Tiny Touchscreen DeskBuddy

// ============================================================
// DeskBuddy — Waveshare ESP32-C6-Touch-LCD-1.47
// Features: animated face, clock, date, weather, moon,
//           stock ticker, GitHub stats.  Touch swipe to
//           change pages; tilt via QMI8658 IMU animates eyes.
// ============================================================
#include <Arduino.h>
#include <Arduino_GFX_Library.h>
#include <ArduinoJson.h>
#include <HTTPClient.h>
#include <WiFi.h>
#include <WiFiClientSecure.h>
#include <Wire.h>
#include <math.h>
#include <string.h>
#include "secrets.h"  // local file: Wi-Fi name and password only

// Network data is fetched over HTTPS. Location is inferred from the public IP,
// so it is approximate; VPNs and mobile/corporate networks can report elsewhere.

// ── Pin definitions ────────────────────────────────────────
#define LCD_BL    23
#define LCD_DC    15
#define LCD_CS    14
#define LCD_SCK    1
#define LCD_MOSI   2
#define LCD_RST   22

#define TOUCH_SDA 18
#define TOUCH_SCL 19
#define TOUCH_RST 20
#define TOUCH_INT 21


struct AccelData {
  float accelX;
  float accelY;
  float accelZ;
  uint32_t timestamp;
};

struct GyroData {
  float gyroX;
  float gyroY;
  float gyroZ;
  uint32_t timestamp;
};

struct calData {
  bool valid;
  float accelBias[3];
  float gyroBias[3];
};

struct TouchPoint {
  uint16_t x;
  uint16_t y;
};

struct touch_data_t {
  uint8_t    count;
  TouchPoint coords[1];  // first active touch point used by this UI
};


// Forward declarations

// Forward declarations

// Forward declarations
void drawRates();
void drawGold();
void drawLocation();

bool httpsGet(const String &url, String &body);
bool fetchLocation();
bool fetchRates();
String htmlCellText(const String &html);
float firstPriceInCell(const String &cell);
float extractGoldTableRate(const String &html, const String &headingMarker);
bool fetchGoldRates();

void resetSharedI2CBus();
void bsp_touch_init(TwoWire *wire, uint8_t rstPin, uint8_t intPin, uint8_t rotation, uint16_t dispW, uint16_t dispH);
void bsp_touch_read();
uint16_t clampTouchCoord(int32_t value, uint16_t maxValue);
uint16_t scaleTouchAxis(uint16_t raw, uint16_t rawMin, uint16_t rawMax, uint16_t outMax);
bool bsp_touch_get_coordinates(uint16_t *outX, uint16_t *outY);
uint16_t rgb(uint8_t r, uint8_t g, uint8_t b);
float clampFloat(float v, float lo, float hi);
void lcdRegInit();
uint32_t compileTimeSeconds();
uint8_t compileMonthNumber();
int32_t daysFromCivil(int32_t y, uint8_t mo, uint8_t d);
void civilFromDays(int32_t z, int32_t *year, uint8_t *month, uint8_t *day);
int32_t compileDateDays();
String csvField(const String &row, uint8_t index);
void centeredText(const char *text, int y, uint8_t size);
void drawPageDots();
void drawWifiName();
void drawDateTimeStatus();
void drawFaceWidget(float tx, float ty);
void drawHeader(const char *title);
void switchApp(int8_t delta);
bool wifiConfigured();
bool ensureWifi();
void drawWeatherIcon(int cx, int cy, int code, bool isDay);
bool fetchWeather();
void drawEye(int cx, int cy, int w, int h, bool closed, int px, int py);
void drawMouth(int cx, int cy);
void drawFace(float tx, float ty);
void drawDigitSegment(int x, int y, int w, int h, int t, uint8_t seg);
void drawDigit(int x, int y, uint8_t digit);
void drawClock();
void drawDatePage();
void drawWeather();
void drawForecast();
void drawMoonDisc(int cx, int cy, int radius, float phase);
void drawMoon();
void triggerFaceTap();
void readSensors();
void readTouch();
void updateFaceTimers();
void updateAutoPage();
void updateNetworkPages();
void calibrateNeutral();

uint32_t lastI2CResetMs = 0;

void resetSharedI2CBus() {
  uint32_t now = millis();
  if (now - lastI2CResetMs < 250) return;
  lastI2CResetMs = now;
  Wire.end();
  delay(5);
  Wire.begin(TOUCH_SDA, TOUCH_SCL);
  // The touch controller is polled at Fast-mode I2C speed. Do not depend on
  // its INT edge: some board revisions leave that line high during a touch.
  Wire.setClock(400000);
}

#define IMU_ADDRESS 0x6B

class QMI8658Mini {
 public:
  int init(calData cal, uint8_t address = IMU_ADDRESS) {
    imuAddress = address;
    calibration = cal;
    if (read8(0x00) != 0x05) return -1;  // WHO_AM_I
    write8(0x60, 0xFF);                  // soft reset
    delay(100);
    write8(0x02, 0x40);                  // CTRL1: auto-increment
    setAccelRange(4);
    setGyroRange(512);
    write8(0x06, 0x03);                  // CTRL5: accel/gyro low-pass defaults
    write8(0x08, 0x03);                  // CTRL7: enable accel + gyro
    delay(100);
    return 0;
  }

  int setAccelRange(int range) {
    uint8_t config = 0x10;
    if (range == 2) { accelScale = 2.0f / 32768.0f; config = 0x00; }
    else if (range == 4) { accelScale = 4.0f / 32768.0f; config = 0x10; }
    else if (range == 8) { accelScale = 8.0f / 32768.0f; config = 0x20; }
    else if (range == 16) { accelScale = 16.0f / 32768.0f; config = 0x30; }
    else return -1;
    write8(0x08, 0x00);
    rmw8(0x03, 0x70, config);            // CTRL2 accel range bits
    write8(0x08, 0x03);
    return 0;
  }

  int setGyroRange(int range) {
    uint8_t config = 0x50;
    if (range == 128 || range == 125) { gyroScale = 128.0f / 32768.0f; config = 0x30; }
    else if (range == 256 || range == 250) { gyroScale = 256.0f / 32768.0f; config = 0x40; }
    else if (range == 512 || range == 500) { gyroScale = 512.0f / 32768.0f; config = 0x50; }
    else if (range == 1024 || range == 1000) { gyroScale = 1024.0f / 32768.0f; config = 0x60; }
    else if (range == 2048 || range == 2000) { gyroScale = 2048.0f / 32768.0f; config = 0x70; }
    else return -1;
    write8(0x08, 0x00);
    rmw8(0x04, 0x70, config);            // CTRL3 gyro range bits
    write8(0x08, 0x03);
    return 0;
  }

  void update() {
    uint8_t status = read8(0x2E);        // STATUS0: accel/gyro ready bits
    if ((status & 0x03) == 0) return;
    uint8_t raw[12] = {0};
    if (!readBytes(0x35, raw, sizeof(raw))) return;

    int16_t ax = (int16_t)((raw[1] << 8) | raw[0]);
    int16_t ay = (int16_t)((raw[3] << 8) | raw[2]);
    int16_t az = (int16_t)((raw[5] << 8) | raw[4]);
    int16_t gx = (int16_t)((raw[7] << 8) | raw[6]);
    int16_t gy = (int16_t)((raw[9] << 8) | raw[8]);
    int16_t gz = (int16_t)((raw[11] << 8) | raw[10]);
    uint32_t now = micros();

    accel.accelX = ax * accelScale - calibration.accelBias[0];
    accel.accelY = ay * accelScale - calibration.accelBias[1];
    accel.accelZ = az * accelScale - calibration.accelBias[2];
    accel.timestamp = now;
    gyro.gyroX = gx * gyroScale - calibration.gyroBias[0];
    gyro.gyroY = gy * gyroScale - calibration.gyroBias[1];
    gyro.gyroZ = gz * gyroScale - calibration.gyroBias[2];
    gyro.timestamp = now;
  }

  void getAccel(AccelData *out) { *out = accel; }
  void getGyro(GyroData *out) { *out = gyro; }

 private:
  uint8_t imuAddress = IMU_ADDRESS;
  float accelScale = 4.0f / 32768.0f;
  float gyroScale = 512.0f / 32768.0f;
  calData calibration = {0};
  AccelData accel = {0};
  GyroData gyro = {0};

  uint8_t read8(uint8_t reg) {
    uint8_t value = 0;
    readBytes(reg, &value, 1);
    return value;
  }

  bool readBytes(uint8_t reg, uint8_t *buffer, uint8_t len) {
    Wire.beginTransmission(imuAddress);
    Wire.write(reg);
    if (Wire.endTransmission(true) != 0) { resetSharedI2CBus(); return false; }
    delayMicroseconds(300);
    if (Wire.requestFrom((uint8_t)imuAddress, len, (uint8_t)true) != len) {
      resetSharedI2CBus();
      return false;
    }
    for (uint8_t i = 0; i < len; i++) buffer[i] = Wire.read();
    return true;
  }

  void write8(uint8_t reg, uint8_t value) {
    Wire.beginTransmission(imuAddress);
    Wire.write(reg);
    Wire.write(value);
    Wire.endTransmission();
  }

  void rmw8(uint8_t reg, uint8_t mask, uint8_t value) {
    uint8_t current = read8(reg);
    write8(reg, (current & ~mask) | (value & mask));
  }
};

