Pocket Arcade Dodge Game

// Pocket Arcade for ESP32-S3-DevKitC-1-N8 (no PSRAM)
// Platform: espressif32@6.7.0 / Arduino-ESP32 2.0.14 family.
// Libraries: Adafruit SSD1306 2.5.7, Adafruit GFX 1.11.5, MD_MAX72XX 3.5.1.
// Safe default: OLED only. Never enable matrix output until its 5 V logic
// interface has been physically approved; a build option cannot verify wiring.

#include <Arduino.h>
#include <Wire.h>
#include <Preferences.h>
#include <Adafruit_GFX.h>
#include <Adafruit_SSD1306.h>
#ifdef POCKET_ENABLE_VERIFIED_MATRIX
#include <MD_MAX72xx.h>
#endif


// Hoisted type definitions
struct Obstacle { int8_t x; int8_t y; bool active; };

enum GameState : uint8_t { TITLE, COUNTDOWN, PLAYING, PAUSED, GAME_OVER };

enum PlayMode : uint8_t { DODGE_GAME, PIXEL_DEMO };

enum ControlMode : uint8_t { JOYSTICK_CONTROL, TILT_CONTROL };


// Forward declarations
bool i2cExists(uint8_t address);
void mpuWrite(uint8_t reg, uint8_t value);
bool mpuAccelX(float &g);
bool pressedEdge(int pin, bool &lastRaw, bool &stable, uint32_t &changed, uint32_t now);
void clearObstacles();
uint32_t elapsedPlay(uint32_t now);
uint32_t fallInterval(uint32_t now);
void resetRound(uint32_t now);
void beginPlaying(uint32_t now);
void togglePause(uint32_t now);
void finishRound();
void spawnObstacle();
void collisionCheck();
void movePlayer(int direction);
void movePixel(int dx, int dy);
int joystickDirection();
int joystickVertical();
void calibrateJoystick();
void calibrateTilt();
int tiltDirection();
bool logicalPixel(int x, int y);
void drawGridToOled();
void drawDisplay(uint32_t now);
bool logicChecks();
void printMenu();
void handleSerial(uint32_t now);
void updateGame(uint32_t now);

constexpr int JOY_X_PIN = 1;
constexpr int JOY_Y_PIN = 2;
constexpr int JOY_CLICK_PIN = 4;
constexpr int START_BUTTON_PIN = 5;
constexpr int MATRIX_CS_PIN = 10;
constexpr int MATRIX_DIN_PIN = 11;
constexpr int MATRIX_CLK_PIN = 12;
constexpr int I2C_SDA_PIN = 17;
constexpr int I2C_SCL_PIN = 18;
constexpr uint8_t OLED_ADDR = 0x3C;
constexpr uint8_t MPU_ADDR = 0x68;
constexpr uint8_t GRID = 8;
constexpr uint32_t FRAME_MS = 50;       // 20 frames/s maximum redraw rate.
constexpr uint32_t REPEAT_MS = 150;
constexpr uint32_t DEBOUNCE_MS = 35;
constexpr uint32_t COUNTDOWN_MS = 3000;
constexpr uint32_t MIN_FALL_MS = 150;   // playable lower speed limit.
constexpr uint32_t MAX_CATCHUP_STEPS = 4;

#ifndef POCKET_ENABLE_VERIFIED_MATRIX
constexpr bool MATRIX_OUTPUT_ENABLED = false;
#else
constexpr bool MATRIX_OUTPUT_ENABLED = true;
MD_MAX72XX matrix(MD_MAX72XX::FC16_HW, MATRIX_CS_PIN, 1);
#endif

Adafruit_SSD1306 oled(128, 64, &Wire, -1);
Preferences prefs;


Obstacle obstacles[8];




