UNIHIKER K10 Overview

#include <Arduino.h>
#include <unihiker_k10.h>
#include <lvgl.h>


// Hoisted type definitions
enum Direction : uint8_t { UP, RIGHT, DOWN, LEFT };

struct Cell {
  int8_t x;
  int8_t y;
};


// Forward declarations
bool sameCell(const Cell &a, const Cell &b);
bool snakeContains(const Cell &candidate);
void paintCell(const Cell &cell, lv_color_t color);
void updateScoreText();
void placeFood();
void startGame();
void turnLeft();
void turnRight();
void endGame();
void advanceSnake();
void createInterface();

UNIHIKER_K10 k10;

constexpr uint8_t COLS = 16;
constexpr uint8_t ROWS = 19;
constexpr uint8_t CELL = 14;
constexpr uint8_t MAX_SNAKE = COLS * ROWS;
constexpr uint32_t STEP_INTERVAL_MS = 190;





lv_obj_t *gridCells[ROWS][COLS];
lv_obj_t *scoreLabel;
lv_obj_t *hintLabel;

Cell snake[MAX_SNAKE];
Cell food;
uint16_t snakeLength;
uint16_t score;
Direction direction;
bool gameOver;
bool previousA;
bool previousB;
uint32_t lastStepMs;

const lv_color_t COLOR_EMPTY = lv_color_hex(0x112029);
const lv_color_t COLOR_HEAD = lv_color_hex(0x5CE1E6);
const lv_color_t COLOR_BODY = lv_color_hex(0x32B17C);
const lv_color_t COLOR_FOOD = lv_color_hex(0xFF6B6B);

bool sameCell(const Cell &a, const Cell &b) {
  return a.x == b.x && a.y == b.y;
}

bool snakeContains(const Cell &candidate) {
  for (uint16_t i = 0; i < snakeLength; ++i) {
    if (sameCell(snake[i], candidate)) {
      return true;
    }
  }
  return false;
}

void paintCell(const Cell &cell, lv_color_t color) {
  if (cell.x >= 0 && cell.x < COLS && cell.y >= 0 && cell.y < ROWS) {
    lv_obj_set_style_bg_color(gridCells[cell.y][cell.x], color, LV_PART_MAIN);
  }
}

void updateScoreText() {
  char text[28];
  snprintf(text, sizeof(text), "SNAKE   SCORE: %u", score);
  lv_label_set_text(scoreLabel, text);
}

void placeFood() {
  uint16_t available = MAX_SNAKE - snakeLength;
  if (available == 0) {
    gameOver = true;
    lv_label_set_text(hintLabel, "YOU WIN! Hold A+B to play again");
    return;
  }

  uint16_t chosen = random(available);
  for (uint8_t y = 0; y < ROWS; ++y) {
    for (uint8_t x = 0; x < COLS; ++x) {
      Cell candidate = {(int8_t)x, (int8_t)y};
      if (!snakeContains(candidate)) {
        if (chosen == 0) {
          food = candidate;
          paintCell(food, COLOR_FOOD);
          return;
        }
        --chosen;
      }
    }
  }
}

void startGame() {
  for (uint8_t y = 0; y < ROWS; ++y) {
    for (uint8_t x = 0; x < COLS; ++x) {
      Cell cell = {(int8_t)x, (int8_t)y};
      paintCell(cell, COLOR_EMPTY);
    }
  }

  snakeLength = 4;
  snake[0] = {8, 9};
  snake[1] = {7, 9};
  snake[2] = {6, 9};
  snake[3] = {5, 9};
  score = 0;
  direction = RIGHT;
  gameOver = false;
  updateScoreText();
  lv_label_set_text(hintLabel, "A: turn left     B: turn right");

  for (uint16_t i = 0; i < snakeLength; ++i) {
    paintCell(snake[i], i == 0 ? COLOR_HEAD : COLOR_BODY);
  }
  placeFood();
  lastStepMs = millis();
}