// ── AXS5106L inline touch reader ──────────────────────────
// The AXS5106L is the capacitive touch controller on the
// Waveshare ESP32-C6-Touch-LCD-1.47. ESP-IDF components exist,
// but this Arduino starter inlines a small polling reader so it
// does not need the ESP-IDF/LVGL touch stack.
// Protocol: I2C @ 400 kHz, 7-bit device address 0x63.
// Touch packets are read from register 0x01. The packet starts
// with gesture_id, touch_count, then point data. This sketch uses
// the first active point for tap/swipe navigation.

#define AXS5106L_ADDR 0x63
#define AXS5106L_TOUCH_DATA_REG 0x01





static TwoWire *_touchWire = nullptr;
static uint8_t  _touchRst  = 255;
static uint8_t  _touchInt  = 255;
static uint16_t _touchW    = 320;
static uint16_t _touchH    = 172;
static uint8_t  _touchRot  = 0;

void bsp_touch_init(TwoWire *wire, uint8_t rstPin, uint8_t intPin,
                    uint8_t rotation, uint16_t dispW, uint16_t dispH) {
  _touchWire = wire;
  _touchRst  = rstPin;
  _touchInt  = intPin;
  _touchRot  = rotation;
  _touchW    = dispW;
  _touchH    = dispH;

  if (_touchRst != 255) {
    pinMode(_touchRst, OUTPUT);
    digitalWrite(_touchRst, LOW);
    delay(20);
    digitalWrite(_touchRst, HIGH);
    delay(50);
  }
  if (_touchInt != 255) {
    pinMode(_touchInt, INPUT_PULLUP);
  }
}

// bsp_touch_read — no-op for polling mode; INT pin can be
// checked externally if needed.
void bsp_touch_read() {}

uint16_t clampTouchCoord(int32_t value, uint16_t maxValue) {
  if (value < 0) return 0;
  if (value >= maxValue) return maxValue - 1;
  return (uint16_t)value;
}

uint16_t scaleTouchAxis(uint16_t raw, uint16_t rawMin, uint16_t rawMax, uint16_t outMax) {
  if (rawMax <= rawMin || outMax == 0) return 0;
  if (raw <= rawMin) return 0;
  if (raw >= rawMax) return outMax - 1;
  return (uint32_t)(raw - rawMin) * (outMax - 1) / (rawMax - rawMin);
}

// Returns true if at least one touch point is active.
bool bsp_touch_get_coordinates(uint16_t *outX, uint16_t *outY) {
  if (!_touchWire || !outX || !outY) return false;

  // Read only the first 6-byte touch frame. The UI only uses one point, and
  // shorter reads are less flaky than asking this controller for the optional
  // second-point bytes on every frame.
  _touchWire->beginTransmission(AXS5106L_ADDR);
  _touchWire->write(AXS5106L_TOUCH_DATA_REG);
  if (_touchWire->endTransmission(true) != 0) { resetSharedI2CBus(); return false; }
  delayMicroseconds(300);

  uint8_t len = _touchWire->requestFrom((uint8_t)AXS5106L_ADDR, (uint8_t)6, (uint8_t)true);
  if (len < 6) { resetSharedI2CBus(); return false; }

  uint8_t buf[6];
  for (uint8_t i = 0; i < 6; i++) buf[i] = _touchWire->read();

  uint8_t nPoints = buf[1] & 0x0F;
  if (nPoints == 0 || nPoints > 2) return false;

  // First point begins at byte 2: x_hi/event, x_lo, y_hi/id, y_lo.
  uint16_t rawX = ((uint16_t)(buf[2] & 0x0F) << 8) | buf[3];
  uint16_t rawY = ((uint16_t)(buf[4] & 0x0F) << 8) | buf[5];
  if ((rawX == 0x0FFF && rawY == 0x0FFF) || rawX > 4090 || rawY > 4090) return false;

  // Small edge dead-zone compensation. The controller reports raw axes with a
  // few pixels of slack at the extremes; scaling them to the active screen area
  // makes edge swipes less sticky while preserving the current orientation.
  const uint16_t edge = 3;
  uint16_t mappedX = rawX;
  uint16_t mappedY = rawY;
  switch (_touchRot) {
    case 1:  // landscape, default for this board
      mappedX = scaleTouchAxis(rawY, edge, _touchW > edge ? _touchW - 1 - edge : _touchW - 1, _touchW);
      mappedY = scaleTouchAxis(rawX, edge, _touchH > edge ? _touchH - 1 - edge : _touchH - 1, _touchH);
      break;
    case 2:
      mappedX = _touchW - 1 - scaleTouchAxis(rawX, edge, _touchW > edge ? _touchW - 1 - edge : _touchW - 1, _touchW);
      mappedY = _touchH - 1 - scaleTouchAxis(rawY, edge, _touchH > edge ? _touchH - 1 - edge : _touchH - 1, _touchH);
      break;
    case 3:
      mappedX = _touchW - 1 - scaleTouchAxis(rawY, edge, _touchW > edge ? _touchW - 1 - edge : _touchW - 1, _touchW);
      mappedY = scaleTouchAxis(rawX, edge, _touchH > edge ? _touchH - 1 - edge : _touchH - 1, _touchH);
      break;
    default:  // 0 — portrait
      mappedX = scaleTouchAxis(rawX, edge, _touchW > edge ? _touchW - 1 - edge : _touchW - 1, _touchW);
      mappedY = scaleTouchAxis(rawY, edge, _touchH > edge ? _touchH - 1 - edge : _touchH - 1, _touchH);
      break;
  }
  *outX = clampTouchCoord(mappedX, _touchW);
  *outY = clampTouchCoord(mappedY, _touchH);
  return true;
}
// ── End AXS5106L driver ────────────────────────────────────

static const int SCREEN_W         = 320;
static const int SCREEN_H         = 172;
static const uint8_t APP_COUNT    = 7;
static const uint8_t FACE_MOOD_COUNT = 5;
static const uint32_t PAGE_AUTO_INTERVAL_MS = 8000;
static const uint16_t FG = RGB565_WHITE;
static const uint16_t BG = RGB565_BLACK;
static const uint8_t ROTATION = 1;

Arduino_DataBus *bus     = new Arduino_HWSPI(LCD_DC, LCD_CS, LCD_SCK, LCD_MOSI);
Arduino_GFX    *display  = new Arduino_ST7789(bus, LCD_RST, 0, false, 172, 320, 34, 0, 34, 0);
Arduino_Canvas *gfx      = new Arduino_Canvas(SCREEN_W, SCREEN_H, display);

