd;
  int nextPassMin;
  bool isISS;
  String streamUrl;
  int sx, sy;
};

struct Launch {
  String rocketName, provider, siteName, streamUrl, status;
  float siteLat, siteLon;
  int minutesToLaunch;
  int sx, sy;
};

struct FlyingPlane { int x,y,dx,dy; bool active; String label; };

struct QuizQ { const char* icao; const char* correct; const char* opts[4]; };

// Forward declarations

// Forward declarations
void drawFilterSettings();
void spawnFlyingPlane(int i);
void initPlaneCatcher();
void runPlaneCatcher();
void initQuiz();
void runAirportQuiz();
void initRocketGame();
void runRocketLaunch();
void drawGamesMenu();

float degToRad(float d);
float dist(float la1,float lo1,float la2,float lo2);
void latLonToScreen(float lat, float lon, float cLat, float cLon, float rangeKm, int &sx, int &sy);
bool inCircle(int x, int y);
String compassDir(float hdg);
String altBand(float alt);
String getAirline(String cs);
String getPlaneType(String icao);
bool isRare(String cs, String type);
String getStreamUrl(String provider);
void drawPlane(int cx, int cy, float hdg, uint32_t col, bool selected);
void drawSweep();
void drawGrid();
void drawHUD(const char* modeLabel, uint32_t modeCol, int count, float range, bool isSpace);
void drawAircraftPanel(int i);
void drawAirportPanel(int i);
void drawSatellitePanel(int i);
void drawLaunchPanel(int i);
void drawQRCode(String url, String title);
void drawHelp();
void drawEmergBanner();
void drawLaunchBanner(int idx);
void drawAirports(float cLat, float cLon, float rangeKm);
void drawTrails(float cLat, float cLon, float rangeKm);
void fetchFlights();
void fetchAirports();
void fetchSpace();
void fetchWeather();
void geolocate();
void updateNightMode();
void drawWifiKeyboard(bool isSSID);
void drawHomeScreen();
void drawFlightScreen();
void drawStatsScreen();
void drawSpaceScreen();
void drawWeatherApp();
void drawSettings();
void handleTouch(int tx, int ty);

Preferences prefs;
float homeLat = FALLBACK_LAT, homeLon = FALLBACK_LON;
float viewLat = FALLBACK_LAT, viewLon = FALLBACK_LON;
String locationCity = "Unknown", locationCountry = "";

// ─── APP STATE ──────────────────────────────────────────────────────────────

AppState appState = APP_BOOT;

// ─── HOME SCREEN ────────────────────────────────────────────────────────────

AppIcon apps[] = {
  { "FLIGHT RADAR", "✈",  0x07E0, APP_FLIGHT },
  { "SPACE",        "🚀", 0x07FF, APP_SPACE  },
  { "GAMES",        "G",  0xF81F, APP_GAMES  },
  { "WEATHER",      "W",  0xFD20, APP_WEATHER_APP },
  { "STATS",        "S",  0x07FF, APP_STATS_APP },
  { "SETTINGS",     "X",  0xC618, APP_SETTINGS  }
};
#define NUM_APPS 6
int homeSelected = 0;
long lastEnc = 0;

// ─── FLIGHT MODE ─────────────────────────────────────────────────────────────

FlightMode flightMode = FM_RADAR;


Aircraft ac[MAX_AC];
int acCount = 0, selAc = -1;

// ─── AIRPORT ─────────────────────────────────────────────────────────────────

Airport airports[MAX_AIRPORTS];
int apCount = 0;
int selAp = -1;

// ─── SPACE MODE ──────────────────────────────────────────────────────────────

SpaceMode spaceMode = SM_RADAR;


Satellite sats[MAX_SATS];
int satCount = 0, selSat = -1;


Launch launches[MAX_LAUNCHES];
int launchCount = 0, selLaunch = -1;

// ─── WEATHER ─────────────────────────────────────────────────────────────────
float weatherTemp = 0, weatherWindSpd = 0, weatherWindDir = 0, weatherCloud = 0;
float weatherRain = 0;
bool weatherLoaded = false;

// ─── STATS ───────────────────────────────────────────────────────────────────
int statsTotalToday = 0, statsEmergToday = 0, statsRareToday = 0, statsUfoToday = 0;
String statsBusiestAirline = "", statsHighestCall = "", statsFastestCall = "";
float statsHighestAlt = 0, statsFastestSpd = 0;

// ─── SETTINGS ────────────────────────────────────────────────────────────────
bool nightMode = false, nightAuto = true, filterOn = false, ufoMode = false;
int screenBright = 220;

// ─── ZOOM ────────────────────────────────────────────────────────────────────
float planeRanges[] = {20,50,100,200,400};
float spaceRanges[] = {500,1000,2000,5000,10000,20000};
int planeZoom = 2, spaceZoom = 2;
#define PLANE_ZOOM_COUNT 5
#define SPACE_ZOOM_COUNT 6

// ─── FREE SCROLL ─────────────────────────────────────────────────────────────
bool freeScroll = false;

// ─── HUD ─────────────────────────────────────────────────────────────────────
bool showHelp = false, showQR = false, showStream = false;
String qrUrl = "", streamTitle = "";
bool showEmergBanner = false, showLaunchBanner = false;
int emergBannerIdx = -1, launchBannerIdx = -1;
unsigned long emergBannerTime = 0, launchBannerTime = 0;

// ─── SWEEP ───────────────────────────────────────────────────────────────────
float sweepAngle = 0;

// ─── TIMING ──────────────────────────────────────────────────────────────────
unsigned long lastFetch = 0, lastWeather = 0, lastDraw = 0;

// ─── WIFI KEYBOARD ───────────────────────────────────────────────────────────
String wifiSSID = "", wifiPass = "";
bool enteringSSID = true;
String currentInput = "";
const char* charset = "abcdefghijklmnopqrstuvwxyzABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789 !@#$%^&*()-_=+[]{}|;:',.<>?/`~DONE";
int charsetLen = 95;
int charIdx = 0;

// ─── BUTTON ──────────────────────────────────────────────────────────────────
unsigned long btnPressTime = 0;
bool btnHeld = false;

// ─── CANVAS ──────────────────────────────────────────────────────────────────
M5Canvas canvas(&M5Dial.Display);

// ────────────────────────────────────────────────────────────────────────────
// HELPERS
// ────────────────────────────────────────────────────────────────────────────
float degToRad(float d) { return d * M_PI / 180.0f; }
float dist(float la1,float lo1,float la2,float lo2){
  float dlat=degToRad(la2-la1), dlon=degToRad(lo2-lo1);
  float a=sin(dlat/2)*sin(dlat/2)+cos(degToRad(la1))*cos(degToRad(la2))*sin(dlon/2)*sin(dlon/2);
  return 6371.0f*2*atan2(sqrt(a),sqrt(1-a));
}
void latLonToScreen(float lat, float lon, float cLat, float cLon, float rangeKm, int &sx, int &sy){
  float dLat = (lat - cLat) * 111.0f;
  float dLon = (lon - cLon) * 111.0f * cos(degToRad(cLat));
  float scale = 110.0f / rangeKm;
  sx = 120 + (int)(dLon * scale);
  sy = 120 - (int)(dLat * scale);
}
bool inCircle(int x, int y){ return (x-120)*(x-120)+(y-120)*(y-120) <= 118*118; }

String compassDir(float hdg){
  const char* dirs[]={"N","NNE","NE","ENE","E","ESE","SE","SSE","S","SSW","SW","WSW","W","WNW","NW","NNW"};
  return dirs[(int)((hdg+11.25f)/22.5f)%16];
}
String altBand(float alt){
  if(alt<100) return "GROUND";
  if(alt<10000) return "LOW ALT";
  if(alt<18000) return "MID ALT";
  if(alt<29000) return "HIGH ALT";
  return "CRUISE";
}
String getAirline(String cs){
  if(cs.startsWith("BAW")) return "BRITISH AIRWAYS";
  if(cs.startsWith("EZY")) return "EASYJET";
  if(cs.startsWith("RYR")) return "RYANAIR";
  if(cs.startsWith("UAL")) return "UNITED";
  if(cs.startsWith("AAL")) return "AMERICAN";
  if(cs.startsWith("DAL")) return "DELTA";
  if(cs.startsWith("SWA")) return "SOUTHWEST";
  if(cs.startsWith("AFR")) return "AIR FRANCE";
  if(cs.startsWith("DLH")) return "LUFTHANSA";
  if(cs.startsWith("KLM")) return "KLM";
  if(cs.startsWith("IBE")) return "IBERIA";
  if(cs.startsWith("UAE")) return "EMIRATES";
  if(cs.startsWith("QTR")) return "QATAR";
  if(cs.startsWith("SIA")) return "SINGAPORE AIR";
  if(cs.startsWith("CPA")) return "CATHAY PACIFIC";
  if(cs.startsWith("ANA")) return "ANA";
  if(cs.startsWith("JAL")) return "JAPAN AIRLINES";
  if(cs.startsWith("THA")) return "THAI AIRWAYS";
  if(cs.startsWith("VIR")) return "VIRGIN ATLANTIC";
  if(cs.startsWith("TCX")) return "THOMAS COOK";
  if(cs.startsWith("TOM")) return "TUI";
  if(cs.startsWith("EXS")) return "JET2";
  if(cs.startsWith("LOG")) return "LOGANAIR";
  return "";
}
String getPlaneType(String icao){
  icao.toUpperCase();
  if(icao=="B738"||icao=="B737") return "Boeing 737-800";
  if(icao=="B77W") return "Boeing 777-300ER";
  if(icao=="B772") return "Boeing 777-200";
  if(icao=="B788") return "Boeing 787-8";
  if(icao=="B789") return "Boeing 787-9";
  if(icao=="B748") return "Boeing 747-8";
  if(icao=="B744") return "Boeing 747-400";
  if(icao=="A320") return "Airbus A320";
  if(icao=="A319") return "Airbus A319";
  if(icao=="A321") return "Airbus A321";
  if(icao=="A21N") return "Airbus A321neo";
  if(icao=="A20N") return "Airbus A320neo";
  if(icao=="A388") return "Airbus A380-800";
  if(icao=="A359") return "Airbus A350-900";
  if(icao=="A333") return "Airbus A330-300";
  if(icao=="E190") return "Embraer E190";
  if(icao=="E175") return "Embraer E175";
  if(icao=="DH8D") return "Dash 8 Q400";
  if(icao=="C172") return "Cessna 172";
  if(icao=="C208") return "Cessna Caravan";
  if(icao=="PC12") return "Pilatus PC-12";
  if(icao=="GLF6") return "Gulfstream G650";
  if(icao=="GLF5") return "Gulfstream G550";
  if(icao=="C56X") return "Citation Excel";
  if(icao=="F16")  return "F-16 Fighting Falcon";
  if(icao=="F35")  return "F-35 Lightning II";
  if(icao=="A10")  return "A-10 Thunderbolt";
  if(icao=="C130") return "C-130 Hercules";
  if(icao=="R44")  return "Robinson R44";
  if(icao=="EC35") return "Eurocopter EC135";
  if(icao=="AS50") return "Eurocopter AS350";
  if(icao=="DC3")  return "Douglas DC-3";
  if(icao=="CONC") return "Concorde";
  return "";
}
bool isRare(String cs, String type){
  String u = cs; u.toUpperCase();
  if(u.startsWith("RRR")||u.startsWith("NATO")||u.startsWith("ARMY")||
     u.startsWith("NAVY")||u.startsWith("USAF")||u.startsWith("RAF")||
     u.startsWith("DUKE")||u.startsWith("COBRA")||u.startsWith("VIPER")) return true;
  String t = type;
  if(t.indexOf("F-16")>=0||t.indexOf("F-35")>=0||t.indexOf("A-10")>=0||
     t.indexOf("C-130")>=0||t.indexOf("Gulfstream")>=0||
     t.indexOf("Concorde")>=0||t.indexOf("DC-3")>=0) return true;
  return false;
}
String getStreamUrl(String provider){
  String p = provider; p.toUpperCase();
  if(p.indexOf("SPACEX")>=0) return "youtube.com/@SpaceX/live";
  if(p.indexOf("NASA")>=0)   return "youtube.com/@NASA/live";
  if(p.indexOf("ESA")>=0)    return "youtube.com/@ESA/live";
  if(p.indexOf("ROSCOSMOS")>=0) return "youtube.com/@Roscosmos/live";
  if(p.indexOf("BLUE ORIGIN")>=0) return "youtube.com/@BlueOrigin/live";
  if(p.indexOf("ROCKET LAB")>=0) return "youtube.com/@RocketLab/live";
  return "youtube.com/results?search_query=" + provider + "+launch+live";
}

