Presence Reader Multi-Protocol

#include <Arduino.h>
#include <SPI.h>
#include <MFRC522.h>
#include <Arduino_GFX_Library.h>
#include <BLEDevice.h>
#include <BLEServer.h>
#include <BLEUtils.h>
#include <WiFi.h>
#include <WebServer.h>
#include <Preferences.h>

// ESP32-2432S028R (CYD). MFRC522: SCK=0, MOSI=1, MISO=3, SS=27, RST=22.
#define RFID_SCK_PIN   0
#define RFID_MOSI_PIN  1
#define RFID_MISO_PIN  3
#define RFID_CS_PIN   27
#define RFID_RST_PIN  22
#define TFT_DC_PIN     2
#define TFT_CS_PIN    15
#define TFT_SCK_PIN   14
#define TFT_MOSI_PIN  13
#define TFT_MISO_PIN  12
#define TFT_BL_PIN    21
#define SPEAKER_PIN    26
#define RGB_RED_PIN     4
#define RGB_GREEN_PIN  16
#define RGB_BLUE_PIN   17

#define BLE_SERVICE_UUID "19B10000-E8F2-537E-4F6C-D104768A1214"
#define BLE_STAMP_UUID   "19B10001-E8F2-537E-4F6C-D104768A1214"
#define MAX_LOG_ENTRIES 50

// Hoisted type definitions
struct AttendanceEntry { char identity[24]; char source; unsigned long millisAtStamp; };


// Forward declarations
void setRgb(bool r, bool g, bool b);
void beepOk();
void beepDenied();
void showScreen(const String &status, const String &detail, uint16_t color);
void showReady();
void addLog(const char *id, char source);
String uidAsText(const MFRC522::Uid &uid);
bool uidIsAuthorized(const MFRC522::Uid &uid);
bool bleUserAllowed(String name);
void setupBle();
void handleRfid();
void handleBle();
String pageHtml();
void setupWeb();
void printLog();

const char *SETUP_AP_NAME = "Presenze-Setup";
const char *SETUP_AP_PASSWORD = "presenze2026";


Arduino_DataBus *displayBus = new Arduino_ESP32SPI(TFT_DC_PIN, TFT_CS_PIN, TFT_SCK_PIN, TFT_MOSI_PIN, TFT_MISO_PIN, HSPI);
Arduino_GFX *display = new Arduino_ILI9341(displayBus, GFX_NOT_DEFINED, 1, false);
MFRC522 rfid(RFID_CS_PIN, RFID_RST_PIN);
WebServer webServer(80);
Preferences preferences;
AttendanceEntry attendanceLog[MAX_LOG_ENTRIES];
uint8_t logHead = 0, logCount = 0;
volatile bool bleStampWaiting = false;
String blePayload;
String bleName = "LettorePresenze";
String blePin = "1234";
String bleUsers = ""; // empty = every name is accepted, if PIN is correct

const uint8_t authorizedUIDs[][7] = {{0xDE,0xAD,0xBE,0xEF,0,0,0},{0x01,0x02,0x03,0x04,0x05,0,0}};
const uint8_t authorizedUIDLengths[] = {4, 5};
const uint8_t authorizedCount = sizeof(authorizedUIDLengths) / sizeof(authorizedUIDLengths[0]);