QMI8658Mini imu;
calData calib = {0};
AccelData accel;
GyroData gyro;

bool     imuReady        = false;
bool     touchReady      = false;
bool     touchWasDown    = false;
bool     wifiAttempted   = false;
bool     weatherValid    = false;
bool     ratesValid      = false;
bool     goldIndiaValid  = false;
bool     goldUaeValid    = false;
bool     locationValid   = false;
uint8_t  currentApp      = 0;
uint8_t  faceMood        = 0;
uint16_t touchStartX     = 0;
uint16_t touchStartY     = 0;
uint16_t touchLastX      = 0;
uint16_t touchLastY      = 0;
uint32_t touchStartMs    = 0;
uint8_t  touchMissFrames  = 0;
bool     touchMoved       = false;
uint32_t nextBlink       = 1400;
uint32_t blinkUntil      = 0;
uint32_t nextGlance      = 900;
uint32_t nextAutoPage    = PAGE_AUTO_INTERVAL_MS;
uint32_t lastSerialMs    = 0;
uint32_t clockStartMillis   = 0;
uint32_t clockStartSeconds  = 0;
uint32_t weatherUpdatedAt   = 0;
uint32_t ratesUpdatedAt     = 0;
uint32_t goldUpdatedAt      = 0;
uint32_t locationUpdatedAt  = 0;
float restAx    = 0.0f;
float restAy    = 0.0f;
float filteredAx = 0.0f;
float filteredAy = 0.0f;
float filteredGz = 0.0f;
float faceGlanceX  = 0.0f;
float faceGlanceY  = 0.0f;
float faceTargetX  = 0.0f;
float faceTargetY  = 0.0f;
float pressPulse   = 0.0f;
int   weatherTempC    = 0;
int   weatherHumidity = 0;
int   weatherWindKmh  = 0;
int   forecastHighC[7] = {0};
int   forecastLowC[7] = {0};
int   forecastCode[7] = {-1,-1,-1,-1,-1,-1,-1};
int   forecastRainChance[7] = {0};
String forecastDate[7];
bool  forecastValid = false;
int   weatherCode     = -1;
bool  weatherIsDay    = true;
String weatherLabel   = "WAITING";
float usdInr = 0.0f;
float aedInr = 0.0f;
float goldIndia24k = 0.0f; // INR per gram
float goldUae24k = 0.0f;   // AED per gram
float latitude = 0.0f;
float longitude = 0.0f;
String locationCity = "LOCATING";
String locationCountry = "";
String localDateText = "";
String localTimeText = "";
uint8_t localHourSeed = 0;
uint8_t localMinuteSeed = 0;
uint32_t localTimeSeedMs = 0;

// ── Helpers ────────────────────────────────────────────────

uint16_t rgb(uint8_t r, uint8_t g, uint8_t b) {
  return ((r & 0xF8) << 8) | ((g & 0xFC) << 3) | (b >> 3);
}

float clampFloat(float v, float lo, float hi) {
  return v < lo ? lo : v > hi ? hi : v;
}

// ── LCD init sequence for the AXS15231B panel ─────────────

void lcdRegInit() {
  static const uint8_t ops[] = {
      BEGIN_WRITE,
      WRITE_COMMAND_8, 0x11,
      END_WRITE,
      DELAY, 120,
      BEGIN_WRITE,
      WRITE_C8_D16, 0xDF, 0x98, 0x53,
      WRITE_C8_D8,  0xB2, 0x23,
      WRITE_COMMAND_8, 0xB7,
      WRITE_BYTES, 4, 0x00, 0x47, 0x00, 0x6F,
      WRITE_COMMAND_8, 0xBB,
      WRITE_BYTES, 6, 0x1C, 0x1A, 0x55, 0x73, 0x63, 0xF0,
      WRITE_C8_D16, 0xC0, 0x44, 0xA4,
      WRITE_C8_D8,  0xC1, 0x16,
      WRITE_COMMAND_8, 0xC3,
      WRITE_BYTES, 8, 0x7D, 0x07, 0x14, 0x06, 0xCF, 0x71, 0x72, 0x77,
      WRITE_COMMAND_8, 0xC4,
      WRITE_BYTES, 12, 0x00, 0x00, 0xA0, 0x79, 0x0B, 0x0A, 0x16, 0x79, 0x0B, 0x0A, 0x16, 0x82,
      WRITE_COMMAND_8, 0xC8,
      WRITE_BYTES, 32,
      0x3F, 0x32, 0x29, 0x29, 0x27, 0x2B, 0x27, 0x28, 0x28, 0x26, 0x25, 0x17, 0x12, 0x0D, 0x04, 0x00,
      0x3F, 0x32, 0x29, 0x29, 0x27, 0x2B, 0x27, 0x28, 0x28, 0x26, 0x25, 0x17, 0x12, 0x0D, 0x04, 0x00,
      WRITE_COMMAND_8, 0xD0,
      WRITE_BYTES, 5, 0x04, 0x06, 0x6B, 0x0F, 0x00,
      WRITE_C8_D16, 0xD7, 0x00, 0x30,
      WRITE_C8_D8,  0xE6, 0x14,
      WRITE_C8_D8,  0xDE, 0x01,
      WRITE_COMMAND_8, 0xB7,
      WRITE_BYTES, 5, 0x03, 0x13, 0xEF, 0x35, 0x35,
      WRITE_COMMAND_8, 0xC1,
      WRITE_BYTES, 3, 0x14, 0x15, 0xC0,
      WRITE_C8_D16, 0xC2, 0x06, 0x3A,
      WRITE_C8_D16, 0xC4, 0x72, 0x12,
      WRITE_C8_D8,  0xBE, 0x00,
      WRITE_C8_D8,  0xDE, 0x02,
      WRITE_COMMAND_8, 0xE5,
      WRITE_BYTES, 3, 0x00, 0x02, 0x00,
      WRITE_COMMAND_8, 0xE5,
      WRITE_BYTES, 3, 0x01, 0x02, 0x00,
      WRITE_C8_D8, 0xDE, 0x00,
      WRITE_C8_D8, 0x35, 0x00,
      WRITE_C8_D8, 0x3A, 0x05,
      WRITE_COMMAND_8, 0x2A,
      WRITE_BYTES, 4, 0x00, 0x22, 0x00, 0xCD,
      WRITE_COMMAND_8, 0x2B,
      WRITE_BYTES, 4, 0x00, 0x00, 0x01, 0x3F,
      WRITE_C8_D8, 0xDE, 0x02,
      WRITE_COMMAND_8, 0xE5,
      WRITE_BYTES, 3, 0x00, 0x02, 0x00,
      WRITE_C8_D8, 0xDE, 0x00,
      WRITE_C8_D8, 0x36, 0x00,
      WRITE_COMMAND_8, 0x21,
      END_WRITE,
      DELAY, 10,
      BEGIN_WRITE,
      WRITE_COMMAND_8, 0x29,
      END_WRITE};
  bus->batchOperation(ops, sizeof(ops));
}

// ── Compile-time clock seed ────────────────────────────────

uint32_t compileTimeSeconds() {
  const char *t = __TIME__;
  uint8_t hh = (t[0]-'0')*10 + (t[1]-'0');
  uint8_t mm = (t[3]-'0')*10 + (t[4]-'0');
  uint8_t ss = (t[6]-'0')*10 + (t[7]-'0');
  return (uint32_t)hh*3600UL + (uint32_t)mm*60UL + ss;
}

uint8_t compileMonthNumber() {
  const char *m = __DATE__;
  static const char names[] = "JanFebMarAprMayJunJulAugSepOctNovDec";
  for (uint8_t i = 0; i < 12; i++)
    if (strncmp(m, names+i*3, 3) == 0) return i+1;
  return 1;
}

int32_t daysFromCivil(int32_t y, uint8_t mo, uint8_t d) {
  y -= mo <= 2;
  const int32_t era = (y >= 0 ? y : y-399)/400;
  const uint32_t yoe = (uint32_t)(y - era*400);
  const uint32_t doy = (153*(mo+(mo>2?-3:9))+2)/5 + d - 1;
  const uint32_t doe = yoe*365 + yoe/4 - yoe/100 + doy;
  return era*146097 + (int32_t)doe - 719468;
}

void civilFromDays(int32_t z, int32_t *year, uint8_t *month, uint8_t *day) {
  z += 719468;
  const int32_t era = (z >= 0 ? z : z-146096)/146097;
  const uint32_t doe = (uint32_t)(z - era*146097);
  const uint32_t yoe = (doe - doe/1460 + doe/36524 - doe/146096)/365;
  int32_t y = (int32_t)yoe + era*400;
  const uint32_t doy = doe - (365*yoe + yoe/4 - yoe/100);
  const uint32_t mp  = (5*doy+2)/153;
  const uint32_t d   = doy - (153*mp+2)/5 + 1;
  const uint32_t mo  = mp + (mp < 10 ? 3 : -9);
  y += mo <= 2;
  *year  = y;
  *month = (uint8_t)mo;
  *day   = (uint8_t)d;
}

int32_t compileDateDays() {
  const char *d = __DATE__;
  uint8_t day = (d[4]==' ' ? 0 : d[4]-'0')*10 + (d[5]-'0');
  int32_t y = (int32_t)(d[7]-'0')*1000 + (int32_t)(d[8]-'0')*100 +
              (int32_t)(d[9]-'0')*10   + (d[10]-'0');
  return daysFromCivil(y, compileMonthNumber(), day);
}