// ─── DRAW PLANE ICON ─────────────────────────────────────────────────────────
void drawPlane(int cx, int cy, float hdg, uint32_t col, bool selected){
  float r = degToRad(hdg);
  float s = sin(r), c2 = cos(r);
  auto rot=[&](float x,float y,int&ox,int&oy){ ox=cx+(int)(x*c2-y*s); oy=cy+(int)(x*s+y*c2); };
  int x1,y1,x2,y2,x3,y3,x4,y4,x5,y5,x6,y6;
  rot(0,-7,x1,y1); rot(0,5,x2,y2);
  rot(-6,1,x3,y3); rot(6,1,x4,y4);
  rot(-3,4,x5,y5); rot(3,4,x6,y6);
  canvas.drawLine(x1,y1,x2,y2,col);
  canvas.drawLine(x3,y3,x4,y4,col);
  canvas.drawLine(x5,y5,x6,y6,col);
  canvas.fillCircle(x1,y1,1,col);
  if(selected){
    canvas.drawCircle(cx,cy,9,TFT_WHITE);
    canvas.drawCircle(cx,cy,10,0x4208);
    canvas.drawCircle(cx,cy,11,0x2104);
  }
}

// ─── DRAW SWEEP ──────────────────────────────────────────────────────────────
void drawSweep(){
  uint32_t nightCol = nightMode ? 0x0300 : 0x0600;
  uint32_t sweepCol = nightMode ? 0x03E0 : 0x07E0;
  for(int i=1;i<=30;i++){
    float a=degToRad(sweepAngle-(float)i*2.0f);
    uint8_t bright=255-(i*8);
    uint32_t c=canvas.color565(0,bright/2,0);
    for(int r=0;r<110;r+=2){
      int x=120+(int)(r*sin(a)), y=120-(int)(r*cos(a));
      if(inCircle(x,y)) canvas.drawPixel(x,y,c);
    }
  }
  float sa=degToRad(sweepAngle);
  for(int r=0;r<112;r++){
    int x=120+(int)(r*sin(sa)), y=120-(int)(r*cos(sa));
    if(inCircle(x,y)) canvas.drawPixel(x,y,sweepCol);
  }
}

// ─── DRAW GRID ───────────────────────────────────────────────────────────────
void drawGrid(){
  uint32_t gc = nightMode ? 0x0841 : 0x1082;
  canvas.drawCircle(120,120,110,gc);
  canvas.drawCircle(120,120,55,gc);
  canvas.drawLine(120,10,120,230,gc);
  canvas.drawLine(10,120,230,120,gc);
  canvas.drawCircle(120,120,3,TFT_WHITE);
  canvas.drawLine(117,120,123,120,TFT_WHITE);
  canvas.drawLine(120,117,120,123,TFT_WHITE);
}

// ─── DRAW HUD ────────────────────────────────────────────────────────────────
void drawHUD(const char* modeLabel, uint32_t modeCol, int count, float range, bool isSpace){
  canvas.setTextSize(1);
  canvas.setTextColor(modeCol);
  canvas.drawString(modeLabel, 8, 8);
  char buf[20];
  snprintf(buf,20,"%d%s",count,isSpace?"OBJ":"AC");
  canvas.setTextColor(TFT_WHITE);
  canvas.drawRightString(buf, 232, 8, 1);
  snprintf(buf,20,freeScroll?"SCROLL":"%.0fkm",range);
  canvas.setTextColor(freeScroll?TFT_CYAN:0x07FF);
  canvas.drawCentreString(buf, 120, 222, 1);
  // weather
  if(weatherLoaded){
    char w[32];
    snprintf(w,32,"%.0f° %.0fkt %s",weatherTemp,weatherWindSpd,compassDir(weatherWindDir).c_str());
    canvas.setTextColor(0xC618);
    canvas.drawCentreString(w,120,210,1);
  }
  // nearest airport
  if(apCount>0){
    float minD=9999; int minI=0;
    for(int i=0;i<apCount;i++){
      float d=dist(homeLat,homeLon,airports[i].lat,airports[i].lon);
      if(d<minD){minD=d;minI=i;}
    }
    char ap[24];
    snprintf(ap,24,"%s %.0fkm",airports[minI].icao.c_str(),minD);
    canvas.setTextColor(0xFD20);
    canvas.drawString(ap,8,222);
  }
  // question mark
  canvas.fillCircle(224,224,10,0x2104);
  canvas.drawCircle(224,224,10,0xC618);
  canvas.setTextColor(TFT_WHITE);
  canvas.drawCentreString("?",224,219,1);
  // free scroll banner
  if(freeScroll){
    canvas.fillRect(30,50,180,18,0x0410);
    canvas.drawRect(30,50,180,18,TFT_CYAN);
    canvas.setTextColor(TFT_CYAN);
    canvas.drawCentreString("🌍 FREE SCROLL — Press knob=HOME",120,53,1);
  }
  // UFO mode indicator
  if(ufoMode){
    canvas.setTextColor(0xF81F);
    canvas.drawString("UFO",8,195);
  }
  // filter indicator
  if(filterOn){
    canvas.setTextColor(0xFD20);
    canvas.drawString("FILTER",8,183);
  }
}

// ─── DRAW INFO PANEL ─────────────────────────────────────────────────────────
void drawAircraftPanel(int i){
  canvas.fillRoundRect(10,150,220,80,6,TFT_BLACK);
  canvas.drawRoundRect(10,150,220,80,6,ac[i].emergency?TFT_RED:TFT_WHITE);
  canvas.setTextColor(TFT_WHITE); canvas.setTextSize(1);
  canvas.drawCentreString(ac[i].callsign.c_str(),120,154,2);
  if(ac[i].airline.length()>0){ canvas.setTextColor(0xFD20); canvas.drawCentreString(ac[i].airline.c_str(),120,168,1); }
  if(ac[i].planeType.length()>0){ canvas.setTextColor(0x07FF); canvas.drawCentreString(ac[i].planeType.c_str(),120,178,1); }
  char buf[48];
  snprintf(buf,48,"ALT %.0fft FL%.0f",ac[i].alt,ac[i].alt/100.0f);
  canvas.setTextColor(TFT_GREEN); canvas.drawCentreString(buf,120,188,1);
  snprintf(buf,48,"SPD %.0fkts  HDG %.0f° %s",ac[i].spd,ac[i].hdg,compassDir(ac[i].hdg).c_str());
  canvas.setTextColor(TFT_WHITE); canvas.drawCentreString(buf,120,198,1);
  snprintf(buf,48,"%s  %s",ac[i].onGround?"ON GROUND":"AIRBORNE",altBand(ac[i].alt).c_str());
  canvas.setTextColor(0xC618); canvas.drawCentreString(buf,120,208,1);
  if(ac[i].rare){ canvas.setTextColor(0xFFE0); canvas.drawCentreString("★ RARE AIRCRAFT",120,218,1); }
  if(ac[i].ufo){ canvas.setTextColor(0xF81F); canvas.drawCentreString("◈ UNIDENTIFIED",120,218,1); }
}

void drawAirportPanel(int i){
  canvas.fillRoundRect(10,170,220,60,6,TFT_BLACK);
  canvas.drawRoundRect(10,170,220,60,6,0xFD20);
  canvas.setTextColor(0xFD20); canvas.setTextSize(1);
  canvas.drawCentreString(airports[i].icao.c_str(),120,174,2);
  canvas.setTextColor(TFT_WHITE);
  canvas.drawCentreString(airports[i].name.c_str(),120,192,1);
  const char* types[]={"SMALL","MEDIUM","LARGE","HELIPORT"};
  char buf[32]; snprintf(buf,32,"ELEV %.0fft  %s",airports[i].elev,types[airports[i].type]);
  canvas.setTextColor(0xC618); canvas.drawCentreString(buf,120,204,1);
}

void drawSatellitePanel(int i){
  canvas.fillRoundRect(10,155,220,75,6,TFT_BLACK);
  canvas.drawRoundRect(10,155,220,75,6,sats[i].isISS?TFT_CYAN:0x001F);
  uint32_t nc=sats[i].isISS?TFT_CYAN:0x7BFF;
  canvas.setTextColor(nc); canvas.setTextSize(1);
  canvas.drawCentreString(sats[i].name.c_str(),120,159,2);
  canvas.setTextColor(TFT_WHITE);
  canvas.drawCentreString(sats[i].fullName.c_str(),120,175,1);
  char buf[48];
  snprintf(buf,48,"ALT %.0fkm  SPD %.0fkm/h",sats[i].alt,sats[i].spd);
  canvas.setTextColor(TFT_GREEN); canvas.drawCentreString(buf,120,187,1);
  snprintf(buf,48,"NEXT PASS: %dmin",sats[i].nextPassMin);
  canvas.setTextColor(0xFD20); canvas.drawCentreString(buf,120,199,1);
  canvas.setTextColor(TFT_CYAN);
  canvas.drawCentreString("[ TAP TO WATCH LIVE ]",120,211,1);
}

void drawLaunchPanel(int i){
  canvas.fillRoundRect(10,155,220,75,6,TFT_BLACK);
  canvas.drawRoundRect(10,155,220,75,6,0xFD20);
  canvas.setTextColor(0xFD20); canvas.setTextSize(1);
  canvas.drawCentreString(launches[i].rocketName.c_str(),120,159,2);
  canvas.setTextColor(TFT_WHITE);
  canvas.drawCentreString(launches[i].provider.c_str(),120,175,1);
  char buf[48];
  snprintf(buf,48,"LAUNCH IN %dmin",launches[i].minutesToLaunch);
  canvas.setTextColor(launches[i].minutesToLaunch<10?TFT_RED:TFT_GREEN);
  canvas.drawCentreString(buf,120,187,1);
  canvas.setTextColor(0xC618);
  canvas.drawCentreString(launches[i].siteName.c_str(),120,199,1);
  canvas.setTextColor(TFT_CYAN);
  canvas.drawCentreString("[ TAP TO WATCH LIVE ]",120,211,1);
}

// ─── DRAW QR CODE ────────────────────────────────────────────────────────────
void drawQRCode(String url, String title){
  canvas.fillScreen(TFT_BLACK);
  canvas.setTextColor(0xFD20); canvas.setTextSize(1);
  canvas.drawCentreString("SCAN TO WATCH",120,12,1);
  canvas.setTextColor(TFT_WHITE);
  canvas.drawCentreString(title.c_str(),120,24,1);
  QRCode qrc;
  uint8_t qrdata[qrcode_getBufferSize(3)];
  qrcode_initText(&qrc,qrdata,3,ECC_LOW,url.c_str());
  int sz=qrc.size, cell=4, ox=120-sz*cell/2, oy=40;
  canvas.fillRect(ox-2,oy-2,sz*cell+4,sz*cell+4,TFT_WHITE);
  for(int y=0;y<sz;y++) for(int x=0;x<sz;x++)
    if(qrcode_getModule(&qrc,x,y)) canvas.fillRect(ox+x*cell,oy+y*cell,cell,cell,TFT_BLACK);
  canvas.setTextColor(0xC618);
  canvas.drawCentreString("Open on your phone!",120,210,1);
  canvas.setTextColor(0x7BFF);
  canvas.drawCentreString("TAP to close",120,222,1);
}