GameState state = TITLE;
PlayMode mode = DODGE_GAME;
ControlMode controlMode = JOYSTICK_CONTROL;

bool oledPresent = false;
bool mpuPresent = false;
bool dirty = true;
bool invertX = false;
bool invertY = false;
bool mirrorMatrixX = false;
bool flipMatrixY = false;
bool tiltInvert = false;
int joyCenterX = 2048, joyCenterY = 2048;
float tiltZero = 0.0f, tiltFiltered = 0.0f;
int playerX = 3, pixelX = 3, pixelY = 3;
uint32_t score = 0, highScore = 0;
uint32_t lastFrame = 0, lastMove = 0, lastFall = 0, stateStarted = 0;
uint32_t unpausedStarted = 0, accumulatedPlayMs = 0;
uint32_t clickChanged = 0, startChanged = 0;
bool lastClickRaw = true, lastStartRaw = true, clickStable = true, startStable = true;

bool i2cExists(uint8_t address) {
  Wire.beginTransmission(address);
  return Wire.endTransmission() == 0;
}

void mpuWrite(uint8_t reg, uint8_t value) {
  Wire.beginTransmission(MPU_ADDR); Wire.write(reg); Wire.write(value); Wire.endTransmission();
}
bool mpuAccelX(float &g) {
  if (!mpuPresent) return false;
  Wire.beginTransmission(MPU_ADDR); Wire.write(0x3B);
  if (Wire.endTransmission(false) != 0 || Wire.requestFrom((int)MPU_ADDR, 2) != 2) return false;
  int16_t raw = (int16_t)((Wire.read() << 8) | Wire.read());
  g = raw / 16384.0f;
  return true;
}

bool pressedEdge(int pin, bool &lastRaw, bool &stable, uint32_t &changed, uint32_t now) {
  bool raw = digitalRead(pin);
  if (raw != lastRaw) { lastRaw = raw; changed = now; }
  if (raw != stable && now - changed >= DEBOUNCE_MS) {
    stable = raw;
    return stable == LOW;
  }
  return false;
}

void clearObstacles() { for (auto &o : obstacles) o.active = false; }
uint32_t elapsedPlay(uint32_t now) { return accumulatedPlayMs + ((state == PLAYING) ? now - unpausedStarted : 0); }
uint32_t fallInterval(uint32_t now) {
  uint32_t level = elapsedPlay(now) / 10000UL;
  uint32_t interval = 650UL - level * 45UL; // drops every 10 s, never below 150 ms.
  return interval < MIN_FALL_MS ? MIN_FALL_MS : interval;
}
void resetRound(uint32_t now) {
  playerX = 3; score = 0; clearObstacles(); accumulatedPlayMs = 0;
  state = COUNTDOWN; stateStarted = now; lastFall = now; dirty = true;
}
void beginPlaying(uint32_t now) { state = PLAYING; unpausedStarted = now; lastFall = now; dirty = true; }
void togglePause(uint32_t now) {
  if (state == PLAYING) { accumulatedPlayMs += now - unpausedStarted; state = PAUSED; }
  else if (state == PAUSED) { state = PLAYING; unpausedStarted = now; }
  dirty = true;
}
void finishRound() {
  state = GAME_OVER;
  if (score > highScore) { highScore = score; prefs.putUInt("high", highScore); }
  dirty = true;
}
void spawnObstacle() {
  for (auto &o : obstacles) if (!o.active) { o = {(int8_t)random(0, 8), 0, true}; return; }
}
void collisionCheck() {
  for (const auto &o : obstacles) if (o.active && o.y == 7 && o.x == playerX) { finishRound(); return; }
}
void movePlayer(int direction) {
  int next = constrain(playerX + direction, 0, 7);
  if (next != playerX) { playerX = next; collisionCheck(); dirty = true; }
}
void movePixel(int dx, int dy) {
  int nx = constrain(pixelX + dx, 0, 7), ny = constrain(pixelY + dy, 0, 7);
  if (nx != pixelX || ny != pixelY) { pixelX = nx; pixelY = ny; dirty = true; }
}
int joystickDirection() {
  int x = analogRead(JOY_X_PIN) - joyCenterX;
  if (invertX) x = -x;
  return (x > 700) ? 1 : ((x < -700) ? -1 : 0);
}
int joystickVertical() {
  int y = analogRead(JOY_Y_PIN) - joyCenterY;
  if (invertY) y = -y;
  return (y > 700) ? 1 : ((y < -700) ? -1 : 0);
}
void calibrateJoystick() { joyCenterX = analogRead(JOY_X_PIN); joyCenterY = analogRead(JOY_Y_PIN); }
void calibrateTilt() {
  float value;
  if (mpuAccelX(value)) { tiltZero = value; tiltFiltered = value; Serial.println("Tilt calibrated: hold level during C command."); }
  else Serial.println("MPU-6050 unavailable; joystick remains active.");
}
int tiltDirection() {
  float value;
  if (!mpuAccelX(value)) { mpuPresent = false; controlMode = JOYSTICK_CONTROL; Serial.println("MPU lost; reverted to joystick."); return 0; }
  tiltFiltered = 0.85f * tiltFiltered + 0.15f * value;
  float delta = (tiltFiltered - tiltZero) * (tiltInvert ? -1.0f : 1.0f);
  return delta > 0.16f ? 1 : (delta < -0.16f ? -1 : 0);
}