// ── CSV helper ────────────────────────────────────────────

String csvField(const String &row, uint8_t index) {
  int start = 0;
  for (uint8_t i = 0; i < index; i++) {
    start = row.indexOf(',', start);
    if (start < 0) return "";
    start++;
  }
  int end = row.indexOf(',', start);
  if (end < 0) end = row.length();
  String v = row.substring(start, end);
  v.trim();
  return v;
}

// ── Drawing primitives ────────────────────────────────────

void centeredText(const char *text, int y, uint8_t size) {
  gfx->setTextSize(size);
  gfx->setTextColor(FG);
  int width = (int)strlen(text)*6*size;
  gfx->setCursor((SCREEN_W-width)/2, y);
  gfx->print(text);
}

void drawPageDots() {
  static const uint16_t colors[] = {rgb(255,105,180), rgb(255,190,40), rgb(70,220,255), rgb(120,240,150), rgb(185,135,255), rgb(255,150,70), rgb(80,170,255)};
  int startX = SCREEN_W/2 - ((APP_COUNT-1)*16)/2;
  for (uint8_t i = 0; i < APP_COUNT; i++) {
    if (i == currentApp) gfx->fillCircle(startX+i*16, SCREEN_H-6, 3, colors[i]);
    else gfx->drawCircle(startX+i*16, SCREEN_H-6, 2, rgb(70,70,90));
  }
}

void drawWifiName() {
  gfx->setTextSize(1);
  if (WiFi.status() == WL_CONNECTED) {
    gfx->setTextColor(rgb(120, 240, 150));
    String name = WiFi.SSID();
    if (name.length() == 0) name = WIFI_SSID;
    if (name.length() > 18) name = name.substring(0, 17) + ".";
    int width = name.length() * 6;
    gfx->setCursor(SCREEN_W - width - 8, 7);
    gfx->print(name);
  } else {
    gfx->setTextColor(rgb(255, 150, 70));
    const char *status = wifiConfigured() ? "WIFI..." : "NO WIFI";
    gfx->setCursor(SCREEN_W - strlen(status) * 6 - 8, 7);
    gfx->print(status);
  }
}

void drawDateTimeStatus() {
  gfx->setTextSize(1);
  gfx->setTextColor(rgb(190, 190, 210));
  if (localDateText.length() >= 10 && localTimeSeedMs > 0) {
    uint32_t totalMinutes = localHourSeed * 60UL + localMinuteSeed +
                            (millis() - localTimeSeedMs) / 60000UL;
    uint8_t hour = (totalMinutes / 60UL) % 24UL;
    uint8_t minute = totalMinutes % 60UL;
    char status[18];
    snprintf(status, sizeof(status), "%s/%s %02u:%02u",
             localDateText.substring(8, 10).c_str(),
             localDateText.substring(5, 7).c_str(), hour, minute);
    gfx->setCursor(8, SCREEN_H - 22);
    gfx->print(status);
  } else {
    gfx->setCursor(8, SCREEN_H - 22);
    gfx->print("TIME SYNCING");
  }
}

// Small always-visible DeskBuddy face. A layered yellow circle, warm lower-right
// shadow, and upper-left highlight give it a cheerful 3D smiley appearance.
// Blink, mood, glance, and IMU-driven gaze remain shared with the main face page.
void drawFaceWidget(float tx, float ty) {
  const int cx = 177, cy = 10;
  uint32_t now = millis();
  bool closed = now < blinkUntil || faceMood == 3;
  int gazeX = (int)(tx * 2.0f + faceGlanceX * 0.12f);
  int gazeY = (int)(ty * 1.0f + faceGlanceY * 0.10f);
  uint16_t outline = rgb(176, 90, 0);
  uint16_t shadow = rgb(218, 132, 0);
  uint16_t yellow = rgb(255, 211, 36);
  uint16_t highlight = rgb(255, 246, 170);
  uint16_t feature = rgb(82, 52, 24);

  // The outline and offset shadow make the circular face legible over every header.
  gfx->fillCircle(cx, cy + 1, 11, outline);
  gfx->fillCircle(cx + 1, cy + 2, 10, shadow);
  gfx->fillCircle(cx - 1, cy - 1, 10, yellow);
  gfx->fillCircle(cx - 4, cy - 5, 3, highlight);
  gfx->drawCircle(cx - 1, cy - 1, 10, rgb(255, 183, 0));

  if (closed) {
    gfx->drawLine(cx - 8, cy - 1, cx - 3, cy, feature);
    gfx->drawLine(cx + 3, cy, cx + 8, cy - 1, feature);
  } else {
    gfx->fillCircle(cx - 6 + gazeX, cy - 1 + gazeY, 2, feature);
    gfx->fillCircle(cx + 6 + gazeX, cy - 1 + gazeY, 2, feature);
    gfx->drawPixel(cx - 7 + gazeX, cy - 2 + gazeY, RGB565_WHITE);
    gfx->drawPixel(cx + 5 + gazeX, cy - 2 + gazeY, RGB565_WHITE);
  }

  if (faceMood == 4) {
    // Playful diagonal mouth.
    gfx->drawLine(cx - 6, cy + 6, cx + 6, cy + 3, feature);
    gfx->drawLine(cx - 5, cy + 7, cx + 6, cy + 4, feature);
  } else if (faceMood == 2) {
    // Surprised mouth.
    gfx->fillCircle(cx, cy + 5, 3, feature);
    gfx->fillCircle(cx, cy + 4, 1, rgb(255, 211, 36));
  } else if (faceMood == 3) {
    gfx->drawLine(cx - 5, cy + 6, cx + 5, cy + 6, feature);
  } else {
    // Warm, thick smile curve.
    gfx->drawLine(cx - 6, cy + 4, cx - 3, cy + 7, feature);
    gfx->drawLine(cx - 3, cy + 7, cx, cy + 8, feature);
    gfx->drawLine(cx, cy + 8, cx + 3, cy + 7, feature);
    gfx->drawLine(cx + 3, cy + 7, cx + 6, cy + 4, feature);
  }
}

void drawHeader(const char *title) {
  gfx->fillScreen(BG);
  gfx->drawLine(0, 20, SCREEN_W, 20, rgb(70,220,255));
  gfx->setTextSize(1);
  gfx->setTextColor(rgb(70,220,255));
  gfx->setCursor(8, 7);
  gfx->print(title);
  float tx = imuReady ? clampFloat(-(filteredAy-restAy)*2.2f, -1.0f, 1.0f) : sin(millis()*0.0014f)*0.25f;
  float ty = imuReady ? clampFloat( (filteredAx-restAx)*2.2f, -1.0f, 1.0f) : cos(millis()*0.0011f)*0.16f;
  drawFaceWidget(tx, ty);
  drawWifiName();
  drawDateTimeStatus();
}

// ── App navigation ────────────────────────────────────────

void switchApp(int8_t delta) {
  currentApp = (currentApp + APP_COUNT + delta) % APP_COUNT;
  pressPulse = 1.0f;
  nextAutoPage = millis() + PAGE_AUTO_INTERVAL_MS;
}

// ── Wi-Fi ─────────────────────────────────────────────────

bool wifiConfigured() {
  return strlen(WIFI_SSID) > 0 && strcmp(WIFI_SSID, "YOUR_WIFI_NAME") != 0;
}

bool ensureWifi() {
  if (WiFi.status() == WL_CONNECTED) return true;
  if (!wifiConfigured() || wifiAttempted) return false;
  wifiAttempted = true;
  WiFi.mode(WIFI_STA);
  WiFi.begin(WIFI_SSID, WIFI_PASSWORD);
  uint32_t start = millis();
  while (WiFi.status() != WL_CONNECTED && millis()-start < 9000UL) delay(120);
  return WiFi.status() == WL_CONNECTED;
}

bool httpsGet(const String &url, String &body) {
  WiFiClientSecure client;
  client.setInsecure(); // HTTPS encryption; no root bundle is embedded in this small firmware.
  HTTPClient http;
  http.setTimeout(9000);
  if (!http.begin(client, url)) return false;
  http.addHeader("User-Agent", "DeskBuddy-ESP32C6/1.0");
  int status = http.GET();
  if (status != HTTP_CODE_OK) { http.end(); return false; }
  body = http.getString();
  http.end();
  return body.length() > 0;
}

bool fetchLocation() {
  if (!ensureWifi()) return false;
  String body;
  if (!httpsGet("https://ipwho.is/", body)) return false;
  JsonDocument doc;
  if (deserializeJson(doc, body) || !doc["success"].as<bool>()) return false;
  float lat = doc["latitude"].as<float>();
  float lon = doc["longitude"].as<float>();
  if (isnan(lat) || isnan(lon) || (lat == 0.0f && lon == 0.0f)) return false;
  latitude = lat; longitude = lon;
  locationCity = doc["city"].as<String>();
  locationCountry = doc["country_code"].as<String>();
  locationValid = locationCity.length() > 0;
  locationUpdatedAt = millis();
  return locationValid;
}