// ─── DRAW HELP ───────────────────────────────────────────────────────────────
void drawHelp(){
  canvas.fillScreen(TFT_BLACK);
  canvas.fillCircle(120,120,118,0x0841);
  canvas.drawCircle(120,120,118,TFT_WHITE);
  canvas.setTextColor(TFT_WHITE); canvas.setTextSize(1);
  canvas.drawCentreString("❓ HELP",120,18,2);
  canvas.setTextColor(0xFD20);
  canvas.drawCentreString("── CONTROLS ──",120,40,1);
  canvas.setTextColor(TFT_WHITE);
  canvas.drawCentreString("KNOB = zoom in/out",120,54,1);
  canvas.drawCentreString("PRESS KNOB = free scroll",120,66,1);
  canvas.drawCentreString("SHORT BTN = cycle mode",120,78,1);
  canvas.drawCentreString("HOLD BTN 2s = PLANE/SPACE",120,90,1);
  canvas.drawCentreString("TAP plane/sat = select",120,102,1);
  canvas.drawCentreString("DRAG = pan map",120,114,1);
  canvas.setTextColor(0xFD20);
  canvas.drawCentreString("── COLOURS ──",120,128,1);
  canvas.setTextColor(TFT_GREEN);  canvas.drawCentreString("● Green = airborne",120,140,1);
  canvas.setTextColor(TFT_YELLOW); canvas.drawCentreString("● Yellow = on ground",120,152,1);
  canvas.setTextColor(TFT_RED);    canvas.drawCentreString("● RED = EMERGENCY",120,164,1);
  canvas.setTextColor(TFT_CYAN);   canvas.drawCentreString("✦ Cyan = ISS",120,176,1);
  canvas.setTextColor(0x7BFF);     canvas.drawCentreString("✦ Blue = satellite",120,188,1);
  canvas.setTextColor(0xFD20);     canvas.drawCentreString("🚀 Orange = launch",120,200,1);
  canvas.setTextColor(0xF81F);     canvas.drawCentreString("◈ Purple = UFO",120,212,1);
  canvas.setTextColor(0xC618);
  canvas.drawCentreString("TAP to close",120,226,1);
}

// ─── DRAW EMERGENCY BANNER ───────────────────────────────────────────────────
void drawEmergBanner(){
  bool flash=(millis()%600)<300;
  if(!flash) return;
  canvas.fillRect(20,28,200,18,TFT_RED);
  canvas.drawRect(20,28,200,18,TFT_WHITE);
  canvas.setTextColor(TFT_WHITE); canvas.setTextSize(1);
  char buf[32];
  if(emergBannerIdx>=0) snprintf(buf,32,"🚨 EMERGENCY %s",ac[emergBannerIdx].callsign.c_str());
  else strcpy(buf,"🚨 EMERGENCY AIRCRAFT");
  canvas.drawCentreString(buf,120,31,1);
}

// ─── DRAW LAUNCH BANNER ──────────────────────────────────────────────────────
void drawLaunchBanner(int idx){
  bool fast=launches[idx].minutesToLaunch<10;
  bool flash=fast?(millis()%300)<150:(millis()%600)<300;
  if(!flash) return;
  canvas.fillRect(20,28,200,18,0xFD20);
  canvas.drawRect(20,28,200,18,TFT_WHITE);
  canvas.setTextColor(TFT_BLACK); canvas.setTextSize(1);
  char buf[40];
  snprintf(buf,40,"🚀 LAUNCH IN %dmin — TAP",launches[idx].minutesToLaunch);
  canvas.drawCentreString(buf,120,31,1);
}

// ─── DRAW AIRPORTS ───────────────────────────────────────────────────────────
void drawAirports(float cLat, float cLon, float rangeKm){
  for(int i=0;i<apCount;i++){
    int sx,sy; latLonToScreen(airports[i].lat,airports[i].lon,cLat,cLon,rangeKm,sx,sy);
    if(!inCircle(sx,sy)) continue;
    uint32_t ac2=(i==selAp)?TFT_WHITE:0xFD20;
    int sz=(airports[i].type==2)?5:3;
    canvas.drawLine(sx-sz,sy,sx+sz,sy,ac2);
    canvas.drawLine(sx,sy-sz,sx,sy+sz,ac2);
    if(i==selAp) canvas.drawCircle(sx,sy,sz+2,TFT_WHITE);
    canvas.setTextSize(1); canvas.setTextColor(ac2);
    canvas.drawString(airports[i].icao.c_str(),sx+4,sy-4);
  }
}

// ─── DRAW FLIGHT HISTORY ─────────────────────────────────────────────────────
void drawTrails(float cLat, float cLon, float rangeKm){
  for(int i=0;i<acCount;i++){
    for(int h=0;h<ac[i].histCount;h++){
      int hx,hy; latLonToScreen(ac[i].histLat[h],ac[i].histLon[h],cLat,cLon,rangeKm,hx,hy);
      if(!inCircle(hx,hy)) continue;
      uint8_t bright=60+(h*(100/MAX_HIST));
      uint32_t tc=(i==selAc)?TFT_WHITE:canvas.color565(0,bright,0);
      canvas.drawPixel(hx,hy,tc);
      canvas.drawPixel(hx+1,hy,tc);
    }
  }
}

// ─── FETCH FLIGHTS ───────────────────────────────────────────────────────────
void fetchFlights(){
  float r=planeRanges[planeZoom]/111.0f;
  char url[200];
  snprintf(url,200,"https://opensky-network.org/api/states/all?lamin=%.4f&lomin=%.4f&lamax=%.4f&lomax=%.4f",
    viewLat-r,viewLon-r,viewLat+r,viewLon+r);
  HTTPClient http; http.begin(url); http.setTimeout(8000);
  int code=http.GET();
  if(code==200){
    String body=http.getString();
    DynamicJsonDocument doc(32768);
    if(!deserializeJson(doc,body)){
      JsonArray states=doc["states"];
      int newCount=0;
      for(JsonArray s:states){
        if(newCount>=MAX_AC) break;
        String cs=s[1].isNull()?"???":String((const char*)s[1]); cs.trim();
        float lat=s[6].isNull()?0:s[6].as<float>();
        float lon=s[5].isNull()?0:s[5].as<float>();
        if(lat==0&&lon==0){newCount++;continue;}
        float alt=s[7].isNull()?0:s[7].as<float>()*3.28084f;
        float spd=s[9].isNull()?0:s[9].as<float>()*1.94384f;
        float hdg=s[10].isNull()?0:s[10].as<float>();
        bool og=s[8].isNull()?false:s[8].as<bool>();
        String icao24=s[0].isNull()?"":String((const char*)s[0]);
        int sq=s[14].isNull()?0:s[14].as<int>();
        if(filterOn&&(spd<50||alt<1000)&&!og){newCount++;continue;}
        // preserve history
        float prevLat=ac[newCount].lat, prevLon=ac[newCount].lon;
        if(prevLat!=0){
          for(int h=MAX_HIST-1;h>0;h--){ ac[newCount].histLat[h]=ac[newCount].histLat[h-1]; ac[newCount].histLon[h]=ac[newCount].histLon[h-1]; }
          ac[newCount].histLat[0]=prevLat; ac[newCount].histLon[0]=prevLon;
          if(ac[newCount].histCount<MAX_HIST) ac[newCount].histCount++;
        }
        ac[newCount].callsign=cs; ac[newCount].icao24=icao24;
        ac[newCount].lat=lat; ac[newCount].lon=lon;
        ac[newCount].alt=alt; ac[newCount].spd=spd; ac[newCount].hdg=hdg;
        ac[newCount].onGround=og; ac[newCount].squawk=sq;
        ac[newCount].emergency=(sq==7700||sq==7600||sq==7500);
        ac[newCount].airline=getAirline(cs);
        ac[newCount].planeType=getPlaneType(icao24);
        ac[newCount].rare=isRare(cs,ac[newCount].planeType);
        ac[newCount].ufo=ufoMode&&(cs=="???"||cs.length()==0)&&ac[newCount].planeType.length()==0;
        // stats
        statsTotalToday++;
        if(ac[newCount].emergency) statsEmergToday++;
        if(ac[newCount].rare) statsRareToday++;
        if(ac[newCount].ufo) statsUfoToday++;
        if(alt>statsHighestAlt){statsHighestAlt=alt;statsHighestCall=cs;}
        if(spd>statsFastestSpd){statsFastestSpd=spd;statsFastestCall=cs;}
        newCount++;
      }
      acCount=newCount;
      // emergency banner
      emergBannerIdx=-1; showEmergBanner=false;
      for(int i=0;i<acCount;i++) if(ac[i].emergency){emergBannerIdx=i;showEmergBanner=true;break;}
    }
  }
  http.end();
}

// ─── FETCH AIRPORTS ──────────────────────────────────────────────────────────
void fetchAirports(){
  float r=planeRanges[planeZoom]/111.0f;
  char url[200];
  snprintf(url,200,"https://api.ourairports.com/airports.json?lat_min=%.4f&lat_max=%.4f&lon_min=%.4f&lon_max=%.4f",
    viewLat-r,viewLat+r,viewLon-r,viewLon+r);
  HTTPClient http; http.begin(url); http.setTimeout(8000);
  int code=http.GET();
  if(code==200){
    String body=http.getString();
    DynamicJsonDocument doc(16384);
    if(!deserializeJson(doc,body)){
      apCount=0;
      for(JsonObject ap:doc.as<JsonArray>()){
        if(apCount>=MAX_AIRPORTS) break;
        String t=ap["type"]|"";
        if(t=="closed"||t=="seaplane_base") continue;
        airports[apCount].icao=String((const char*)(ap["ident"]|""));
        airports[apCount].name=String((const char*)(ap["name"]|""));
        airports[apCount].lat=ap["latitude_deg"]|0.0f;
        airports[apCount].lon=ap["longitude_deg"]|0.0f;
        airports[apCount].elev=ap["elevation_ft"]|0.0f;
        if(t=="large_airport") airports[apCount].type=2;
        else if(t=="medium_airport") airports[apCount].type=1;
        else if(t=="heliport") airports[apCount].type=3;
        else airports[apCount].type=0;
        apCount++;
      }
    }
  }
  http.end();
}

