Build A Tiny Esp Deskbuddy Using Waveshare Esp32

#include <Arduino.h>
#include <WiFi.h>
#include <WiFiClientSecure.h>
#include <HTTPClient.h>
#include <ArduinoJson.h>
#include <Wire.h>
#include <SPI.h>
#include <SD.h>
#include <Arduino_GFX_Library.h>
#include <FastIMU.h>
#include "secrets.h"

#define LCD_MOSI 2
#define LCD_CS 14
#define LCD_DC 15
#define LCD_RST 22
#define LCD_BL 23
#define SD_CS 4
#define TOUCH_SCL 19
#define TOUCH_RST 20


// Hoisted type definitions
enum Page : uint8_t { PET_PAGE, CLOCK_PAGE, WEATHER_PAGE, SPOTIFY_PAGE, STATS_PAGE, PAGE_COUNT };

enum Mood : uint8_t { CALM, HAPPY, LOVE, WORRIED, LEVEL_UP };

struct OnlineState {
  float temperatureC = NAN;
  int weatherCode = -1;
  float aapl = NAN;
  float aaplChange = NAN;
  int githubRepos = -1;
  int githubFollowers = -1;
  int completedTasks = -1;
  String nextEvent = "Sin calendario";
  String track = "Sin conectar";
  String artist = "Spotify remoto";
};


// Forward declarations
uint16_t color(uint8_t r, uint8_t g, uint8_t b);
void centered(const String &text, int16_t y, uint16_t ink, uint8_t size);
void beep(uint16_t hz, uint16_t durationMs);
void serviceBuzzer();
bool readTouch(int16_t &x, int16_t &y);
bool drawRgb565Asset(const char *path);
String moonPhase();
void drawDots();
void drawFallbackFace();
void drawScreen();
bool getJson(const String &url, JsonDocument &document, const String &authorization);
void requestProxy(const char *route);
void networkTask(void *);
void handleTouch();
void serviceImu();

constexpr int LCD_SCK = 1, LCD_MOSI = 2, LCD_CS = 14, LCD_DC = 15, LCD_RST = 22, LCD_BL = 23;
constexpr int SD_MISO = 3, SD_CS = 4;
constexpr int TOUCH_SDA = 18, TOUCH_SCL = 19, TOUCH_RST = 20;
constexpr int BUZZER_PIN = 7;
constexpr uint16_t SCREEN_W = 172, SCREEN_H = 320;
constexpr uint32_t NETWORK_PERIOD_MS = 10UL * 60UL * 1000UL;






Arduino_DataBus *bus = new Arduino_HWSPI(LCD_DC, LCD_CS, LCD_SCK, LCD_MOSI);
Arduino_GFX *gfx = new Arduino_ST7789(bus, LCD_RST, 0, false, SCREEN_W, SCREEN_H, 34, 0, 34, 0);
QMI8658 imu;
calData imuCalibration{};

OnlineState online;
Page page = PET_PAGE;
Mood mood = CALM;
bool sdReady = false, imuReady = false, faceDown = false, redrawNeeded = true;
bool touchActive = false, toneActive = false, networkBusy = false;
int16_t touchStartX = 0, touchLastX = 0;
float eyeX = 0, eyeY = 0;
uint32_t lastImuMs = 0, lastClockMs = 0, lastNetworkMs = 0, toneEndsMs = 0;
volatile bool networkResultReady = false;
volatile bool spotifyToggleRequested = false, spotifyNextRequested = false;

uint16_t color(uint8_t r, uint8_t g, uint8_t b) { return gfx->color565(r, g, b); }

void centered(const String &text, int16_t y, uint16_t ink, uint8_t size = 1) {
  gfx->setTextSize(size);
  gfx->setTextColor(ink);
  int16_t x = (SCREEN_W - gfx->textWidth(text)) / 2;
  gfx->setCursor(max<int16_t>(0, x), y);
  gfx->print(text);
}

void beep(uint16_t hz, uint16_t durationMs) {
  ledcAttach(BUZZER_PIN, hz, 8);
  ledcWriteTone(BUZZER_PIN, hz);
  toneEndsMs = millis() + durationMs;
  toneActive = true;
}

void serviceBuzzer() {
  if (toneActive && (int32_t)(millis() - toneEndsMs) >= 0) {
    ledcWriteTone(BUZZER_PIN, 0);
    toneActive = false;
  }
}