// ── Weather fetch (Open-Meteo, NYC default) ───────────────

const char *weatherCodeText(int code) {
  if (code == 0)                             return "CLEAR";
  if (code == 1 || code == 2)               return "PARTLY CLOUDY";
  if (code == 3)                             return "CLOUDY";
  if (code == 45 || code == 48)             return "FOG";
  if ((code>=51&&code<=67)||(code>=80&&code<=82)) return "RAIN";
  if (code >= 71 && code <= 77)             return "SNOW";
  if (code >= 95)                            return "STORM";
  return "WEATHER";
}

void drawWeatherIcon(int cx, int cy, int code, bool isDay) {
  uint16_t iconColor = (code == 0 || code == 1) ? rgb(255, 190, 40) : ((code >= 51 && code <= 82) ? rgb(70, 160, 255) : rgb(220, 210, 255));
  if (code == 0) {
    gfx->drawCircle(cx, cy, 22, iconColor);
    for (uint8_t i = 0; i < 8; i++) {
      float a = i*0.7854f;
      gfx->drawLine(cx+(int)(cos(a)*30), cy+(int)(sin(a)*30),
                    cx+(int)(cos(a)*40), cy+(int)(sin(a)*40), iconColor);
    }
    if (!isDay) gfx->fillCircle(cx+11, cy-8, 18, BG);
    return;
  }
  gfx->fillCircle(cx-19, cy+5, 19, iconColor);
  gfx->fillCircle(cx+2,  cy-6, 25, iconColor);
  gfx->fillCircle(cx+27, cy+8, 17, iconColor);
  gfx->fillRoundRect(cx-42, cy+8, 87, 25, 12, iconColor);
  if ((code>=51&&code<=67)||(code>=80&&code<=82)) {
    for (int x=-25; x<=25; x+=17) {
      gfx->drawLine(cx+x, cy+45, cx+x-8, cy+62, FG);
      gfx->drawLine(cx+x+1, cy+45, cx+x-7, cy+62, FG);
    }
  } else if (code>=71 && code<=77) {
    for (int x=-24; x<=24; x+=24) {
      gfx->drawLine(cx+x-6, cy+53, cx+x+6, cy+53, FG);
      gfx->drawLine(cx+x, cy+47, cx+x, cy+59, FG);
      gfx->drawLine(cx+x-5, cy+48, cx+x+5, cy+58, FG);
      gfx->drawLine(cx+x+5, cy+48, cx+x-5, cy+58, FG);
    }
  }
}

bool fetchWeather() {
  if (!locationValid && !fetchLocation()) return false;
  String url = String("https://api.open-meteo.com/v1/forecast?latitude=") + String(latitude, 4) +
    "&longitude=" + String(longitude, 4) +
    "&current=temperature_2m,relative_humidity_2m,weather_code,wind_speed_10m,is_day&daily=weather_code,temperature_2m_max,temperature_2m_min,precipitation_probability_max&forecast_days=7&timezone=auto";
  String body;
  if (!httpsGet(url, body)) return false;
  JsonDocument doc;
  if (deserializeJson(doc, body)) return false;
  weatherTempC = (int)round(doc["current"]["temperature_2m"].as<float>());
  weatherHumidity = doc["current"]["relative_humidity_2m"].as<int>();
  weatherWindKmh = (int)round(doc["current"]["wind_speed_10m"].as<float>());
  weatherCode = doc["current"]["weather_code"].as<int>();
  weatherIsDay = doc["current"]["is_day"].as<int>() != 0;
  weatherLabel = weatherCodeText(weatherCode);
  String stamp = doc["current"]["time"].as<String>(); // local due to timezone=auto
  if (stamp.length() >= 16) {
    localDateText = stamp.substring(0, 10); localTimeText = stamp.substring(11, 16);
    localHourSeed = stamp.substring(11, 13).toInt();
    localMinuteSeed = stamp.substring(14, 16).toInt();
    localTimeSeedMs = millis();
  }
  JsonArray days = doc["daily"]["time"].as<JsonArray>();
  JsonArray highs = doc["daily"]["temperature_2m_max"].as<JsonArray>();
  JsonArray lows = doc["daily"]["temperature_2m_min"].as<JsonArray>();
  JsonArray codes = doc["daily"]["weather_code"].as<JsonArray>();
  JsonArray rain = doc["daily"]["precipitation_probability_max"].as<JsonArray>();
  forecastValid = days.size() >= 7 && highs.size() >= 7 && lows.size() >= 7 && codes.size() >= 7;
  if (forecastValid) {
    for (uint8_t i = 0; i < 7; i++) {
      forecastDate[i] = days[i].as<String>();
      forecastHighC[i] = (int)round(highs[i].as<float>());
      forecastLowC[i] = (int)round(lows[i].as<float>());
      forecastCode[i] = codes[i].as<int>();
      forecastRainChance[i] = rain.size() > i ? rain[i].as<int>() : 0;
    }
  }
  weatherUpdatedAt = millis(); weatherValid = true;
  return true;
}

// ── Stock fetch (stooq CSV, AAPL) ────────────────────────

bool fetchRates() {
  if (!ensureWifi()) return false;
  String body;
  if (!httpsGet("https://open.er-api.com/v6/latest/USD", body)) return false;
  JsonDocument doc;
  if (deserializeJson(doc, body) || doc["result"].as<String>() != "success") return false;
  float inrPerUsd = doc["rates"]["INR"].as<float>();
  float aedPerUsd = doc["rates"]["AED"].as<float>();
  if (inrPerUsd <= 0.0f || aedPerUsd <= 0.0f) return false;
  usdInr = inrPerUsd;
  aedInr = inrPerUsd / aedPerUsd;
  ratesUpdatedAt = millis(); ratesValid = true;
  return true;
}

// Return visible text from one small HTML table cell. Goodreturns can add spans,
// currency entities, and change CSS classes, so the parser deliberately ignores tags.
String htmlCellText(const String &html) {
  String text;
  bool inTag = false;
  for (uint16_t i = 0; i < html.length(); i++) {
    char c = html[i];
    if (c == '<') { inTag = true; continue; }
    if (c == '>') { inTag = false; continue; }
    if (!inTag) text += c;
  }
  text.replace("&nbsp;", " ");
  text.replace("&#x20B9;", " ");
  text.replace("&#8377;", " ");
  text.trim();
  return text;
}

// Take the first price-like number in the cell. This intentionally ignores
// Goodreturns' optional change figure, such as "(+2.75)", after the price.
float firstPriceInCell(const String &cell) {
  String number;
  bool started = false;
  for (uint16_t i = 0; i < cell.length(); i++) {
    char c = cell[i];
    if ((c >= '0' && c <= '9') || c == '.' || c == ',') {
      number += c;
      started = true;
    } else if (started) {
      break;
    }
  }
  number.replace(",", "");
  return number.toFloat();
}

// Find the country-specific "per gram" table, then use its first data row:
// first cell = 1 gram, second cell = 24K. This avoids matching 10g, 22K,
// city tables, and the INR-converted table that appears lower on the UAE page.
float extractGoldTableRate(const String &html, const String &headingMarker) {
  int heading = html.indexOf(headingMarker);
  if (heading < 0) return 0.0f;
  int tableStart = html.indexOf("<table", heading);
  int tableEnd = tableStart < 0 ? -1 : html.indexOf("</table>", tableStart);
  if (tableStart < 0 || tableEnd < 0) return 0.0f;
  String table = html.substring(tableStart, tableEnd);
  if (table.indexOf("24K") < 0 || table.indexOf("22K") < 0 || table.indexOf("Gram") < 0) return 0.0f;

  int rowStart = table.indexOf("<tr");
  while (rowStart >= 0) {
    int rowEnd = table.indexOf("</tr>", rowStart);
    if (rowEnd < 0) break;
    String row = table.substring(rowStart, rowEnd);
    int cellStart = row.indexOf("<td");
    if (cellStart >= 0) {
      int firstOpenEnd = row.indexOf('>', cellStart);
      int firstClose = firstOpenEnd < 0 ? -1 : row.indexOf("</td>", firstOpenEnd);
      if (firstClose >= 0 && htmlCellText(row.substring(firstOpenEnd + 1, firstClose)) == "1") {
        int secondStart = row.indexOf("<td", firstClose + 5);
        int secondOpenEnd = secondStart < 0 ? -1 : row.indexOf('>', secondStart);
        int secondClose = secondOpenEnd < 0 ? -1 : row.indexOf("</td>", secondOpenEnd);
        if (secondClose >= 0) return firstPriceInCell(row.substring(secondOpenEnd + 1, secondClose));
      }
    }
    rowStart = table.indexOf("<tr", rowEnd + 5);
  }
  return 0.0f;
}

bool fetchGoldRates() {
  if (!ensureWifi()) { Serial.println("Gold: Wi-Fi unavailable"); return false; }

