Raspberry Pi Pico 2
Pinout
- GP01Type · GPIO
- GP12Type · GPIO
- GND3Type · Ground
- GP24Type · GPIO
- GP35Type · GPIO
- GP46Type · GPIO
- GP57Type · GPIO
- GND8Type · Ground
- GP69Type · GPIO
- GP710Type · GPIO
- GP811Type · GPIO
- GP912Type · GPIO
- GND13Type · Ground
- GP1014Type · GPIO
- GP1115Type · GPIO
- GP1216Type · GPIO
- GP1317Type · GPIO
- GND18Type · Ground
- GP1419Type · GPIO
- GP1520Type · GPIO
- GP1621Type · GPIO
- GP1722Type · GPIO
- GND23Type · Ground
- GP1824Type · GPIO
- GP1925Type · GPIO
- GP2026Type · GPIO
- GP2127Type · GPIO
- GND28Type · Ground
- GP2229Type · GPIO
- GP2330Type · GPIO
- GP2431Type · GPIO
- GP2532Type · GPIO
- GND33Type · Ground
- GP2634Type · GPIO
- GP2735Type · GPIO
- GP2836Type · GPIO
- GND37Type · Ground
- 3V336Type · Power
- 3V3_EN37Type · Control
- VSYS39Type · Power
- VBUS40Type · Power
| Pin | Position | Type |
|---|---|---|
| GP0 | 1 | GPIO |
| GP1 | 2 | GPIO |
| GND | 3 | Ground |
| GP2 | 4 | GPIO |
| GP3 | 5 | GPIO |
| GP4 | 6 | GPIO |
| GP5 | 7 | GPIO |
| GND | 8 | Ground |
| GP6 | 9 | GPIO |
| GP7 | 10 | GPIO |
| GP8 | 11 | GPIO |
| GP9 | 12 | GPIO |
| GND | 13 | Ground |
| GP10 | 14 | GPIO |
| GP11 | 15 | GPIO |
| GP12 | 16 | GPIO |
| GP13 | 17 | GPIO |
| GND | 18 | Ground |
| GP14 | 19 | GPIO |
| GP15 | 20 | GPIO |
| GP16 | 21 | GPIO |
| GP17 | 22 | GPIO |
| GND | 23 | Ground |
| GP18 | 24 | GPIO |
| GP19 | 25 | GPIO |
| GP20 | 26 | GPIO |
| GP21 | 27 | GPIO |
| GND | 28 | Ground |
| GP22 | 29 | GPIO |
| GP23 | 30 | GPIO |
| GP24 | 31 | GPIO |
| GP25 | 32 | GPIO |
| GND | 33 | Ground |
| GP26 | 34 | GPIO |
| GP27 | 35 | GPIO |
| GP28 | 36 | GPIO |
| GND | 37 | Ground |
| 3V3 | 36 | Power |
| 3V3_EN | 37 | Control |
| VSYS | 39 | Power |
| VBUS | 40 | Power |
Pin details
41 connections- GP01GPIO
- GP12GPIO
- GND3Ground
- GP24GPIO
- GP35GPIO
- GP46GPIO
- GP57GPIO
- GND8Ground
- GP69GPIO
- GP710GPIO
- GP811GPIO
- GP912GPIO
- GND13Ground
- GP1014GPIO
- GP1115GPIO
- GP1216GPIO
- GP1317GPIO
- GND18Ground
- GP1419GPIO
- GP1520GPIO
- GP1621GPIO
- GP1722GPIO
- GND23Ground
- GP1824GPIO
- GP1925GPIO
- GP2026GPIO
- GP2127GPIO
- GND28Ground
- GP2229GPIO
- GP2330GPIO
- GP2431GPIO
- GP2532GPIO
- GND33Ground
- GP2634GPIO
- GP2735GPIO
- GP2836GPIO
- GND37Ground
- 3V336Power
- 3V3_EN37Control
- VSYS39Power
- VBUS40Power
Pi Pico