// AXS5106L: byte 0 is touch count; point 0 then contains event/id, X hi/lo, Y hi/lo, pressure.
bool readTouch(int16_t &x, int16_t &y) {
  Wire.beginTransmission(0x3B);
  Wire.write(0x00);
  if (Wire.endTransmission(false) != 0 || Wire.requestFrom(0x3B, 7) != 7) return false;
  uint8_t count = Wire.read();
  if ((count & 0x0F) == 0) { while (Wire.available()) Wire.read(); return false; }
  Wire.read(); // event and finger id
  uint8_t xh = Wire.read(), xl = Wire.read(), yh = Wire.read(), yl = Wire.read();
  Wire.read(); // pressure
  x = constrain((int16_t)(((xh & 0x0F) << 8) | xl), 0, (int)SCREEN_W - 1);
  y = constrain((int16_t)(((yh & 0x0F) << 8) | yl), 0, (int)SCREEN_H - 1);
  return true;
}

const char *faceAsset() {
  switch (mood) {
    case HAPPY: return "/faces/happy.rgb565";
    case LOVE: return "/faces/love.rgb565";
    case WORRIED: return "/faces/worried.rgb565";
    case LEVEL_UP: return "/faces/levelup.rgb565";
    default: return "/faces/calm.rgb565";
  }
}

// Optional SD assets are raw 172x320 RGB565, little-endian. Missing assets fall back to vector art.
bool drawRgb565Asset(const char *path) {
  File file = SD.open(path, FILE_READ);
  if (!file) return false;
  uint16_t row[SCREEN_W];
  for (uint16_t y = 0; y < SCREEN_H; ++y) {
    if (file.read((uint8_t *)row, sizeof(row)) != sizeof(row)) { file.close(); return false; }
    gfx->draw16bitRGBBitmap(0, y, row, SCREEN_W, 1);
  }
  file.close();
  return true;
}

String moonPhase() {
  time_t now = time(nullptr);
  if (now < 100000) return "Luna: esperando hora";
  float age = fmodf((now / 86400.0f - 10957.5f), 29.53059f);
  if (age < 0) age += 29.53059f;
  if (age < 1.85f || age >= 27.68f) return "Luna nueva";
  if (age < 7.38f) return "Luna creciente";
  if (age < 14.77f) return "Luna llena";
  if (age < 22.15f) return "Luna menguante";
  return "Luna menguante";
}

void drawDots() {
  for (uint8_t i = 0; i < PAGE_COUNT; ++i)
    gfx->fillCircle(66 + i * 10, 307, 3, i == page ? WHITE : color(66, 76, 96));
}

void drawFallbackFace() {
  uint16_t background = mood == WORRIED ? color(45, 15, 27) : color(15, 18, 30);
  uint16_t accent = mood == LEVEL_UP ? color(92, 255, 165) : color(255, 100, 150);
  gfx->fillScreen(background);
  gfx->fillCircle(34, 218, 17, accent);
  gfx->fillCircle(138, 218, 17, accent);
  gfx->fillRoundRect(25, 102, 54, 76, 27, WHITE);
  gfx->fillRoundRect(93, 102, 54, 76, 27, WHITE);
  int radius = mood == LOVE ? 18 : (mood == CALM ? 10 : 14);
  gfx->fillCircle(52 + (int)eyeX, 140 + (int)eyeY, radius, background);
  gfx->fillCircle(120 + (int)eyeX, 140 + (int)eyeY, radius, background);
  gfx->fillRoundRect(58, 197, 56, 14, 7, WHITE);
  if (mood == LEVEL_UP) centered("LEVEL UP!", 47, color(120, 255, 180), 2);
  if (mood == WORRIED) centered("!", 45, color(255, 190, 105), 3);
  if (online.weatherCode >= 51 && online.weatherCode <= 82) centered("PARAGUAS", 268, color(120, 205, 255));
  else if (!isnan(online.temperatureC) && online.temperatureC >= 28) centered("GAFAS", 268, color(255, 225, 100));
}