// ─── FETCH SPACE ─────────────────────────────────────────────────────────────
void fetchSpace(){
  // ISS
  HTTPClient http;
  http.begin("http://api.open-notify.org/iss-now.json");
  http.setTimeout(6000);
  if(http.GET()==200){
    String body=http.getString();
    DynamicJsonDocument doc(512);
    if(!deserializeJson(doc,body)){
      satCount=0;
      sats[0].name="ISS"; sats[0].fullName="Intl Space Station";
      sats[0].lat=doc["iss_position"]["latitude"]|0.0f;
      sats[0].lon=doc["iss_position"]["longitude"]|0.0f;
      sats[0].alt=408; sats[0].spd=27600; sats[0].isISS=true;
      sats[0].nextPassMin=random(5,95);
      sats[0].streamUrl="youtube.com/@NASA/live";
      satCount=1;
      // Add some known sats
      const char* names[]={"Hubble","Starlink-1","JWST","Tiangong"};
      const char* full[]={"Hubble Space Telescope","Starlink Sat","James Webb ST","Chinese Space Stn"};
      float alts[]={547,550,1500000,389};
      float spds[]={27000,27560,1,27600};
      for(int i=0;i<4&&satCount<MAX_SATS;i++){
        sats[satCount].name=names[i]; sats[satCount].fullName=full[i];
        sats[satCount].lat=random(-80,80); sats[satCount].lon=random(-180,180);
        sats[satCount].alt=alts[i]; sats[satCount].spd=spds[i];
        sats[satCount].isISS=false; sats[satCount].nextPassMin=random(10,120);
        sats[satCount].streamUrl="youtube.com/@NASA/live";
        satCount++;
      }
    }
  }
  http.end();
  // Launches
  http.begin("https://ll.thespacedevs.com/2.2.0/launch/upcoming/?limit=8&format=json");
  http.setTimeout(8000);
  if(http.GET()==200){
    String body=http.getString();
    DynamicJsonDocument doc(16384);
    if(!deserializeJson(doc,body)){
      launchCount=0;
      for(JsonObject l:doc["results"].as<JsonArray>()){
        if(launchCount>=MAX_LAUNCHES) break;
        launches[launchCount].rocketName=String((const char*)(l["name"]|"Unknown")).substring(0,20);
        launches[launchCount].provider=String((const char*)(l["launch_service_provider"]["name"]|"Unknown")).substring(0,20);
        launches[launchCount].siteName=String((const char*)(l["pad"]["name"]|"Unknown")).substring(0,24);
        launches[launchCount].siteLat=l["pad"]["latitude"]|28.5f;
        launches[launchCount].siteLon=l["pad"]["longitude"]|-80.6f;
        launches[launchCount].status=String((const char*)(l["status"]["name"]|"TBD")).substring(0,20);
        launches[launchCount].minutesToLaunch=random(10,1440);
        launches[launchCount].streamUrl=getStreamUrl(launches[launchCount].provider);
        launchCount++;
      }
      // launch banner
      showLaunchBanner=false;
      for(int i=0;i<launchCount;i++) if(launches[i].minutesToLaunch<=60){showLaunchBanner=true;launchBannerIdx=i;break;}
    }
  }
  http.end();
}

// ─── FETCH WEATHER ───────────────────────────────────────────────────────────
void fetchWeather(){
  char url[200];
  snprintf(url,200,"https://api.open-meteo.com/v1/forecast?latitude=%.4f&longitude=%.4f&current_weather=true&hourly=cloudcover,precipitation",
    homeLat,homeLon);
  HTTPClient http; http.begin(url); http.setTimeout(8000);
  if(http.GET()==200){
    String body=http.getString();
    DynamicJsonDocument doc(8192);
    if(!deserializeJson(doc,body)){
      weatherTemp=doc["current_weather"]["temperature"]|0.0f;
      weatherWindSpd=doc["current_weather"]["windspeed"]|0.0f;
      weatherWindDir=doc["current_weather"]["winddirection"]|0.0f;
      weatherCloud=doc["hourly"]["cloudcover"][0]|0.0f;
      weatherRain=doc["hourly"]["precipitation"][0]|0.0f;
      weatherLoaded=true;
    }
  }
  http.end();
}

// ─── GEOLOCATE ───────────────────────────────────────────────────────────────
void geolocate(){
  HTTPClient http;
  http.begin("http://ip-api.com/json");
  http.setTimeout(6000);
  if(http.GET()==200){
    String body=http.getString();
    DynamicJsonDocument doc(1024);
    if(!deserializeJson(doc,body)){
      homeLat=doc["lat"]|FALLBACK_LAT;
      homeLon=doc["lon"]|FALLBACK_LON;
      viewLat=homeLat; viewLon=homeLon;
      locationCity=String((const char*)(doc["city"]|"Unknown"));
      locationCountry=String((const char*)(doc["country"]|""));
    }
  }
  http.end();
}

// ─── NIGHT MODE ──────────────────────────────────────────────────────────────
void updateNightMode(){
  if(!nightAuto) return;
  int h=millis()/3600000%24;
  nightMode=(h>=20||h<6);
  M5Dial.Display.setBrightness(nightMode?80:screenBright);
}

// ─── WIFI KEYBOARD ───────────────────────────────────────────────────────────
void drawWifiKeyboard(bool isSSID){
  canvas.fillScreen(TFT_BLACK);
  canvas.fillCircle(120,120,118,0x0841);
  canvas.drawCircle(120,120,118,TFT_WHITE);
  canvas.setTextColor(0xFD20); canvas.setTextSize(1);
  canvas.drawCentreString(isSSID?"Enter WiFi Name":"Enter Password",120,15,1);
  // input box
  canvas.fillRoundRect(20,32,200,18,4,0x2104);
  canvas.drawRoundRect(20,32,200,18,4,TFT_WHITE);
  String display=isSSID?currentInput:String(currentInput.length(),'*');
  if(display.length()>14) display=".."+display.substring(display.length()-12);
  canvas.setTextColor(TFT_WHITE);
  canvas.drawCentreString(display.c_str(),120,35,1);
  // character selector
  String cur=String(charset[charIdx]);
  String prev=charIdx>0?String(charset[charIdx-1]):"";
  String next=charIdx<charsetLen-1?String(charset[charIdx+1]):"";
  canvas.setTextColor(0x4208); canvas.drawCentreString(prev.c_str(),120,90,2);
  canvas.fillRoundRect(90,108,60,28,6,0x2104);
  canvas.drawRoundRect(90,108,60,28,6,0xFD20);
  canvas.setTextColor(TFT_WHITE); canvas.drawCentreString(cur.c_str(),120,112,2);
  canvas.setTextColor(0x4208); canvas.drawCentreString(next.c_str(),120,148,2);
  canvas.setTextColor(0xC618); canvas.setTextSize(1);
  canvas.drawCentreString("Rotate=select",120,175,1);
  canvas.drawCentreString("Press=confirm",120,187,1);
  canvas.drawCentreString("Hold=delete last",120,199,1);
  canvas.drawCentreString("Scroll to DONE",120,211,1);
}

// ─── HOME SCREEN ─────────────────────────────────────────────────────────────
void drawHomeScreen(){
  canvas.fillScreen(TFT_BLACK);
  canvas.fillCircle(120,120,118,0x0821);
  canvas.drawCircle(120,120,118,0x07E0);
  canvas.setTextColor(TFT_WHITE);
  canvas.drawCentreString("FLIGHT & SPACE",120,18,2);
  canvas.drawCentreString("RADAR",120,36,2);
  canvas.setTextColor(0x07E0);
  canvas.drawCentreString("Select an app:",120,58,1);
  // draw 5 app icons in a circle
  float angles[]={270,342,54,126,198};
  for(int i=0;i<NUM_APPS;i++){
    float a=degToRad(angles[i]);
    int cx=120+(int)(75*cos(a));
    int cy=120+(int)(75*sin(a));
    bool sel=(i==homeSelected);
    uint32_t bc=sel?apps[i].color:0x2104;
    canvas.fillCircle(cx,cy,22,bc);
    canvas.drawCircle(cx,cy,22,sel?TFT_WHITE:0x4208);
    canvas.setTextColor(sel?TFT_WHITE:0xC618);
    canvas.drawCentreString(apps[i].icon,cx,cy-6,1);
    canvas.setTextSize(1);
    canvas.drawCentreString(apps[i].name,cx,cy+8,1);
  }
  // selected app name big at bottom
  canvas.setTextColor(apps[homeSelected].color);
  canvas.drawCentreString(apps[homeSelected].name,120,215,1);
  canvas.setTextColor(0xC618);
  canvas.drawCentreString("Rotate=select  Press=open",120,227,1);
}

// ─── DRAW FLIGHT SCREEN ──────────────────────────────────────────────────────
void drawFlightScreen(){
  canvas.fillScreen(TFT_BLACK);
  canvas.fillCircle(120,120,118,TFT_BLACK);
  drawGrid();
  drawSweep();
  drawTrails(viewLat,viewLon,planeRanges[planeZoom]);
  drawAirports(viewLat,viewLon,planeRanges[planeZoom]);
  // draw planes
  for(int i=0;i<acCount;i++){
    latLonToScreen(ac[i].lat,ac[i].lon,viewLat,viewLon,planeRanges[planeZoom],ac[i].sx,ac[i].sy);
    if(!inCircle(ac[i].sx,ac[i].sy)) continue;
    uint32_t col;
    if(ac[i].emergency){ col=(millis()%400)<200?TFT_RED:TFT_WHITE; }
    else if(ac[i].ufo){ col=0xF81F; }
    else if(ac[i].rare){ col=0xFFE0; }
    else if(ac[i].onGround){ col=TFT_YELLOW; }
    else {
      float bright=ac[i].sweepBright;
      uint8_t g=120+(uint8_t)(bright*135);
      col=canvas.color565(0,g,0);
    }
    drawPlane(ac[i].sx,ac[i].sy,ac[i].hdg,col,(i==selAc));
    if(ac[i].rare){ canvas.setTextColor(0xFFE0); canvas.drawString("★",ac[i].sx+8,ac[i].sy-8); }
    if(ac[i].ufo){ canvas.setTextColor(0xF81F); canvas.drawString("◈",ac[i].sx+8,ac[i].sy-8); }
    // callsign
    canvas.setTextSize(1); canvas.setTextColor(0xC618);
    canvas.drawString(ac[i].callsign.c_str(),ac[i].sx+8,ac[i].sy-4);
    // update sweep brightness
    float sa=sweepAngle; float pa=atan2(ac[i].sx-120,-(ac[i].sy-120))*180.0f/M_PI;
    if(pa<0) pa+=360;
    float diff=fmod(sa-pa+360,360);
    if(diff<5) ac[i].sweepBright=1.0f;
    else ac[i].sweepBright=max(0.0f,ac[i].sweepBright-0.01f);
  }
  // panels
  if(selAc>=0&&selAc<acCount) drawAircraftPanel(selAc);
  else if(selAp>=0&&selAp<apCount) drawAirportPanel(selAp);
  // banners
  if(showEmergBanner&&emergBannerIdx>=0) drawEmergBanner();
  if(showLaunchBanner&&launchBannerIdx>=0) drawLaunchBanner(launchBannerIdx);
  // HUD
  const char* modeLabels[]={"RADAR","SELECT"};
  uint32_t modeCols[]={0x07FF,0xFFE0};
  drawHUD(modeLabels[flightMode],modeCols[flightMode],acCount,planeRanges[planeZoom],false);
  canvas.pushSprite(0,0);
}

// ─── DRAW STATS SCREEN ───────────────────────────────────────────────────────
void drawStatsScreen(){
  canvas.fillScreen(TFT_BLACK);
  canvas.fillCircle(120,120,118,0x0821);
  canvas.drawCircle(120,120,118,0x07FF);
  canvas.setTextColor(0x07FF);
  canvas.drawCentreString("📊 STATS",120,18,2);
  canvas.setTextColor(TFT_WHITE); canvas.setTextSize(1);
  char buf[48];
  snprintf(buf,48,"Planes seen: %d",statsTotalToday);
  canvas.drawCentreString(buf,120,55,1);
  if(statsBusiestAirline.length()>0){
    snprintf(buf,48,"Busiest: %s",statsBusiestAirline.c_str());
    canvas.drawCentreString(buf,120,72,1);
  }
  if(statsHighestCall.length()>0){
    snprintf(buf,48,"Highest: %s %.0fft",statsHighestCall.c_str(),statsHighestAlt);
    canvas.drawCentreString(buf,120,89,1);
  }
  if(statsFastestCall.length()>0){
    snprintf(buf,48,"Fastest: %s %.0fkts",statsFastestCall.c_str(),statsFastestSpd);
    canvas.drawCentreString(buf,120,106,1);
  }
  snprintf(buf,48,"Emergencies: %d",statsEmergToday);
  canvas.setTextColor(statsEmergToday>0?TFT_RED:TFT_WHITE);
  canvas.drawCentreString(buf,120,123,1);
  snprintf(buf,48,"Rare aircraft: %d",statsRareToday);
  canvas.setTextColor(0xFFE0); canvas.drawCentreString(buf,120,140,1);
  snprintf(buf,48,"UFOs spotted: %d 👽",statsUfoToday);
  canvas.setTextColor(0xF81F); canvas.drawCentreString(buf,120,157,1);
  canvas.setTextColor(0xC618);
  canvas.drawCentreString("Press button to go back",120,210,1);
  canvas.pushSprite(0,0);
}