void setRgb(bool r, bool g, bool b) { digitalWrite(RGB_RED_PIN, r ? LOW : HIGH); digitalWrite(RGB_GREEN_PIN, g ? LOW : HIGH); digitalWrite(RGB_BLUE_PIN, b ? LOW : HIGH); }
void beepOk() { tone(SPEAKER_PIN, 1800, 100); delay(130); }
void beepDenied() { for (uint8_t i=0;i<3;i++) { tone(SPEAKER_PIN, 500, 70); delay(130); } }
void showScreen(const String &status, const String &detail, uint16_t color) {
  display->fillScreen(BLACK); display->setTextColor(WHITE); display->setTextSize(3); display->setCursor(18, 50); display->println("PRESENZE");
  display->fillRoundRect(12, 108, 296, 84, 10, color); display->setTextColor(BLACK); display->setTextSize(2); display->setCursor(24, 136); display->println(status);
  display->setTextColor(WHITE); display->setTextSize(2); display->setCursor(18, 220); display->println(detail);
}
void showReady() { setRgb(false,false,false); showScreen("AVVICINA", "RFID/NFC o BLE", CYAN); }
void addLog(const char *id, char source) {
  strncpy(attendanceLog[logHead].identity, id, 23); attendanceLog[logHead].identity[23] = 0;
  attendanceLog[logHead].source=source; attendanceLog[logHead].millisAtStamp=millis(); logHead=(logHead+1)%MAX_LOG_ENTRIES; if(logCount<MAX_LOG_ENTRIES) logCount++;
}
String uidAsText(const MFRC522::Uid &uid) { String s; for(byte i=0;i<uid.size;i++){if(uid.uidByte[i]<16)s+='0';s+=String(uid.uidByte[i],HEX);if(i+1<uid.size)s+=':';} s.toUpperCase(); return s; }
bool uidIsAuthorized(const MFRC522::Uid &uid) {
  for(uint8_t u=0;u<authorizedCount;u++){ if(uid.size!=authorizedUIDLengths[u]) continue; bool ok=true; for(byte i=0;i<uid.size;i++)if(uid.uidByte[i]!=authorizedUIDs[u][i]){ok=false;break;} if(ok)return true; } return false;
}
bool bleUserAllowed(String name) {
  name.trim();
  if (bleUsers.isEmpty()) return true;
  String list = "," + bleUsers + ","; list.toLowerCase();
  String wanted = "," + name + ","; wanted.toLowerCase();
  return list.indexOf(wanted) >= 0;
}
class StampCallbacks : public BLECharacteristicCallbacks { void onWrite(BLECharacteristic *c) override { std::string v=c->getValue(); if(!v.empty()){blePayload=String(v.c_str()); bleStampWaiting=true;} } };
void setupBle() {
  BLEDevice::init(bleName.c_str()); BLEServer *server=BLEDevice::createServer(); BLEService *service=server->createService(BLE_SERVICE_UUID);
  BLECharacteristic *stamp=service->createCharacteristic(BLE_STAMP_UUID, BLECharacteristic::PROPERTY_WRITE); stamp->setCallbacks(new StampCallbacks()); service->start();
  BLEAdvertising *advertising=BLEDevice::getAdvertising(); advertising->addServiceUUID(BLE_SERVICE_UUID); advertising->start();
}
void handleRfid() {
  if(!rfid.PICC_IsNewCardPresent() || !rfid.PICC_ReadCardSerial()) return;
  String uid=uidAsText(rfid.uid); Serial.printf("[RFID] UID: %s\n",uid.c_str());
  if(uidIsAuthorized(rfid.uid)){showScreen("ACCESSO OK",uid,GREEN);setRgb(false,true,false);beepOk();addLog(uid.c_str(),'R');}
  else {showScreen("NON AUTORIZZATO",uid,RED);setRgb(true,false,false);beepDenied();}
  rfid.PICC_HaltA(); rfid.PCD_StopCrypto1(); delay(1000); showReady();
}
void handleBle() {
  if(!bleStampWaiting) return; bleStampWaiting=false; blePayload.trim();
  int separator=blePayload.lastIndexOf('|');
  String name = separator >= 0 ? blePayload.substring(0,separator) : "";
  String pin = separator >= 0 ? blePayload.substring(separator+1) : "";
  name.trim(); pin.trim(); name=name.substring(0,23);
  if(name.isEmpty() || pin != blePin || !bleUserAllowed(name)) { Serial.println("[BLE] Timbratura rifiutata"); showScreen("BLE RIFIUTATO","Nome o codice",RED);setRgb(true,false,false);beepDenied();delay(1000);showReady();return; }
