MAX232CPE DIP-16
Pinout
- C1+1Type · Signal
- V+2Type · Power
- C1-3Type · Signal
- C2+4Type · Signal
- C2-5Type · Signal
- V-6Type · Power
- T2OUT7Type · Signal
- R2IN8Type · Signal
- R2OUT9Type · Signal
- T2IN10Type · Signal
- T1IN11Type · Signal
- R1OUT12Type · Signal
- R1IN13Type · Signal
- T1OUT14Type · Signal
- GND15Type · Ground
- VCC16Type · Power
| Pin | Position | Type |
|---|---|---|
| C1+ | 1 | Signal |
| V+ | 2 | Power |
| C1- | 3 | Signal |
| C2+ | 4 | Signal |
| C2- | 5 | Signal |
| V- | 6 | Power |
| T2OUT | 7 | Signal |
| R2IN | 8 | Signal |
| R2OUT | 9 | Signal |
| T2IN | 10 | Signal |
| T1IN | 11 | Signal |
| R1OUT | 12 | Signal |
| R1IN | 13 | Signal |
| T1OUT | 14 | Signal |
| GND | 15 | Ground |
| VCC | 16 | Power |
Pin details
16 connections- C1+1Signal
- V+2Power
- C1-3Signal
- C2+4Signal
- C2-5Signal
- V-6Power
- T2OUT7Signal
- R2IN8Signal
- R2OUT9Signal
- T2IN10Signal
- T1IN11Signal
- R1OUT12Signal
- R1IN13Signal
- T1OUT14Signal
- GND15Ground
- VCC16Power