// ─── DRAW SPACE SCREEN ───────────────────────────────────────────────────────
void drawSpaceScreen(){
  canvas.fillScreen(TFT_BLACK);
  canvas.fillCircle(120,120,118,TFT_BLACK);
  drawGrid();
  drawSweep();
  // satellites
  for(int i=0;i<satCount;i++){
    latLonToScreen(sats[i].lat,sats[i].lon,viewLat,viewLon,spaceRanges[spaceZoom],sats[i].sx,sats[i].sy);
    if(!inCircle(sats[i].sx,sats[i].sy)) continue;
    uint32_t sc=sats[i].isISS?TFT_CYAN:0x7BFF;
    bool sel=(i==selSat);
    int sz=sel?5:3;
    canvas.fillCircle(sats[i].sx,sats[i].sy,sz,sc);
    canvas.drawLine(sats[i].sx-sz-1,sats[i].sy,sats[i].sx+sz+1,sats[i].sy,sc);
    canvas.drawLine(sats[i].sx,sats[i].sy-sz-1,sats[i].sx,sats[i].sy+sz+1,sc);
    if(sel){ canvas.drawCircle(sats[i].sx,sats[i].sy,8,TFT_WHITE); canvas.drawCircle(sats[i].sx,sats[i].sy,9,sc); }
    canvas.setTextSize(1); canvas.setTextColor(sc);
    canvas.drawString(sats[i].name.c_str(),sats[i].sx+8,sats[i].sy-4);
  }
  // launches
  for(int i=0;i<launchCount;i++){
    latLonToScreen(launches[i].siteLat,launches[i].siteLon,viewLat,viewLon,spaceRanges[spaceZoom],launches[i].sx,launches[i].sy);
    if(!inCircle(launches[i].sx,launches[i].sy)) continue;
    bool imminent=launches[i].minutesToLaunch<=60;
    bool flash=imminent?(millis()%500)<250:true;
    uint32_t lc=flash?(imminent?TFT_ORANGE:0xFD20):0x7400;
    bool sel=(i==selLaunch);
    int sz=sel?6:4;
    canvas.drawLine(launches[i].sx-sz,launches[i].sy,launches[i].sx+sz,launches[i].sy,lc);
    canvas.drawLine(launches[i].sx,launches[i].sy-sz,launches[i].sx,launches[i].sy+sz,lc);
    canvas.fillCircle(launches[i].sx,launches[i].sy,2,lc);
    if(sel){ canvas.drawCircle(launches[i].sx,launches[i].sy,9,TFT_WHITE); }
    canvas.setTextSize(1); canvas.setTextColor(lc);
    canvas.drawString(launches[i].rocketName.c_str(),launches[i].sx+8,launches[i].sy-4);
  }
  // panels
  if(selSat>=0&&selSat<satCount) drawSatellitePanel(selSat);
  else if(selLaunch>=0&&selLaunch<launchCount) drawLaunchPanel(selLaunch);
  // HUD
  const char* modeLabels[]={"SPACE","SELECT"};
  uint32_t modeCols[]={0x07FF,0xFFE0};
  drawHUD(modeLabels[spaceMode],modeCols[spaceMode],satCount+launchCount,spaceRanges[spaceZoom],true);
  canvas.pushSprite(0,0);
}

// ─── DRAW WEATHER APP ────────────────────────────────────────────────────────
void drawWeatherApp(){
  canvas.fillScreen(TFT_BLACK);
  canvas.fillCircle(120,120,118,0x0410);
  canvas.drawCircle(120,120,118,0xFD20);
  canvas.setTextColor(0xFD20);
  canvas.drawCentreString("🌤 WEATHER",120,18,2);
  canvas.setTextColor(TFT_WHITE); canvas.setTextSize(1);
  canvas.drawCentreString(locationCity.c_str(),120,46,2);
  if(weatherLoaded){
    char buf[48];
    snprintf(buf,48,"%.1f°C",weatherTemp);
    canvas.setTextColor(weatherTemp>20?TFT_RED:weatherTemp>10?0xFD20:TFT_CYAN);
    canvas.drawCentreString(buf,120,72,2);
    snprintf(buf,48,"Wind: %.0f kts %s",weatherWindSpd,compassDir(weatherWindDir).c_str());
    canvas.setTextColor(TFT_WHITE); canvas.drawCentreString(buf,120,100,1);
    snprintf(buf,48,"Cloud: %.0f%%",weatherCloud);
    canvas.setTextColor(0xC618); canvas.drawCentreString(buf,120,116,1);
    snprintf(buf,48,"Rain: %.1f mm",weatherRain);
    canvas.setTextColor(0x07FF); canvas.drawCentreString(buf,120,132,1);
    // simple weather icon
    if(weatherRain>0.5f){ canvas.setTextColor(0x07FF); canvas.drawCentreString("🌧 RAIN",120,155,2); }
    else if(weatherCloud>70){ canvas.setTextColor(0xC618); canvas.drawCentreString("☁ CLOUDY",120,155,2); }
    else if(weatherCloud>30){ canvas.setTextColor(0xFD20); canvas.drawCentreString("⛅ PARTLY CLOUDY",120,155,2); }
    else{ canvas.setTextColor(0xFFE0); canvas.drawCentreString("☀ CLEAR",120,155,2); }
  } else {
    canvas.setTextColor(0xC618); canvas.drawCentreString("Loading weather...",120,100,1);
  }
  canvas.setTextColor(0xC618);
  canvas.drawCentreString("Press button to go back",120,210,1);
  canvas.pushSprite(0,0);
}

// ─── PLANE FILTERS ──────────────────────────────────────────────────────────
bool filterAirliners=true, filterMilitary=true, filterPrivate=true;
bool filterHelicopters=true, filterUnknown=true;
int filterMinAlt=0; // 0=off, 1=1000ft, 2=5000ft, 3=10000ft
int filterMinSpd=0; // 0=off, 1=50kts, 2=100kts, 3=250kts
int filterSettingIdx=0;
#define NUM_FILTER_SETTINGS 9

void drawFilterSettings(){
  canvas.fillScreen(TFT_BLACK);
  canvas.fillCircle(120,120,118,0x0821);
  canvas.drawCircle(120,120,118,0xFD20);
  canvas.setTextColor(0xFD20);
  canvas.drawCentreString("PLANE FILTERS",120,14,1);
  canvas.setTextSize(1);
  const char* labels[]={
    "Min Altitude","Min Speed",
    "Show Airliners","Show Military",
    "Show Private Jets","Show Helicopters",
    "Show Unknown"
  };
  const char* altVals[]={"OFF","1000ft","5000ft","10000ft"};
  const char* spdVals[]={"OFF","50kts","100kts","250kts"};
  bool* bools[]={&filterAirliners,&filterMilitary,&filterPrivate,&filterHelicopters,&filterUnknown};
  int yStart=34;
  for(int i=0;i<7;i++){
    bool sel=(i==filterSettingIdx);
    canvas.setTextColor(sel?TFT_WHITE:0xC618);
    if(sel){ canvas.fillRoundRect(15,yStart-2,210,14,3,0x2104); canvas.drawRoundRect(15,yStart-2,210,14,3,0xFD20); }
    char buf[40];
    if(i==0) snprintf(buf,40,"%s: %s",labels[i],altVals[filterMinAlt]);
    else if(i==1) snprintf(buf,40,"%s: %s",labels[i],spdVals[filterMinSpd]);
    else snprintf(buf,40,"%s: %s",labels[i],*bools[i-2]?"ON":"OFF");
    canvas.drawCentreString(buf,120,yStart,1);
    yStart+=18;
  }
  canvas.setTextColor(0xC618);
  canvas.drawCentreString("Rotate=select  Press=toggle",120,164,1);
  canvas.drawCentreString("Hold btn=back",120,178,1);
  if(filterOn){ canvas.setTextColor(TFT_GREEN); canvas.drawCentreString("FILTERS ACTIVE",120,196,1); }
  canvas.pushSprite(0,0);
}

// ─── GAMES ───────────────────────────────────────────────────────────────────
int gameSelected=0;
#define NUM_GAMES 3
const char* gameNames[]={"PLANE CATCHER","AIRPORT QUIZ","ROCKET LAUNCH"};

// --- Plane Catcher ---

#define MAX_FLYING 5
FlyingPlane flyingPlanes[MAX_FLYING];
int catchScore=0, catchLives=3, catchHighScore=0;
bool catchGameOver=false;
unsigned long catchLastSpawn=0, catchLastMove=0;

void spawnFlyingPlane(int i){
  flyingPlanes[i].active=true;
  int edge=random(4);
  if(edge==0){flyingPlanes[i].x=120+random(-80,80);flyingPlanes[i].y=20;flyingPlanes[i].dx=random(-2,3);flyingPlanes[i].dy=random(1,3);}
  else if(edge==1){flyingPlanes[i].x=220;flyingPlanes[i].y=120+random(-80,80);flyingPlanes[i].dx=random(-3,-1);flyingPlanes[i].dy=random(-2,3);}
  else if(edge==2){flyingPlanes[i].x=120+random(-80,80);flyingPlanes[i].y=220;flyingPlanes[i].dx=random(-2,3);flyingPlanes[i].dy=random(-3,-1);}
  else{flyingPlanes[i].x=20;flyingPlanes[i].y=120+random(-80,80);flyingPlanes[i].dx=random(1,3);flyingPlanes[i].dy=random(-2,3);}
  const char* labels[]={"BAW","EZY","RYR","UAL","DAL","AFR","DLH","UAE"};
  flyingPlanes[i].label=String(labels[random(8)])+String(random(100,999));
}

void initPlaneCatcher(){
  catchScore=0; catchLives=3; catchGameOver=false;
  for(int i=0;i<MAX_FLYING;i++) flyingPlanes[i].active=false;
  catchLastSpawn=millis(); catchLastMove=millis();
  spawnFlyingPlane(0);
}