void turnLeft() {
  direction = static_cast<Direction>((direction + 3) % 4);
}

void turnRight() {
  direction = static_cast<Direction>((direction + 1) % 4);
}

void endGame() {
  gameOver = true;
  lv_label_set_text(hintLabel, "GAME OVER - hold A+B to restart");
}

void advanceSnake() {
  Cell next = snake[0];
  if (direction == UP) --next.y;
  if (direction == RIGHT) ++next.x;
  if (direction == DOWN) ++next.y;
  if (direction == LEFT) --next.x;

  bool ateFood = sameCell(next, food);
  if (next.x < 0 || next.x >= COLS || next.y < 0 || next.y >= ROWS) {
    endGame();
    return;
  }

  uint16_t collisionLength = ateFood ? snakeLength : snakeLength - 1;
  for (uint16_t i = 0; i < collisionLength; ++i) {
    if (sameCell(next, snake[i])) {
      endGame();
      return;
    }
  }

  Cell oldTail = snake[snakeLength - 1];
  if (!ateFood) {
    paintCell(oldTail, COLOR_EMPTY);
  } else {
    ++snakeLength;
    ++score;
    updateScoreText();
  }

  for (int16_t i = snakeLength - 1; i > 0; --i) {
    snake[i] = snake[i - 1];
  }
  snake[0] = next;

  paintCell(snake[1], COLOR_BODY);
  paintCell(snake[0], COLOR_HEAD);

  if (ateFood) {
    placeFood();
  }
}

void createInterface() {
  k10.setScreenBackground(0x0B141A);

  scoreLabel = lv_label_create(lv_scr_act());
  lv_obj_set_pos(scoreLabel, 8, 7);
  lv_obj_set_style_text_color(scoreLabel, lv_color_hex(0xE6F1F5), LV_PART_MAIN);
  lv_obj_set_style_text_font(scoreLabel, &lv_font_montserrat_14, LV_PART_MAIN);

  hintLabel = lv_label_create(lv_scr_act());
  lv_obj_set_pos(hintLabel, 8, 27);
  lv_obj_set_style_text_color(hintLabel, lv_color_hex(0xA9BBC3), LV_PART_MAIN);
  lv_obj_set_style_text_font(hintLabel, &lv_font_montserrat_14, LV_PART_MAIN);

  for (uint8_t y = 0; y < ROWS; ++y) {
    for (uint8_t x = 0; x < COLS; ++x) {
      lv_obj_t *tile = lv_obj_create(lv_scr_act());
      gridCells[y][x] = tile;
      lv_obj_set_size(tile, CELL - 1, CELL - 1);
      lv_obj_set_pos(tile, 8 + x * CELL, 53 + y * CELL);
      lv_obj_set_style_bg_opa(tile, LV_OPA_COVER, LV_PART_MAIN);
      lv_obj_set_style_bg_color(tile, COLOR_EMPTY, LV_PART_MAIN);
      lv_obj_set_style_border_width(tile, 0, LV_PART_MAIN);
      lv_obj_set_style_radius(tile, 2, LV_PART_MAIN);
      lv_obj_clear_flag(tile, LV_OBJ_FLAG_SCROLLABLE);
    }
  }
}

void setup() {
  k10.begin();
  k10.initScreen();
  randomSeed(static_cast<uint32_t>(micros()));
  createInterface();
  startGame();
}

void loop() {
  lv_timer_handler();

  bool aPressed = k10.buttonA->isPressed();
  bool bPressed = k10.buttonB->isPressed();

  if (gameOver) {
    if (aPressed && bPressed) {
      startGame();
    }
  } else {
    if (aPressed && !previousA && !bPressed) {
      turnLeft();
    }
    if (bPressed && !previousB && !aPressed) {
      turnRight();
    }
    if (millis() - lastStepMs >= STEP_INTERVAL_MS) {
      lastStepMs += STEP_INTERVAL_MS;
      advanceSnake();
    }
  }

  previousA = aPressed;
  previousB = bPressed;
  delay(5);
}