  // XAUS supplies 24K/pure-gold indicative spot prices directly in the requested
  // currency and unit. This replaces the Goodreturns HTML scraper, whose layout
  // and bot protection can make an embedded-device request fail.
  String india, uae;
  if (!httpsGet("https://xaus.com/api/v1/spot?currency=INR&unit=gram&compact=1", india)) {
    Serial.println("Gold: INR spot request failed"); return false;
  }
  if (!httpsGet("https://xaus.com/api/v1/spot?currency=AED&unit=gram&compact=1", uae)) {
    Serial.println("Gold: AED spot request failed"); return false;
  }

  JsonDocument inrDoc, aedDoc;
  if (deserializeJson(inrDoc, india) || deserializeJson(aedDoc, uae)) {
    Serial.println("Gold: spot JSON parse failed"); return false;
  }
  String inrCurrency = inrDoc["xau"]["currency"].as<String>();
  String aedCurrency = aedDoc["xau"]["currency"].as<String>();
  String inrUnit = inrDoc["xau"]["unit"].as<String>();
  String aedUnit = aedDoc["xau"]["unit"].as<String>();
  float inr = inrDoc["xau"]["price"].as<float>();
  float aed = aedDoc["xau"]["price"].as<float>();
  if (inr <= 0.0f || aed <= 0.0f || inrCurrency != "INR" || aedCurrency != "AED" ||
      inrUnit != "gram" || aedUnit != "gram") {
    Serial.println("Gold: invalid spot response"); return false;
  }

  goldIndia24k = inr; goldUae24k = aed;
  goldIndiaValid = goldUaeValid = true; goldUpdatedAt = millis();
  Serial.print("Gold spot updated: India INR "); Serial.print(inr, 2);
  Serial.print("/g, UAE AED "); Serial.println(aed, 2);
  return true;
}


// ── Face rendering ────────────────────────────────────────

void drawEye(int cx, int cy, int w, int h, bool closed, int px, int py) {
  if (closed) {
    gfx->fillRoundRect(cx-w/2, cy-3, w, 6, 3, FG);
    return;
  }
  gfx->fillRoundRect(cx-w/2, cy-h/2, w, h, h/2, FG);
  gfx->fillRoundRect(cx-7+px, cy-9+py, 14, 18, 7, BG);
}

void drawMouth(int cx, int cy) {
  if (faceMood == 2) {
    gfx->fillEllipse(cx, cy+2, 15, 21, FG);
    gfx->fillEllipse(cx, cy+2, 7, 11, BG);
  } else if (faceMood == 3) {
    gfx->fillRoundRect(cx-38, cy, 76, 6, 3, FG);
  } else if (faceMood == 4) {
    gfx->drawLine(cx-28, cy+8, cx+28, cy-8, FG);
    gfx->drawLine(cx-28, cy+9, cx+28, cy-7, FG);
  } else {
    int radius = (faceMood == 1) ? 48 : 40;
    gfx->fillArc(cx, cy-16, radius, radius-5, 34.0f, 146.0f, FG);
  }
}

void drawFace(float tx, float ty) {
  uint32_t now = millis();
  drawHeader("FACE");
  float breathe = sin(now*0.0021f)*0.03f + pressPulse*0.08f;
  int dx   = (int)(tx*14.0f + faceGlanceX);
  int dy   = (int)(ty*8.0f  + faceGlanceY);
  int eyeW = 44 + (int)(breathe*28.0f);
  int eyeH = (faceMood==2) ? 45 : (faceMood==3) ? 16 : (62 + (int)(breathe*18.0f));
  bool blink = now < blinkUntil;

  for (int x=12; x<SCREEN_W-12; x+=18) {
    gfx->drawLine(x,   31, x+8,  31, FG);
    gfx->drawLine(x+4,144, x+12,144, FG);
  }
  drawEye(114+dx, 75+dy, eyeW, eyeH, blink||faceMood==3,           dx/4, dy/5);
  drawEye(206+dx, 75+dy, eyeW, eyeH, blink||faceMood==3||faceMood==4, dx/4, dy/5);
  drawMouth(160+dx/4, 116+dy/4);
  drawPageDots();
}

// ── 7-segment clock ───────────────────────────────────────

void drawDigitSegment(int x, int y, int w, int h, int t, uint8_t seg) {
  int half = h/2, r = t/2;
  switch (seg) {
    case 0: gfx->fillRoundRect(x+t, y, w-2*t, t, r, FG); break;
    case 1: gfx->fillRoundRect(x+w-t, y+t, t, half-t, r, FG); break;
    case 2: gfx->fillRoundRect(x+w-t, y+half, t, half-t, r, FG); break;
    case 3: gfx->fillRoundRect(x+t, y+h-t, w-2*t, t, r, FG); break;
    case 4: gfx->fillRoundRect(x, y+half, t, half-t, r, FG); break;
    case 5: gfx->fillRoundRect(x, y+t, t, half-t, r, FG); break;
    case 6: gfx->fillRoundRect(x+t, y+half-t/2, w-2*t, t, r, FG); break;
  }
}

void drawDigit(int x, int y, uint8_t digit) {
  static const uint8_t masks[10] = {
    0b00111111,0b00000110,0b01011011,0b01001111,0b01100110,
    0b01101101,0b01111101,0b00000111,0b01111111,0b01101111};
  for (uint8_t seg = 0; seg < 7; seg++)
    if (masks[digit%10] & (1<<seg)) drawDigitSegment(x, y, 42, 76, 8, seg);
}

void drawClock() {
  drawHeader("LOCAL TIME");
  if (!weatherValid || localTimeText.length() < 5) {
    centeredText(wifiConfigured() ? "SYNCING TIME" : "SET WIFI IN secrets.h", 72, 2);
    drawPageDots(); return;
  }
  uint32_t minutes = localHourSeed * 60UL + localMinuteSeed + (millis() - localTimeSeedMs) / 60000UL;
  uint8_t hh = (minutes / 60UL) % 24UL, mm = minutes % 60UL;
  char timeLine[6]; snprintf(timeLine, sizeof(timeLine), "%02u:%02u", hh, mm);
  gfx->setTextSize(7); gfx->setTextColor(FG);
  gfx->setCursor(48, 55); gfx->print(timeLine);
  gfx->setTextSize(2); gfx->setCursor(87, 128); gfx->print(localDateText);
  drawPageDots();
}

// ── Date page ─────────────────────────────────────────────

void drawDatePage() {
  static const char *wd[]  = {"SUNDAY","MONDAY","TUESDAY","WEDNESDAY","THURSDAY","FRIDAY","SATURDAY"};
  static const char *mon[] = {"JAN","FEB","MAR","APR","MAY","JUN","JUL","AUG","SEP","OCT","NOV","DEC"};
  uint32_t elapsedSec = (millis()-clockStartMillis)/1000UL;
  int32_t days = compileDateDays() + (int32_t)((clockStartSeconds+elapsedSec)/86400UL);
  int32_t year; uint8_t month, day;
  civilFromDays(days, &year, &month, &day);
  uint8_t weekday = (uint8_t)((days+4)%7);
  drawHeader("DATE");
  centeredText(wd[weekday], 35, 3);
  char line[24];
  snprintf(line, sizeof(line), "%s %02u", mon[month-1], day);
  centeredText(line, 82, 5);
  snprintf(line, sizeof(line), "%ld", (long)year);
  centeredText(line, 130, 2);
  drawPageDots();
}