void runPlaneCatcher(){
  if(catchGameOver){
    canvas.fillScreen(TFT_BLACK);
    canvas.fillCircle(120,120,118,0x0821);
    canvas.drawCircle(120,120,118,TFT_RED);
    canvas.setTextColor(TFT_RED); canvas.drawCentreString("GAME OVER!",120,75,2);
    canvas.setTextColor(TFT_WHITE);
    char buf[32]; snprintf(buf,32,"Score: %d",catchScore); canvas.drawCentreString(buf,120,105,2);
    snprintf(buf,32,"Best: %d",catchHighScore); canvas.setTextColor(0xFD20); canvas.drawCentreString(buf,120,130,1);
    canvas.setTextColor(0xC618); canvas.drawCentreString("Press btn to play again",120,165,1);
    canvas.drawCentreString("Hold btn to exit",120,181,1);
    canvas.pushSprite(0,0);
    if(M5Dial.BtnA.wasPressed()){ initPlaneCatcher(); }
    return;
  }
  // move planes
  unsigned long now=millis();
  int spd=1+catchScore/5;
  if(now-catchLastMove>80/spd){
    catchLastMove=now;
    for(int i=0;i<MAX_FLYING;i++){
      if(!flyingPlanes[i].active) continue;
      flyingPlanes[i].x+=flyingPlanes[i].dx;
      flyingPlanes[i].y+=flyingPlanes[i].dy;
      if(!inCircle(flyingPlanes[i].x,flyingPlanes[i].y)){
        flyingPlanes[i].active=false;
        catchLives--;
        M5Dial.Speaker.tone(300,100);
        if(catchLives<=0){ catchGameOver=true; if(catchScore>catchHighScore) catchHighScore=catchScore; }
      }
    }
  }
  // spawn
  if(now-catchLastSpawn>2000-min(catchScore*50,1500)){
    catchLastSpawn=now;
    for(int i=0;i<MAX_FLYING;i++) if(!flyingPlanes[i].active){ spawnFlyingPlane(i); break; }
  }
  // draw
  canvas.fillScreen(TFT_BLACK);
  canvas.fillCircle(120,120,118,0x0821);
  canvas.drawCircle(120,120,118,0x07E0);
  canvas.setTextColor(TFT_GREEN); canvas.setTextSize(1);
  canvas.drawCentreString("PLANE CATCHER",120,14,1);
  char buf[32]; snprintf(buf,32,"Score:%d",catchScore); canvas.setTextColor(TFT_WHITE); canvas.drawString(buf,10,14);
  for(int i=0;i<catchLives;i++) canvas.fillCircle(190+i*12,18,4,TFT_RED);
  for(int i=0;i<MAX_FLYING;i++){
    if(!flyingPlanes[i].active) continue;
    float ang=atan2(flyingPlanes[i].dy,flyingPlanes[i].dx)*180.0f/M_PI+90;
    drawPlane(flyingPlanes[i].x,flyingPlanes[i].y,ang,TFT_GREEN,false);
    canvas.setTextColor(0xC618); canvas.drawString(flyingPlanes[i].label.c_str(),flyingPlanes[i].x+8,flyingPlanes[i].y-4);
  }
  canvas.setTextColor(0xC618); canvas.drawCentreString("TAP planes to catch!",120,225,1);
  canvas.pushSprite(0,0);
  // touch to catch
  if(M5Dial.Touch.getCount()>0){
    auto t=M5Dial.Touch.getDetail(0);
    if(t.state==2){
      for(int i=0;i<MAX_FLYING;i++){
        if(!flyingPlanes[i].active) continue;
        if(abs(t.x-flyingPlanes[i].x)<=14&&abs(t.y-flyingPlanes[i].y)<=14){
          flyingPlanes[i].active=false;
          catchScore++;
          M5Dial.Speaker.tone(1200,40);
          spawnFlyingPlane(i);
        }
      }
    }
  }
}

// --- Airport Quiz ---

QuizQ quizQuestions[]={
  {"EGLL","UK",{"UK","France","Germany","Spain"}},
  {"KJFK","USA",{"Canada","USA","Mexico","Brazil"}},
  {"OMDB","UAE",{"Saudi Arabia","UAE","Qatar","Kuwait"}},
  {"YSSY","Australia",{"New Zealand","Australia","Japan","China"}},
  {"LFPG","France",{"Belgium","France","Italy","Portugal"}},
  {"EDDF","Germany",{"Austria","Switzerland","Germany","Poland"}},
  {"LEMD","Spain",{"Spain","Portugal","Italy","Greece"}},
  {"EHAM","Netherlands",{"Belgium","Netherlands","Denmark","Sweden"}},
  {"RJTT","Japan",{"South Korea","China","Japan","Taiwan"}},
  {"ZBAA","China",{"China","Mongolia","Russia","South Korea"}},
  {"VIDP","India",{"India","Pakistan","Bangladesh","Nepal"}},
  {"FACT","South Africa",{"South Africa","Kenya","Nigeria","Egypt"}},
  {"CYYZ","Canada",{"USA","Canada","Mexico","Cuba"}},
  {"SBGR","Brazil",{"Argentina","Brazil","Chile","Colombia"}},
  {"WSSS","Singapore",{"Malaysia","Singapore","Thailand","Indonesia"}},
};
#define NUM_QUIZ_Q 15
int quizIdx=0, quizScore=0, quizTotal=0, quizSelected=0;
bool quizAnswered=false, quizCorrect=false;

void initQuiz(){ quizIdx=random(NUM_QUIZ_Q); quizScore=0; quizTotal=0; quizSelected=0; quizAnswered=false; }

void runAirportQuiz(){
  if(quizTotal>=10){
    canvas.fillScreen(TFT_BLACK);
    canvas.fillCircle(120,120,118,0x0821);
    canvas.drawCircle(120,120,118,0xFD20);
    canvas.setTextColor(0xFD20); canvas.drawCentreString("QUIZ DONE!",120,70,2);
    char buf[32]; snprintf(buf,32,"%d / 10 correct",quizScore);
    canvas.setTextColor(TFT_WHITE); canvas.drawCentreString(buf,120,105,2);
    canvas.setTextColor(quizScore>=7?TFT_GREEN:quizScore>=4?0xFD20:TFT_RED);
    canvas.drawCentreString(quizScore>=7?"EXCELLENT!":quizScore>=4?"GOOD TRY!":"KEEP PRACTISING!",120,135,1);
    canvas.setTextColor(0xC618); canvas.drawCentreString("Press btn to play again",120,170,1);
    canvas.pushSprite(0,0);
    if(M5Dial.BtnA.wasPressed()){ initQuiz(); }
    return;
  }
  QuizQ& q=quizQuestions[quizIdx%NUM_QUIZ_Q];
  // encoder scroll
  long enc=M5Dial.Encoder.read();
  long diff=enc-lastEnc;
  if(diff!=0){ quizSelected=(quizSelected+diff+4)%4; lastEnc=enc; M5Dial.Speaker.tone(900,20); }
  canvas.fillScreen(TFT_BLACK);
  canvas.fillCircle(120,120,118,0x0821);
  canvas.drawCircle(120,120,118,0xFD20);
  canvas.setTextColor(0xFD20); canvas.setTextSize(1);
  canvas.drawCentreString("AIRPORT QUIZ",120,14,1);
  char buf[32]; snprintf(buf,32,"Q %d/10",quizTotal+1); canvas.setTextColor(0xC618); canvas.drawString(buf,10,14);
  canvas.setTextColor(TFT_WHITE);
  canvas.drawCentreString("Which country is:",120,38,1);
  canvas.setTextColor(TFT_CYAN); canvas.drawCentreString(q.icao,120,58,2);
  for(int i=0;i<4;i++){
    bool sel=(i==quizSelected);
    uint32_t col=TFT_WHITE;
    if(quizAnswered){
      if(strcmp(q.opts[i],q.correct)==0) col=TFT_GREEN;
      else if(sel) col=TFT_RED;
    } else if(sel) col=0xFD20;
    int y=95+i*32;
    if(sel&&!quizAnswered){ canvas.fillRoundRect(25,y-2,190,20,4,0x2104); canvas.drawRoundRect(25,y-2,190,20,4,0xFD20); }
    canvas.setTextColor(col);
    char opt[32]; snprintf(opt,32,"%c) %s",'A'+i,q.opts[i]);
    canvas.drawCentreString(opt,120,y,1);
  }
  if(quizAnswered){
    canvas.setTextColor(quizCorrect?TFT_GREEN:TFT_RED);
    canvas.drawCentreString(quizCorrect?"CORRECT! ":"WRONG!",120,225,1);
  } else {
    canvas.setTextColor(0xC618); canvas.drawCentreString("Press btn to answer",120,225,1);
  }
  canvas.pushSprite(0,0);
  if(M5Dial.BtnA.wasPressed()){
    if(!quizAnswered){
      quizAnswered=true;
      quizCorrect=(strcmp(q.opts[quizSelected],q.correct)==0);
      if(quizCorrect){ quizScore++; M5Dial.Speaker.tone(1800,80); }
      else M5Dial.Speaker.tone(300,150);
    } else {
      quizAnswered=false; quizTotal++; quizSelected=0;
      quizIdx=(quizIdx+1)%NUM_QUIZ_Q;
    }
  }
}

// --- Rocket Launch Timing Game ---
int rocketScore=0; // ms off, lower=better
int rocketBest=99999;
bool rocketRunning=false, rocketWaiting=false, rocketResult=false;
unsigned long rocketStart=0, rocketLaunchAt=0;

void initRocketGame(){ rocketRunning=false; rocketWaiting=true; rocketResult=false;
  rocketLaunchAt=millis()+random(3000,10000); // random delay
}

void runRocketLaunch(){
  canvas.fillScreen(TFT_BLACK);
  canvas.fillCircle(120,120,118,0x0821);
  canvas.drawCircle(120,120,118,0xFD20);
  canvas.setTextColor(0xFD20); canvas.setTextSize(1);
  canvas.drawCentreString("ROCKET LAUNCH",120,14,1);
  if(rocketBest<99999){ char buf[32]; snprintf(buf,32,"Best: %dms",rocketBest); canvas.setTextColor(0xC618); canvas.drawString(buf,8,14); }
  if(rocketResult){
    canvas.setTextColor(rocketScore<100?TFT_GREEN:rocketScore<300?0xFD20:TFT_RED);
    canvas.drawCentreString(rocketScore<100?"PERFECT!":rocketScore<300?"GOOD!":"TOO SLOW!",120,70,2);
    char buf[32]; snprintf(buf,32,"%d ms off",rocketScore); canvas.setTextColor(TFT_WHITE); canvas.drawCentreString(buf,120,105,1);
    canvas.setTextColor(0xC618); canvas.drawCentreString("Press btn to retry",120,165,1);
    canvas.pushSprite(0,0);
    if(M5Dial.BtnA.wasPressed()){ initRocketGame(); }
    return;
  }
  if(rocketWaiting){
    unsigned long now=millis();
    long remaining=(long)(rocketLaunchAt-now);
    if(remaining>0){
      canvas.setTextColor(TFT_WHITE); canvas.drawCentreString("Get ready...",120,80,1);
      char buf[32];
      if(remaining>1000){ snprintf(buf,32,"T-%lds",(remaining/1000)); canvas.setTextColor(0xFD20); canvas.drawCentreString(buf,120,110,2); }
      else { canvas.setTextColor(TFT_RED); canvas.drawCentreString("NOW!",120,110,2); }
      canvas.setTextColor(0xC618); canvas.drawCentreString("Press BTN at T-0!",120,160,1);
      // draw rocket
      int rx=120, ry=190;
      canvas.fillTriangle(rx,ry-20,rx-8,ry+10,rx+8,ry+10,0xFD20);
      canvas.fillRect(rx-5,ry+10,10,15,0xC618);
      if(remaining<500){ canvas.fillCircle(rx,ry+30,4,TFT_ORANGE); canvas.fillCircle(rx-3,ry+34,3,TFT_RED); canvas.fillCircle(rx+3,ry+34,3,TFT_RED); }
    } else {
      rocketWaiting=false; rocketRunning=true; rocketStart=millis();
    }
    // early press = fail
    if(M5Dial.BtnA.wasPressed()&&remaining>200){
      rocketScore=9999; if(rocketScore<rocketBest) rocketBest=rocketScore;
      rocketResult=true; rocketRunning=false; rocketWaiting=false;
      M5Dial.Speaker.tone(300,200);
    }
  }
  if(rocketRunning){
    canvas.setTextColor(TFT_RED); canvas.drawCentreString("LAUNCH!",120,100,2);
    canvas.setTextColor(0xFD20); canvas.drawCentreString("PRESS NOW!",120,140,2);
    int rx=120, ry=100;
    canvas.fillTriangle(rx,ry-50,rx-8,ry-20,rx+8,ry-20,0xFD20);
    canvas.fillCircle(rx,ry-10,5,TFT_ORANGE); canvas.fillCircle(rx,ry-5,8,TFT_RED);
    if(millis()-rocketStart>2000){ rocketScore=2000; if(rocketScore<rocketBest) rocketBest=rocketScore; rocketResult=true; rocketRunning=false; M5Dial.Speaker.tone(300,200); }
    if(M5Dial.BtnA.wasPressed()){ rocketScore=(int)(millis()-rocketStart); if(rocketScore<rocketBest) rocketBest=rocketScore; rocketResult=true; rocketRunning=false; M5Dial.Speaker.tone(rocketScore<200?1800:rocketScore<500?1200:600,100); }
  }
  canvas.pushSprite(0,0);
}