void drawScreen() {
  if (faceDown) { gfx->fillScreen(BLACK); return; }
  if (page == PET_PAGE) {
    if (!(sdReady && SD.exists(faceAsset()) && drawRgb565Asset(faceAsset()))) drawFallbackFace();
    drawDots();
    return;
  }
  gfx->fillScreen(color(12, 14, 24));
  if (page == CLOCK_PAGE) {
    struct tm localTime;
    if (getLocalTime(&localTime, 5)) {
      char clockText[8], dateText[24];
      strftime(clockText, sizeof(clockText), "%H:%M", &localTime);
      strftime(dateText, sizeof(dateText), "%a %d %b", &localTime);
      centered(clockText, 72, WHITE, 5); centered(dateText, 139, color(165, 190, 230), 2);
    } else centered("Conectando reloj", 112, WHITE, 2);
    centered(online.nextEvent, 205, color(180, 205, 255));
    if (!isnan(online.temperatureC)) centered(String(online.temperatureC, 1) + " C", 245, color(115, 220, 255), 2);
  } else if (page == WEATHER_PAGE) {
    centered("CLIMA", 33, color(120, 215, 255), 2);
    if (isnan(online.temperatureC)) centered("Wi-Fi pendiente", 118, WHITE, 2);
    else centered(String(online.temperatureC, 1) + " C", 100, WHITE, 4);
    centered(moonPhase(), 186, color(230, 225, 170), 2);
    centered("Open-Meteo", 254, color(160, 180, 210));
  } else if (page == SPOTIFY_PAGE) {
    centered("SPOTIFY REMOTE", 33, color(80, 225, 130), 2);
    gfx->fillRoundRect(36, 67, 100, 100, 14, color(35, 62, 46));
    centered(online.track, 192, WHITE, 2);
    centered(online.artist, 220, color(170, 200, 180));
    centered("toque: pausa | deslice: sig.", 271, color(135, 160, 145));
  } else {
    centered("ESTADO", 33, WHITE, 2);
    String stock = isnan(online.aapl) ? "AAPL: proxy pendiente" : "AAPL $" + String(online.aapl, 2);
    uint16_t stockInk = (!isnan(online.aaplChange) && online.aaplChange < 0) ? color(255, 105, 120) : color(95, 235, 155);
    centered(stock, 90, stockInk, 2);
    centered("GitHub repos: " + String(online.githubRepos), 143, color(190, 200, 235), 2);
    centered("Seguidores: " + String(online.githubFollowers), 178, color(190, 200, 235), 2);
    centered("Tareas: " + String(online.completedTasks), 222, color(255, 210, 120), 2);
  }
  drawDots();
}

bool getJson(const String &url, JsonDocument &document, const String &authorization = "") {
  if (WiFi.status() != WL_CONNECTED) return false;
  WiFiClientSecure client; client.setInsecure();
  HTTPClient request; request.setTimeout(7000);
  if (!request.begin(client, url)) return false;
  if (authorization.length()) request.addHeader("Authorization", authorization);
  int status = request.GET();
  if (status != HTTP_CODE_OK) { request.end(); return false; }
  DeserializationError error = deserializeJson(document, request.getStream());
  request.end();
  return !error;
}

void requestProxy(const char *route) {
  if (!String(DESKBUDDY_PROXY_URL).length() || WiFi.status() != WL_CONNECTED) return;
  WiFiClientSecure client; client.setInsecure(); HTTPClient request;
  String url = String(DESKBUDDY_PROXY_URL) + route;
  if (!request.begin(client, url)) return;
  if (String(DESKBUDDY_PROXY_BEARER).length()) request.addHeader("Authorization", "Bearer " + String(DESKBUDDY_PROXY_BEARER));
  request.POST(""); request.end();
}

// Runs network I/O away from loop(), so touch, eyes and the clock remain responsive.
void networkTask(void *) {
  for (;;) {
    if (WiFi.status() == WL_CONNECTED) {
      JsonDocument document;
      String weatherUrl = "https://api.open-meteo.com/v1/forecast?latitude=" + String(WEATHER_LAT, 4) + "&longitude=" + String(WEATHER_LON, 4) + "&current=temperature_2m,weather_code&timezone=" + String(WEATHER_TZ);
      if (getJson(weatherUrl, document)) {
        online.temperatureC = document["current"]["temperature_2m"] | NAN;
        online.weatherCode = document["current"]["weather_code"] | -1;
      }
      if (String(GITHUB_USER).length()) {
        document.clear();
        String auth = String(GITHUB_TOKEN).length() ? "Bearer " + String(GITHUB_TOKEN) : "";
        if (getJson("https://api.github.com/users/" + String(GITHUB_USER), document, auth)) {
          online.githubRepos = document["public_repos"] | -1;
          online.githubFollowers = document["followers"] | -1;
        }
      }
      if (String(DESKBUDDY_PROXY_URL).length()) {
        document.clear();
        String auth = String(DESKBUDDY_PROXY_BEARER).length() ? "Bearer " + String(DESKBUDDY_PROXY_BEARER) : "";
        if (getJson(String(DESKBUDDY_PROXY_URL) + "/deskbuddy/summary", document, auth)) {
          online.aapl = document["aapl"]["price"] | NAN;
          online.aaplChange = document["aapl"]["change"] | NAN;
          online.completedTasks = document["productivity"]["completed"] | -1;
          online.nextEvent = String((const char *)document["calendar"]["next"] | "Sin calendario");
          online.track = String((const char *)document["spotify"]["track"] | "Sin reproducir");
          online.artist = String((const char *)document["spotify"]["artist"] | "Spotify remoto");
        }
      }
      if (spotifyToggleRequested) { spotifyToggleRequested = false; requestProxy("/spotify/toggle"); }
      if (spotifyNextRequested) { spotifyNextRequested = false; requestProxy("/spotify/next"); }
      networkResultReady = true;
    }
    vTaskDelay(pdMS_TO_TICKS(NETWORK_PERIOD_MS));
  }
}