// ── Weather page ──────────────────────────────────────────

void drawWeather() {
  drawHeader(locationValid ? locationCity.c_str() : "LOCAL WEATHER");
  if (!wifiConfigured()) {
    centeredText("NO WIFI CONFIG", 70, 2);
    centeredText("EDIT CONFIG", 102, 1);
    drawPageDots(); return;
  }
  if (WiFi.status() != WL_CONNECTED) {
    centeredText("CONNECTING", 75, 2);
    drawWeatherIcon(250, 82, 3, true);
    drawPageDots(); return;
  }
  if (!weatherValid) { centeredText("UPDATING", 76, 2); drawPageDots(); return; }
  drawWeatherIcon(241, 70, weatherCode, weatherIsDay);
  gfx->setTextSize(7); gfx->setTextColor(rgb(255, 190, 40));
  gfx->setCursor(20, 60); gfx->print(weatherTempC);
  gfx->setTextSize(3); gfx->print("C");
  gfx->setTextSize(1); gfx->setTextColor(rgb(120, 220, 255));
  gfx->setCursor(24,  136); gfx->print(weatherLabel);
  gfx->setCursor(146, 136); gfx->print("H "); gfx->print(weatherHumidity); gfx->print("%");
  gfx->setCursor(214, 136); gfx->print("W "); gfx->print(weatherWindKmh); gfx->print("KM/H");
  drawPageDots();
}

// ── Moon phase page ───────────────────────────────────────

const char *moonPhaseLabel(float phase) {
  if (phase<0.03f||phase>0.97f) return "NEW MOON";
  if (phase<0.22f)              return "WAXING CRESCENT";
  if (phase<0.28f)              return "FIRST QUARTER";
  if (phase<0.47f)              return "WAXING GIBBOUS";
  if (phase<0.53f)              return "FULL MOON";
  if (phase<0.72f)              return "WANING GIBBOUS";
  if (phase<0.78f)              return "LAST QUARTER";
  return "WANING CRESCENT";
}

void drawForecast() {
  drawHeader(locationValid ? "7 DAY FORECAST" : "WEEKLY FORECAST");
  if (!wifiConfigured()) { centeredText("SET WIFI IN secrets.h", 76, 2); drawPageDots(); return; }
  if (!forecastValid) { centeredText("UPDATING FORECAST", 76, 2); drawPageDots(); return; }
  static const char *weekDays[] = {"SUN","MON","TUE","WED","THU","FRI","SAT"};
  for (uint8_t i = 0; i < 7; i++) {
    int x = 4 + i * 45;
    int dayNum = 0;
    if (forecastDate[i].length() >= 10) {
      int y = forecastDate[i].substring(0,4).toInt();
      int m = forecastDate[i].substring(5,7).toInt();
      int d = forecastDate[i].substring(8,10).toInt();
      dayNum = (daysFromCivil(y, m, d) + 4) % 7;
      if (dayNum < 0) dayNum += 7;
    }
    gfx->setTextSize(1); gfx->setTextColor(rgb(120, 220, 255));
    gfx->setCursor(x + 5, 28); gfx->print(weekDays[dayNum]);
    int iconColor = (forecastCode[i] <= 2) ? rgb(255,190,40) : (forecastCode[i] >= 51 ? rgb(70,160,255) : rgb(210,190,255));
    gfx->fillCircle(x + 20, 56, 10, iconColor);
    if (forecastCode[i] >= 51) gfx->drawLine(x+16, 68, x+12, 76, rgb(70,160,255));
    gfx->setTextColor(rgb(255, 120, 90)); gfx->setCursor(x + 5, 84); gfx->print(forecastHighC[i]); gfx->print("C");
    gfx->setTextColor(rgb(120, 220, 255)); gfx->setCursor(x + 5, 101); gfx->print(forecastLowC[i]); gfx->print("C");
    gfx->setTextColor(rgb(100, 180, 255)); gfx->setCursor(x + 5, 122); gfx->print(forecastRainChance[i]); gfx->print("%");
  }
  gfx->setTextSize(1); gfx->setTextColor(rgb(150,150,150)); gfx->setCursor(63, 143); gfx->print("HIGH / LOW / RAIN CHANCE");
  drawPageDots();
}

void drawMoonDisc(int cx, int cy, int radius, float phase) {
  phase = phase - floor(phase);
  gfx->drawCircle(cx, cy, radius+3, rgb(72,72,72));
  gfx->fillCircle(cx, cy, radius, FG);
  if (phase<0.03f||phase>0.97f) {
    gfx->fillCircle(cx, cy, radius-2, BG);
    gfx->drawCircle(cx, cy, radius, FG);
    return;
  }
  if (phase>0.47f && phase<0.53f) return;
  int shadowX = (phase < 0.5f)
    ? cx - (int)(4.0f*radius*phase)
    : cx + (int)(2.0f*radius - 4.0f*radius*(phase-0.5f));
  gfx->fillCircle(shadowX, cy, radius, BG);
  gfx->drawCircle(cx, cy, radius, FG);
}

void drawMoon() {
  const float syn = 29.53058867f;
  uint32_t elapsed = (millis()-clockStartMillis)/1000UL;
  float days = (float)compileDateDays() + ((float)compileTimeSeconds()+(float)elapsed)/86400.0f;
  float age  = fmod(days-10962.7597f, syn);
  if (age < 0.0f) age += syn;
  float phase       = age/syn;
  int   illumination = (int)round((1.0f-cos(phase*6.2831853f))*50.0f);
  drawHeader("MOON");
  drawMoonDisc(232, 82, 45, phase);
  gfx->setTextSize(2); gfx->setTextColor(FG);
  gfx->setCursor(24, 58);  gfx->print(moonPhaseLabel(phase));
  gfx->setTextSize(1);
  gfx->setCursor(26, 98);  gfx->print("AGE "); gfx->print(age, 1); gfx->print(" DAYS");
  gfx->setCursor(26, 118); gfx->print("LIGHT "); gfx->print(illumination); gfx->print("%");
  drawPageDots();
}

// ── Stock page ────────────────────────────────────────────

void drawRates() {
  drawHeader("EXCHANGE RATES");
  if (!wifiConfigured()) { centeredText("SET WIFI IN secrets.h", 76, 2); drawPageDots(); return; }
  if (!ratesValid) { centeredText("UPDATING", 76, 2); drawPageDots(); return; }
  gfx->setTextSize(3); gfx->setTextColor(FG);
  gfx->setCursor(24, 52); gfx->print("USD / INR");
  gfx->setCursor(24, 112); gfx->print("AED / INR");
  gfx->setTextSize(4);
  gfx->setCursor(186, 52); gfx->print(usdInr, 2);
  gfx->setCursor(186, 112); gfx->print(aedInr, 2);
  gfx->setTextSize(1); gfx->setCursor(24, 142); gfx->print("MID-MARKET; REFRESH 30 MIN");
  drawPageDots();
}

// ── GitHub page ───────────────────────────────────────────

void drawGold() {
  drawHeader("24K GOLD / GRAM");
  if (!wifiConfigured()) { centeredText("SET WIFI IN secrets.h", 76, 2); drawPageDots(); return; }
  if (!goldIndiaValid || !goldUaeValid) { centeredText("UPDATING", 76, 2); drawPageDots(); return; }
  // Tax-inclusive values are estimates for pure 24K gold: India GST 3%, UAE
  // VAT 5%. Jewellery making charges, dealer premiums, customs, and any local
  // exemptions are not included.
  float indiaWithTax = goldIndia24k * 1.03f;
  float uaeWithTax = goldUae24k * 1.05f;
  gfx->setTextSize(1); gfx->setTextColor(rgb(255, 190, 40));
  gfx->setCursor(16, 31); gfx->print("INDIA 24K/G + 3% GST");
  gfx->setCursor(16, 84); gfx->print("UAE 24K/G + 5% VAT");
  gfx->setTextSize(3); gfx->setTextColor(FG);
  gfx->setCursor(16, 45); gfx->print("INR "); gfx->print(indiaWithTax, 0);
  gfx->setCursor(16, 98); gfx->print("AED "); gfx->print(uaeWithTax, 2);
  gfx->setTextSize(1); gfx->setTextColor(rgb(160, 175, 195));
  gfx->setCursor(16, 120); gfx->print("SPOT + EST. TAX / GRAM");
  gfx->setCursor(16, 134); gfx->print("EXCL. MAKING / DEALER FEES");
  drawPageDots();
}

void drawLocation() {
  drawHeader("CURRENT LOCATION");
  if (!wifiConfigured()) { centeredText("SET WIFI IN secrets.h", 76, 2); drawPageDots(); return; }
  if (!locationValid) { centeredText("LOCATING", 76, 2); drawPageDots(); return; }
  centeredText(locationCity.c_str(), 55, 3);
  centeredText(locationCountry.c_str(), 92, 3);
  gfx->setTextSize(1); gfx->setTextColor(FG); gfx->setCursor(28, 132);
  gfx->print("IP LOCATION - APPROXIMATE");
  drawPageDots();
}