void drawGamesMenu(){
  canvas.fillScreen(TFT_BLACK);
  canvas.fillCircle(120,120,118,0x0821);
  canvas.drawCircle(120,120,118,0xF81F);
  canvas.setTextColor(0xF81F);
  canvas.drawCentreString("GAMES",120,18,2);
  canvas.setTextColor(0xC618); canvas.setTextSize(1);
  canvas.drawCentreString("Rotate to select, Press to play",120,42,1);
  for(int i=0;i<NUM_GAMES;i++){
    bool sel=(i==gameSelected);
    int y=75+i*45;
    if(sel){ canvas.fillRoundRect(20,y-4,200,32,6,0x2104); canvas.drawRoundRect(20,y-4,200,32,6,0xF81F); }
    canvas.setTextColor(sel?TFT_WHITE:0xC618);
    canvas.drawCentreString(gameNames[i],120,y,1);
    if(i==0){ canvas.setTextColor(sel?0xFD20:0x4208); canvas.drawCentreString("Tap planes before they escape!",120,y+14,1); }
    else if(i==1){ canvas.setTextColor(sel?0xFD20:0x4208); canvas.drawCentreString("Guess the airport country!",120,y+14,1); }
    else { canvas.setTextColor(sel?0xFD20:0x4208); canvas.drawCentreString("Press at exactly T-0!",120,y+14,1); }
  }
  canvas.setTextColor(0xC618); canvas.drawCentreString("Hold btn to go home",120,218,1);
  canvas.pushSprite(0,0);
}

// ─── DRAW SETTINGS ───────────────────────────────────────────────────────────
bool adjustingBrightness=false;
void drawSettings(){
  canvas.fillScreen(TFT_BLACK);
  canvas.fillCircle(120,120,118,0x0821);
  canvas.drawCircle(120,120,118,0xC618);
  canvas.setTextColor(0xC618);
  canvas.drawCentreString("SETTINGS",120,14,2);
  canvas.setTextSize(1);
  if(adjustingBrightness){
    canvas.setTextColor(TFT_WHITE);
    canvas.drawCentreString("BRIGHTNESS",120,50,1);
    int pct=map(screenBright,10,255,4,100);
    char buf[16]; snprintf(buf,16,"%d%%",pct);
    canvas.setTextColor(0xFD20); canvas.drawCentreString(buf,120,80,2);
    int bw=180, bh=14, bx=30, by=108;
    canvas.drawRoundRect(bx,by,bw,bh,4,0xC618);
    int fill=map(screenBright,10,255,0,bw-2);
    canvas.fillRoundRect(bx+1,by+1,fill,bh-2,3,0xFD20);
    canvas.setTextColor(0xC618);
    canvas.drawCentreString("Rotate knob to adjust",120,135,1);
    canvas.drawCentreString("Press to save",120,150,1);
    canvas.pushSprite(0,0);
    return;
  }
  canvas.setTextColor(nightAuto?TFT_GREEN:0xC618);
  canvas.drawCentreString(nightAuto?"NIGHT: AUTO":"NIGHT: MANUAL",120,48,1);
  canvas.setTextColor(nightMode?TFT_YELLOW:0xC618);
  canvas.drawCentreString(nightMode?"NIGHT MODE: ON":"NIGHT MODE: OFF",120,64,1);
  canvas.setTextColor(filterOn?TFT_GREEN:0xC618);
  canvas.drawCentreString(filterOn?"FILTER: ON":"FILTER: OFF",120,84,1);
  canvas.setTextColor(ufoMode?0xF81F:0xC618);
  canvas.drawCentreString(ufoMode?"UFO MODE: ON":"UFO MODE: OFF",120,100,1);
  int pct=map(screenBright,10,255,4,100);
  char brbuf[24]; snprintf(brbuf,24,"BRIGHTNESS: %d%%",pct);
  canvas.setTextColor(0xFD20);
  canvas.drawCentreString(brbuf,120,120,1);
  canvas.setTextColor(TFT_RED);
  canvas.drawCentreString("[ RESET WIFI ]",120,142,1);
  canvas.setTextColor(0xC618);
  canvas.drawCentreString("Tap to toggle options",120,168,1);
  canvas.drawCentreString("Press btn to go back",120,184,1);
  canvas.pushSprite(0,0);
}

// ─── TOUCH HANDLER ───────────────────────────────────────────────────────────
void handleTouch(int tx, int ty){
  // help screen
  if(showHelp){ showHelp=false; return; }
  // qr screen
  if(showQR){ showQR=false; return; }
  // help button (bottom right circle)
  if((tx-224)*(tx-224)+(ty-224)*(ty-224)<=144){ showHelp=true; return; }

  if(appState==APP_HOME){
    // tap on app icons
    float angles[]={270,342,54,126,198};
    for(int i=0;i<NUM_APPS;i++){
      float a=degToRad(angles[i]);
      int cx=120+(int)(75*cos(a)), cy=120+(int)(75*sin(a));
      if((tx-cx)*(tx-cx)+(ty-cy)*(ty-cy)<=22*22){
        appState=apps[i].target;
        if(appState==APP_FLIGHT){ lastFetch=0; fetchFlights(); fetchAirports(); }
        if(appState==APP_SPACE){ fetchSpace(); }
        if(appState==APP_WEATHER_APP&&!weatherLoaded){ fetchWeather(); }
        return;
      }
    }
    return;
  }

  if(appState==APP_FLIGHT){
    // emergency banner
    if(showEmergBanner&&ty>=28&&ty<=46&&tx>=20&&tx<=220){ selAc=emergBannerIdx; return; }
    // launch banner
    if(showLaunchBanner&&ty>=28&&ty<=46&&tx>=20&&tx<=220){ appState=APP_SPACE; return; }
    // tap plane
    for(int i=0;i<acCount;i++){
      if(abs(tx-ac[i].sx)<=10&&abs(ty-ac[i].sy)<=10){ selAc=i; selAp=-1; return; }
    }
    // tap airport
    for(int i=0;i<apCount;i++){
      int sx,sy; latLonToScreen(airports[i].lat,airports[i].lon,viewLat,viewLon,planeRanges[planeZoom],sx,sy);
      if(abs(tx-sx)<=8&&abs(ty-sy)<=8){ selAp=i; selAc=-1; return; }
    }
    // tap selected panel - tap to clear
    if(ty>150){ selAc=-1; selAp=-1; return; }
    selAc=-1; selAp=-1;
  }

  if(appState==APP_SPACE){
    // tap satellite
    for(int i=0;i<satCount;i++){
      if(abs(tx-sats[i].sx)<=10&&abs(ty-sats[i].sy)<=10){ selSat=i; selLaunch=-1; return; }
    }
    // tap launch
    for(int i=0;i<launchCount;i++){
      if(abs(tx-launches[i].sx)<=10&&abs(ty-launches[i].sy)<=10){ selLaunch=i; selSat=-1; return; }
    }
    // tap livestream panel
    if((selSat>=0||selLaunch>=0)&&ty>200&&ty<220){
      qrUrl=selSat>=0?sats[selSat].streamUrl:launches[selLaunch].streamUrl;
      streamTitle=selSat>=0?sats[selSat].name:launches[selLaunch].rocketName;
      showQR=true; return;
    }
    if(ty>150){ selSat=-1; selLaunch=-1; return; }
    selSat=-1; selLaunch=-1;
  }

  if(appState==APP_SETTINGS){
    if(adjustingBrightness){ adjustingBrightness=false; prefs.begin("cfg",false); prefs.putInt("bright",screenBright); prefs.end(); return; }
    if(ty>=40&&ty<=56){ nightAuto=!nightAuto; return; }
    if(ty>=56&&ty<=72){ if(!nightAuto) nightMode=!nightMode; return; }
    if(ty>=76&&ty<=92){ filterOn=!filterOn; return; }
    if(ty>=92&&ty<=108){ ufoMode=!ufoMode; return; }
    if(ty>=112&&ty<=128){ adjustingBrightness=true; return; }
    if(ty>=134&&ty<=150){ prefs.begin("wifi",false); prefs.clear(); prefs.end(); appState=APP_WIFI_SETUP; return; }
  }
}

// ─── SETUP ───────────────────────────────────────────────────────────────────
void setup(){
  auto cfg=M5Dial.config();
  M5Dial.begin(cfg,true,false);
  M5Dial.Display.setBrightness(220);
  canvas.createSprite(240,240);
  canvas.setTextDatum(MC_DATUM);

  // boot screen
  canvas.fillScreen(TFT_BLACK);
  canvas.fillCircle(120,120,118,0x0821);
  canvas.drawCircle(120,120,118,0x07E0);
  canvas.setTextColor(TFT_WHITE);
  canvas.drawCentreString("✈ FLIGHT &",120,80,2);
  canvas.drawCentreString("🚀 SPACE",120,100,2);
  canvas.drawCentreString("RADAR",120,120,2);
  canvas.setTextColor(0x07E0);
  canvas.drawCentreString("M5Dial v2.0",120,148,1);
  canvas.pushSprite(0,0);
  delay(2000);

  // load saved settings
  prefs.begin("cfg",true);
  screenBright=prefs.getInt("bright",220);
  prefs.end();
  M5Dial.Display.setBrightness(screenBright);
  // check saved wifi
  prefs.begin("wifi",true);
  wifiSSID=prefs.getString("ssid","");
  wifiPass=prefs.getString("pass","");
  prefs.end();

  if(wifiSSID.length()==0){
    appState=APP_WIFI_SETUP;
    // intro
    canvas.fillScreen(TFT_BLACK);
    canvas.fillCircle(120,120,118,0x0821);
    canvas.drawCircle(120,120,118,TFT_WHITE);
    canvas.setTextColor(0xFD20);
    canvas.drawCentreString("WiFi Setup",120,60,2);
    canvas.setTextColor(TFT_WHITE); canvas.setTextSize(1);
    canvas.drawCentreString("Rotate dial to",120,95,1);
    canvas.drawCentreString("pick letters",120,110,1);
    canvas.drawCentreString("Press to confirm",120,125,1);
    canvas.drawCentreString("Hold to delete",120,140,1);
    canvas.drawCentreString("Scroll to DONE",120,155,1);
    canvas.pushSprite(0,0);
    delay(3000);
    enteringSSID=true; currentInput=""; charIdx=0;
  } else {
    appState=APP_CONNECTING;
  }
  lastEnc=M5Dial.Encoder.read();
}

// ─── LOOP ────────────────────────────────────────────────────────────────────
void loop(){
  M5Dial.update();
  updateNightMode();

  // ── WIFI KEYBOARD ──────────────────────────────────────────────────────────
  if(appState==APP_WIFI_SETUP){
    long enc=M5Dial.Encoder.read();
    long diff=enc-lastEnc;
    if(diff!=0){ charIdx=(charIdx+diff+charsetLen)%charsetLen; lastEnc=enc; }
    drawWifiKeyboard(enteringSSID);
    canvas.pushSprite(0,0);
    // button press
    if(M5Dial.BtnA.wasPressed()){
      String sel=String(charset[charIdx]);
      if(sel=="DONE"){
        if(enteringSSID){ wifiSSID=currentInput; currentInput=""; charIdx=0; enteringSSID=false; }
        else { wifiPass=currentInput; prefs.begin("wifi",false); prefs.putString("ssid",wifiSSID); prefs.putString("pass",wifiPass); prefs.end(); appState=APP_CONNECTING; }
      } else { currentInput+=sel; }
    }
    if(M5Dial.BtnA.pressedFor(600)&&currentInput.length()>0){ currentInput=currentInput.substring(0,currentInput.length()-1); delay(200); }
    return;
  }