  Serial.printf("[BLE] Timbratura: %s\n",name.c_str()); showScreen("TIMBRATO BLE",name,GREEN);setRgb(false,true,false);beepOk();addLog(name.c_str(),'B');delay(1000);showReady();
}
String pageHtml() {
  String h = F("<!doctype html><html lang='it'><meta name='viewport' content='width=device-width,initial-scale=1'><style>body{font-family:Arial;background:#10202d;color:#fff;margin:24px;max-width:620px}input{box-sizing:border-box;width:100%;padding:12px;margin:6px 0 18px;border-radius:6px;border:0}button{background:#00bfa5;border:0;padding:13px 18px;border-radius:6px;font-weight:bold}small{color:#c7d5dd}</style><h1>Presenze BLE</h1><p>Configura le timbrature Bluetooth.</p><form method='POST' action='/save'><label>Nome visibile Bluetooth</label><input name='name' maxlength='20' value='");
  h += bleName; h += F("'><label>Codice di timbratura BLE</label><input name='pin' maxlength='16' value='"); h += blePin;
  h += F("'><label>Nomi autorizzati (separati da virgola)</label><input name='users' maxlength='180' value='"); h += bleUsers;
  h += F("'><small>Lascia vuoto l'elenco per accettare qualsiasi nome con il codice corretto. Dal client BLE invia: <b>Nome|Codice</b>, ad esempio <b>Mario Rossi|1234</b>.</small><p><button type='submit'>Salva e riavvia BLE</button></p></form><hr><small>Rete di configurazione: "); h += SETUP_AP_NAME; h += F(" &mdash; IP 192.168.4.1</small></html>"); return h;
}
void setupWeb() {
  WiFi.mode(WIFI_AP); WiFi.softAP(SETUP_AP_NAME, SETUP_AP_PASSWORD);
  webServer.on("/", HTTP_GET, [](){ webServer.send(200,"text/html; charset=utf-8",pageHtml()); });
  webServer.on("/save", HTTP_POST, [](){
    String name=webServer.arg("name"); String pin=webServer.arg("pin"); String users=webServer.arg("users"); name.trim();pin.trim();users.trim();
    if(name.isEmpty() || pin.isEmpty()){webServer.send(400,"text/plain; charset=utf-8","Nome BLE e codice sono obbligatori.");return;}
    preferences.putString("bleName",name.substring(0,20)); preferences.putString("blePin",pin.substring(0,16)); preferences.putString("bleUsers",users.substring(0,180));
    webServer.send(200,"text/html; charset=utf-8","<meta http-equiv='refresh' content='3;url=/'><h2>Salvato.</h2><p>Riavvio del Bluetooth in corso...</p>"); delay(500); ESP.restart();
  });
  webServer.begin(); Serial.printf("[WEB] Wi-Fi %s, apri http://%s\n",SETUP_AP_NAME,WiFi.softAPIP().toString().c_str());
}
void printLog() { Serial.println("--- LOG PRESENZE ---"); uint8_t first=(logCount<MAX_LOG_ENTRIES)?0:logHead; for(uint8_t i=0;i<logCount;i++){AttendanceEntry &e=attendanceLog[(first+i)%MAX_LOG_ENTRIES];Serial.printf("[%s] %s t=%lu ms\n",e.source=='B'?"BLE":"RFID",e.identity,e.millisAtStamp);} }
void setup() {
  Serial.begin(115200); preferences.begin("presenze",false); bleName=preferences.getString("bleName",bleName);blePin=preferences.getString("blePin",blePin);bleUsers=preferences.getString("bleUsers",bleUsers);
  pinMode(TFT_BL_PIN,OUTPUT);digitalWrite(TFT_BL_PIN,HIGH);pinMode(SPEAKER_PIN,OUTPUT);pinMode(RGB_RED_PIN,OUTPUT);pinMode(RGB_GREEN_PIN,OUTPUT);pinMode(RGB_BLUE_PIN,OUTPUT);
  display->begin();showReady(); SPI.begin(RFID_SCK_PIN,RFID_MISO_PIN,RFID_MOSI_PIN,RFID_CS_PIN);rfid.PCD_Init();rfid.PCD_DumpVersionToSerial(); setupWeb();setupBle();
  Serial.println("[SYS] Pronto. Seriale: L=log, C=cancella log.");
}
void loop() { webServer.handleClient(); if(Serial.available()){char c=(char)Serial.read();if(c=='L'||c=='l')printLog();if(c=='C'||c=='c'){logHead=0;logCount=0;Serial.println("[SYS] Log cancellato.");}} handleBle();handleRfid(); }