// ── Interaction handlers ──────────────────────────────────

void triggerFaceTap() {
  if (currentApp == 0) {
    faceMood = (faceMood+1) % FACE_MOOD_COUNT;
    pressPulse = 1.0f;
  } else {
    switchApp(1);
  }
  nextAutoPage = millis() + PAGE_AUTO_INTERVAL_MS;
}

void readSensors() {
  if (!imuReady) {
    // Animate eyes sinusoidally when IMU is absent
    filteredAx = sin(millis()*0.0012f)*0.12f;
    filteredAy = cos(millis()*0.0010f)*0.12f;
    return;
  }
  imu.update();
  imu.getAccel(&accel);
  imu.getGyro(&gyro);
  filteredAx = filteredAx*0.88f + accel.accelX*0.12f;
  filteredAy = filteredAy*0.88f + accel.accelY*0.12f;
  filteredGz = filteredGz*0.82f + gyro.gyroZ*0.18f;
  // Fast spin → surprised face
  if (fabs(filteredGz) > 130.0f) { faceMood = 2; pressPulse = 1.0f; }
}

void readTouch() {
  if (!touchReady) return;
  // Poll every frame instead of gating on TOUCH_INT. This keeps swipes working
  // on boards where the AXS controller's interrupt is not asserted reliably.
  uint16_t x = 0, y = 0;
  bsp_touch_read();
  if (bsp_touch_get_coordinates(&x, &y)) {
    uint32_t now = millis();
    touchLastX = x; touchLastY = y;
    touchMissFrames = 0;
    if (!touchWasDown) {
      touchStartX = x; touchStartY = y; touchStartMs = now;
      touchMoved = false;
      touchWasDown = true;
      return;
    }
    int16_t dx = (int16_t)x-(int16_t)touchStartX;
    int16_t dy = (int16_t)y-(int16_t)touchStartY;
    if (abs(dx) > 12 || abs(dy) > 12) touchMoved = true;
    if (abs(dx) > 55 && abs(dx) > abs(dy)+18) {
      // Left swipe returns to the previous page; right swipe advances.
      switchApp(dx < 0 ? -1 : 1);
      touchWasDown = false;
      touchMissFrames = 0;
      touchMoved = false;
    }
  } else if (touchWasDown) {
    // The AXS5106L INT/read path can miss the odd frame. Require a few
    // consecutive misses before treating it as release, otherwise taps/swipes
    // get chopped up and feel flaky.
    if (++touchMissFrames < 3) return;
    uint32_t pressMs = millis() - touchStartMs;
    int16_t dx = (int16_t)touchLastX-(int16_t)touchStartX;
    int16_t dy = (int16_t)touchLastY-(int16_t)touchStartY;
    if (pressMs >= 35 && pressMs <= 650 && !touchMoved && abs(dx) < 35 && abs(dy) < 35) {
      triggerFaceTap();
    }
    touchWasDown = false;
    touchMissFrames = 0;
    touchMoved = false;
  }
}

void updateFaceTimers() {
  uint32_t now = millis();
  if (now > nextBlink) {
    blinkUntil = now + (random(0,6)==0 ? 220 : 105);
    nextBlink  = now + 1000 + random(0, 2600);
  }
  if (now > nextGlance) {
    faceTargetX = (float)random(-8, 9);
    faceTargetY = (float)random(-4, 5);
    nextGlance  = now + 650 + random(0, 1500);
  }
  faceGlanceX = faceGlanceX*0.84f + faceTargetX*0.16f;
  faceGlanceY = faceGlanceY*0.84f + faceTargetY*0.16f;
  pressPulse *= 0.86f;
}

void updateAutoPage() {
  if (millis() > nextAutoPage) switchApp(1);
}

void updateNetworkPages() {
  // Requests occur only when a related page is visible; failed requests retry
  // after two minutes rather than blocking the touch UI in a tight loop.
  uint32_t now = millis();
  if (currentApp == 1 || currentApp == 2 || currentApp == 3 || currentApp == 6) {
    if ((!locationValid && (locationUpdatedAt == 0 || now - locationUpdatedAt > 120000UL)) || now - locationUpdatedAt > 24UL*60UL*60UL*1000UL) {
      locationUpdatedAt = now; fetchLocation();
    }
  }
  if ((currentApp == 1 || currentApp == 3 || currentApp == 6) && (!weatherValid || now - weatherUpdatedAt > 15UL*60UL*1000UL)) {
    weatherUpdatedAt = now; fetchWeather();
  }
  if (currentApp == 4 && (!ratesValid || now - ratesUpdatedAt > 30UL*60UL*1000UL)) {
    ratesUpdatedAt = now; fetchRates();
  }
  if (currentApp == 5 && (!goldIndiaValid || now - goldUpdatedAt > 6UL*60UL*60UL*1000UL)) {
    goldUpdatedAt = now; fetchGoldRates();
  }
}

void calibrateNeutral() {
  gfx->fillScreen(BG);
  centeredText("HOLD STILL", 76, 2);
  gfx->flush();
  delay(900);
  for (uint8_t i = 0; i < 100; i++) { imu.update(); delay(5); }
  float sumX=0.0f, sumY=0.0f;
  for (uint8_t i = 0; i < 140; i++) {
    imu.update(); imu.getAccel(&accel);
    sumX += accel.accelX; sumY += accel.accelY;
    delay(5);
  }
  restAx = sumX/140.0f; restAy = sumY/140.0f;
  filteredAx = restAx;  filteredAy = restAy;
}

// ── Arduino entry points ──────────────────────────────────

void setup() {
  Serial.begin(115200);
  delay(150);
  Serial.println("ESP32-C6 DeskBuddy starting");

  if (!gfx->begin(40000000)) Serial.println("Display init failed — check wiring");
  lcdRegInit();
  display->setRotation(ROTATION);
  pinMode(LCD_BL, OUTPUT);
  digitalWrite(LCD_BL, HIGH);
  gfx->fillScreen(BG);
  gfx->flush();

  Wire.begin(TOUCH_SDA, TOUCH_SCL);
  Wire.setClock(400000);
  bsp_touch_init(&Wire, TOUCH_RST, TOUCH_INT, ROTATION, gfx->width(), gfx->height());
  touchReady = true;
  Serial.println("Touch controller initialised");

  int err = imu.init(calib, IMU_ADDRESS);
  if (err == 0) {
    imuReady = (imu.setAccelRange(4)==0 && imu.setGyroRange(512)==0);
    if (imuReady) calibrateNeutral();
  }
  if (!imuReady) Serial.println("IMU unavailable — using animated fallback motion");

  randomSeed(micros());
  clockStartMillis  = millis();
  clockStartSeconds = compileTimeSeconds();
  nextBlink         = millis() + 1200;
  nextGlance        = millis() + 600;
  nextAutoPage      = millis() + PAGE_AUTO_INTERVAL_MS;
}

void loop() {
  readSensors();
  readTouch();
  updateAutoPage();
  updateFaceTimers();
  updateNetworkPages();

  float tx=0.0f, ty=0.0f;
  if (imuReady) {
    tx = clampFloat(-(filteredAy-restAy)*2.2f, -1.0f, 1.0f);
    ty = clampFloat( (filteredAx-restAx)*2.2f, -1.0f, 1.0f);
  } else {
    tx = sin(millis()*0.0014f)*0.25f;
    ty = cos(millis()*0.0011f)*0.16f;
  }

  switch (currentApp) {
    case 0: drawFace(tx, ty);  break;
    case 1: drawClock();       break;
    case 2: drawLocation();    break;
    case 3: drawWeather();     break;
    case 4: drawRates();       break;
    case 5: drawGold();        break;
    default: drawForecast();   break;
  }
  gfx->flush();

  if (millis()-lastSerialMs > 1200) {
    lastSerialMs = millis();
    Serial.print("app="); Serial.print(currentApp);
    Serial.print(" mood="); Serial.println(faceMood);
  }
  delay(24);
}