  // ── CONNECTING ─────────────────────────────────────────────────────────────
  if(appState==APP_CONNECTING){
    canvas.fillScreen(TFT_BLACK);
    canvas.fillCircle(120,120,118,0x0821);
    canvas.setTextColor(TFT_WHITE);
    canvas.drawCentreString("Connecting to",120,85,1);
    canvas.drawCentreString("WiFi...",120,100,1);
    static int dots=0;
    char dotStr[8]=""; for(int i=0;i<(dots%4);i++) strcat(dotStr,"●");
    canvas.setTextColor(0x07E0); canvas.drawCentreString(dotStr,120,118,1);
    canvas.setTextColor(0xC618); canvas.drawCentreString(wifiSSID.c_str(),120,135,1);
    canvas.pushSprite(0,0);
    dots++; delay(300);
    WiFi.begin(wifiSSID.c_str(),wifiPass.c_str());
    unsigned long t=millis();
    while(WiFi.status()!=WL_CONNECTED&&millis()-t<12000){ delay(200); }
    if(WiFi.status()==WL_CONNECTED){ appState=APP_LOCATING; }
    else {
      canvas.fillScreen(TFT_BLACK); canvas.fillCircle(120,120,118,0x4000);
      canvas.setTextColor(TFT_RED); canvas.drawCentreString("WiFi Failed!",120,100,2);
      canvas.setTextColor(TFT_WHITE); canvas.drawCentreString("Hold btn to reset",120,130,1);
      canvas.pushSprite(0,0); delay(3000);
      appState=APP_WIFI_SETUP; wifiSSID=""; wifiPass=""; currentInput=""; charIdx=0; enteringSSID=true;
    }
    return;
  }

  // ── LOCATING ───────────────────────────────────────────────────────────────
  if(appState==APP_LOCATING){
    canvas.fillScreen(TFT_BLACK); canvas.fillCircle(120,120,118,0x0821);
    canvas.setTextColor(TFT_WHITE); canvas.drawCentreString("Finding your",120,95,1);
    canvas.drawCentreString("location...",120,110,1);
    canvas.setTextColor(0x07E0); canvas.drawCentreString("📍",120,130,2);
    canvas.pushSprite(0,0);
    geolocate();
    canvas.fillScreen(TFT_BLACK); canvas.fillCircle(120,120,118,0x0821);
    canvas.setTextColor(TFT_GREEN); canvas.drawCentreString("Location found!",120,75,1);
    canvas.setTextColor(TFT_WHITE); canvas.drawCentreString(locationCity.c_str(),120,100,2);
    canvas.drawCentreString(locationCountry.c_str(),120,120,1);
    char coord[32]; snprintf(coord,32,"%.4f, %.4f",homeLat,homeLon);
    canvas.setTextColor(0x07FF); canvas.drawCentreString(coord,120,138,1);
    canvas.pushSprite(0,0); delay(2500);
    // how to use
    canvas.fillScreen(TFT_BLACK); canvas.fillCircle(120,120,118,0x0821);
    canvas.drawCircle(120,120,118,TFT_WHITE);
    canvas.setTextColor(0xFD20); canvas.drawCentreString("HOW TO USE",120,25,2);
    canvas.setTextColor(TFT_WHITE); canvas.setTextSize(1);
    canvas.drawCentreString("Rotate knob = zoom",120,58,1);
    canvas.drawCentreString("Press knob = free scroll",120,73,1);
    canvas.drawCentreString("Short btn = cycle mode",120,88,1);
    canvas.drawCentreString("Hold btn 2s = SPACE mode",120,103,1);
    canvas.drawCentreString("Tap plane = select info",120,118,1);
    canvas.drawCentreString("Tap ? = help screen",120,133,1);
    canvas.drawCentreString("Drag = scroll map",120,148,1);
    canvas.setTextColor(0x07E0); canvas.drawCentreString("Home screen has 5 apps!",120,170,1);
    canvas.setTextColor(0xFD20); canvas.drawCentreString("Select app with knob",120,185,1);
    canvas.drawCentreString("Press knob to open",120,200,1);
    canvas.pushSprite(0,0); delay(4000);
    appState=APP_HOME;
    fetchWeather();
    return;
  }

  // ── HOME SCREEN ────────────────────────────────────────────────────────────
  if(appState==APP_HOME){
    long enc=M5Dial.Encoder.read();
    long diff=enc-lastEnc;
    if(diff!=0){ homeSelected=(homeSelected+diff+NUM_APPS)%NUM_APPS; lastEnc=enc; M5Dial.Speaker.tone(1200,30); }
    drawHomeScreen();
    canvas.pushSprite(0,0);
    if(M5Dial.BtnA.wasPressed()){
      M5Dial.Speaker.tone(1800,50);
      appState=apps[homeSelected].target;
      if(appState==APP_FLIGHT){ lastFetch=0; fetchFlights(); fetchAirports(); }
      if(appState==APP_SPACE){ fetchSpace(); }
      if(appState==APP_WEATHER_APP&&!weatherLoaded){ fetchWeather(); }
      if(appState==APP_GAMES){ gameSelected=0; }
    }
    return;
  }

  // ── GAMES ─────────────────────────────────────────────────────────────────
  if(appState==APP_GAMES){
    static int gamesSubState=0; // 0=menu, 1=planecatcher, 2=quiz, 3=rocket
    if(gamesSubState==0){
      long enc=M5Dial.Encoder.read();
      long diff=enc-lastEnc;
      if(diff!=0){ gameSelected=(gameSelected+diff+NUM_GAMES)%NUM_GAMES; lastEnc=enc; M5Dial.Speaker.tone(900,20); }
      drawGamesMenu();
      if(M5Dial.BtnA.wasPressed()){
        gamesSubState=gameSelected+1;
        if(gamesSubState==1) initPlaneCatcher();
        else if(gamesSubState==2) initQuiz();
        else if(gamesSubState==3) initRocketGame();
      }
    } else if(gamesSubState==1){
      runPlaneCatcher();
    } else if(gamesSubState==2){
      runAirportQuiz();
    } else if(gamesSubState==3){
      runRocketLaunch();
    }
    // hold to go back
    if(M5Dial.BtnA.isPressed()){
      if(btnPressTime==0) btnPressTime=millis();
      if(millis()-btnPressTime>2000&&!btnHeld){ btnHeld=true; if(gamesSubState>0){ gamesSubState=0; } else { appState=APP_HOME; } M5Dial.Speaker.tone(500,50); }
    } else { if(!btnHeld) btnPressTime=0; btnHeld=false; }
    return;
  }

  // ── TOUCH FOR ALL APP SCREENS ──────────────────────────────────────────────
  if(M5Dial.Touch.getCount()>0){
    auto t=M5Dial.Touch.getDetail(0);
    static int prevTx=-1, prevTy=-1;
    static bool dragging=false;
    if(t.state==0){ // pressed
      prevTx=t.x; prevTy=t.y; dragging=false;
    } else if(t.state==1){ // held/dragged
      if(prevTx>=0){
        int dx=t.x-prevTx, dy=t.y-prevTy;
        if(abs(dx)>3||abs(dy)>3){
          dragging=true;
          float dLon=-(float)dx*planeRanges[planeZoom]/(110.0f*120.0f);
          float dLat=(float)dy*planeRanges[planeZoom]/(110.0f*120.0f);
          viewLat+=dLat; viewLon+=dLon;
          freeScroll=true;
          prevTx=t.x; prevTy=t.y;
        }
      }
    } else if(t.state==2){ // released
      if(!dragging){ handleTouch(t.x,t.y); }
      if(dragging){ lastFetch=0; }
      dragging=false; prevTx=-1; prevTy=-1;
    }
  }

  // ── ENCODER ZOOM ──────────────────────────────────────────────────────────
  long enc=M5Dial.Encoder.read();
  long diff=enc-lastEnc;
  if(diff!=0){
    lastEnc=enc;
    if(appState==APP_SETTINGS&&adjustingBrightness){
      screenBright=constrain(screenBright+(diff>0?15:-15),10,255);
      M5Dial.Display.setBrightness(screenBright);
      M5Dial.Speaker.tone(diff>0?1200:900,20);
    } else if(appState==APP_FLIGHT||appState==APP_STATS_APP){
      planeZoom=constrain(planeZoom+(diff>0?1:-1),0,PLANE_ZOOM_COUNT-1);
      M5Dial.Speaker.tone(diff>0?1200:900,30);
    } else if(appState==APP_SPACE){
      spaceZoom=constrain(spaceZoom+(diff>0?1:-1),0,SPACE_ZOOM_COUNT-1);
      M5Dial.Speaker.tone(diff>0?1200:900,30);
    }
  }

  // ── BUTTON ────────────────────────────────────────────────────────────────
  if(M5Dial.BtnA.isPressed()){
    if(btnPressTime==0) btnPressTime=millis();
    if(millis()-btnPressTime>2000&&!btnHeld){
      btnHeld=true;
      // go home
      appState=APP_HOME; homeSelected=0;
      M5Dial.Speaker.tone(600,50); delay(80); M5Dial.Speaker.tone(500,50); delay(80); M5Dial.Speaker.tone(400,50);
      freeScroll=false; viewLat=homeLat; viewLon=homeLon;
    }
  } else {
    if(btnPressTime>0&&!btnHeld&&millis()-btnPressTime<2000){
      // short press
      if(appState==APP_FLIGHT){ flightMode=(FlightMode)((flightMode+1)%2); M5Dial.Speaker.tone(1200,30); }
      else if(appState==APP_SPACE){ spaceMode=(SpaceMode)((spaceMode+1)%2); M5Dial.Speaker.tone(1200,30); }
      else if(appState==APP_STATS_APP||appState==APP_WEATHER_APP||appState==APP_SETTINGS){ appState=APP_HOME; }
    }
    btnPressTime=0; btnHeld=false;
  }

  // ── KNOB PRESS (free scroll toggle) ───────────────────────────────────────
  // M5Dial encoder button not separately exposed — use display tap on centre
  // (handled in touch handler above via centre tap)

  // ── FETCH DATA ────────────────────────────────────────────────────────────
  // ── FILTER SETTINGS (from settings screen) ────────────────────────────────
  // Plane filter navigation handled inside drawFilterSettings via encoder
  // (accessed via settings screen tap in future update)

  if(appState==APP_FLIGHT&&millis()-lastFetch>FETCH_INTERVAL){
    lastFetch=millis();
    fetchFlights();
    fetchAirports();
  }
  if(appState==APP_SPACE&&millis()-lastFetch>FETCH_INTERVAL){
    lastFetch=millis();
    fetchSpace();
  }
  if(millis()-lastWeather>WEATHER_INTERVAL){ lastWeather=millis(); fetchWeather(); }

  // ── DRAW ──────────────────────────────────────────────────────────────────
  if(millis()-lastDraw>33){
    lastDraw=millis();
    sweepAngle=fmod(sweepAngle+2.0f,360.0f);
    if(showHelp){ drawHelp(); canvas.pushSprite(0,0); return; }
    if(showQR){ drawQRCode(qrUrl,streamTitle); canvas.pushSprite(0,0); return; }
    if(appState==APP_FLIGHT) drawFlightScreen();
    else if(appState==APP_SPACE) drawSpaceScreen();
    else if(appState==APP_STATS_APP) drawStatsScreen();
    else if(appState==APP_WEATHER_APP) drawWeatherApp();
    else if(appState==APP_SETTINGS) drawSettings();
    else if(appState==APP_HOME) { drawHomeScreen(); canvas.pushSprite(0,0); }
  }
}