void handleTouch() {
  int16_t x, y;
  bool down = readTouch(x, y);
  if (down) {
    touchLastX = x;
    if (!touchActive) { touchActive = true; touchStartX = x; }
    return;
  }
  if (!touchActive) return;
  touchActive = false;
  int16_t dx = touchLastX - touchStartX;
  if (abs(dx) > 35) {
    if (page == SPOTIFY_PAGE && dx < 0) spotifyNextRequested = true;
    page = (Page)((page + (dx < 0 ? 1 : PAGE_COUNT - 1)) % PAGE_COUNT);
    redrawNeeded = true;
  } else if (page == PET_PAGE) {
    mood = (Mood)((mood + 1) % 5);
    beep(mood == LEVEL_UP ? 1047 : 660, 75);
    redrawNeeded = true;
  } else if (page == SPOTIFY_PAGE) {
    spotifyToggleRequested = true;
    online.track = "Orden enviada";
    redrawNeeded = true;
  }
}

void serviceImu() {
  if (!imuReady || millis() - lastImuMs < 50) return;
  lastImuMs = millis();
  AccelData acceleration; imu.getAccel(&acceleration);
  float nextX = constrain(acceleration.accelY * 7.0f, -8.0f, 8.0f);
  float nextY = constrain(-acceleration.accelX * 7.0f, -8.0f, 8.0f);
  if (abs(nextX - eyeX) > 0.5f || abs(nextY - eyeY) > 0.5f) { eyeX = nextX; eyeY = nextY; if (page == PET_PAGE) redrawNeeded = true; }
  bool nowFaceDown = acceleration.accelZ < -0.82f;
  if (nowFaceDown != faceDown && (nowFaceDown || acceleration.accelZ > -0.55f)) {
    faceDown = nowFaceDown; digitalWrite(LCD_BL, faceDown ? LOW : HIGH); redrawNeeded = true;
  }
}

void setup() {
  Serial.begin(115200);
  pinMode(LCD_BL, OUTPUT); digitalWrite(LCD_BL, HIGH);
  pinMode(TOUCH_RST, OUTPUT); digitalWrite(TOUCH_RST, LOW); delay(5); digitalWrite(TOUCH_RST, HIGH);
  Wire.begin(TOUCH_SDA, TOUCH_SCL);
  SPI.begin(LCD_SCK, SD_MISO, LCD_MOSI, SD_CS);
  gfx->begin();
  // JD9853 accepts the ST7789 command set; these commands wake and enable the panel.
  bus->beginWrite(); bus->writeCommand(0x11); bus->endWrite(); delay(120);
  bus->beginWrite(); bus->writeCommand(0x29); bus->endWrite();
  gfx->setRotation(2); gfx->invertDisplay(true);
  sdReady = SD.begin(SD_CS, SPI, 25000000);
  imuReady = imu.init(imuCalibration, 0x6B) == 0;
  if (imuReady) { imu.setAccelRange(QMI8658AccelRange::ACCEL_RANGE_2G); imu.setAccelOdr(QMI8658AccelOdr::ACCEL_ODR_125Hz); }
  if (String(WIFI_SSID).length()) { WiFi.mode(WIFI_STA); WiFi.begin(WIFI_SSID, WIFI_PASSWORD); }
  configTzTime(WEATHER_TZ, "pool.ntp.org", "time.nist.gov");
  xTaskCreate(networkTask, "deskbuddy_net", 8192, nullptr, 1, nullptr);
  drawScreen();
}

void loop() {
  handleTouch(); serviceImu(); serviceBuzzer();
  if (networkResultReady) {
    networkResultReady = false;
    if (!isnan(online.aaplChange)) mood = online.aaplChange < 0 ? WORRIED : HAPPY;
    redrawNeeded = true;
  }
  if (page == CLOCK_PAGE && millis() - lastClockMs >= 1000) { lastClockMs = millis(); redrawNeeded = true; }
  if (redrawNeeded && !faceDown) { redrawNeeded = false; drawScreen(); }
}