bool logicalPixel(int x, int y) {
  if (mode == PIXEL_DEMO) return x == pixelX && y == pixelY;
  if (state == PLAYING || state == PAUSED || state == GAME_OVER || state == COUNTDOWN) {
    if (y == 7 && x == playerX) return true;
    for (const auto &o : obstacles) if (o.active && o.x == x && o.y == y) return true;
  }
  return false;
}
void drawGridToOled() {
  oled.fillRect(64, 0, 64, 64, SSD1306_BLACK);
  for (int y = 0; y < 8; ++y) for (int x = 0; x < 8; ++x)
    if (logicalPixel(x, y)) oled.fillRect(66 + x * 7, 4 + y * 7, 6, 6, SSD1306_WHITE);
}
void drawDisplay(uint32_t now) {
  if (!dirty) return;
  if (oledPresent) {
    oled.clearDisplay(); oled.setTextColor(SSD1306_WHITE); oled.setTextSize(1); oled.setCursor(0, 0);
    if (mode == PIXEL_DEMO) { oled.println("PIXEL DEMO"); oled.println("Stick: move"); oled.println("Click: game"); }
    else {
      oled.println(state == TITLE ? "POCKET ARCADE" : state == PAUSED ? "PAUSED" : state == GAME_OVER ? "GAME OVER" : state == COUNTDOWN ? "GET READY" : "DODGE");
      oled.printf("Score: %lu\nHigh:  %lu\n", (unsigned long)score, (unsigned long)highScore);
      if (state == COUNTDOWN) oled.printf("%lu", (unsigned long)(3 - min(2UL, (now - stateStarted) / 1000UL)));
      else if (state == GAME_OVER) oled.println("Start: retry");
      else oled.println(controlMode == TILT_CONTROL ? "Tilt control" : "Stick control");
    }
    drawGridToOled(); oled.display();
  }
#ifdef POCKET_ENABLE_VERIFIED_MATRIX
  matrix.clear();
  for (int y = 0; y < 8; ++y) for (int x = 0; x < 8; ++x) if (logicalPixel(x, y)) {
    int mx = mirrorMatrixX ? 7 - x : x, my = flipMatrixY ? 7 - y : y;
    matrix.setPoint(my, mx, true);
  }
  matrix.update();
#endif
  dirty = false;
}

// Hardware-independent production logic checks: bounds, collision decisions,
// held button edge behavior, and decreasing/clamped difficulty calculation.
bool logicChecks() {
  bool ok = true;
  ok &= constrain(-1, 0, 7) == 0 && constrain(8, 0, 7) == 7;
  uint32_t slow = 650, fast = MIN_FALL_MS; ok &= slow > fast && fast == 150;
  int savedPlayer = playerX; clearObstacles(); playerX = 2; obstacles[0] = {2, 7, true};
  state = PLAYING; collisionCheck(); ok &= state == GAME_OVER;
  clearObstacles(); playerX = savedPlayer; state = TITLE;
  Serial.printf("Logic checks: %s (bounds, difficulty clamp, collision path)\n", ok ? "PASS" : "FAIL");
  return ok;
}
void printMenu() {
  Serial.println("Commands: d=dodge, p=pixel demo, j=joystick, t=tilt, c=tilt recalibrate, x=toggle X, y=toggle Y, m=matrix mirror, f=matrix flip.");
  Serial.println("Matrix output is compiled OFF unless POCKET_ENABLE_VERIFIED_MATRIX=1 was explicitly approved.");
}
void handleSerial(uint32_t now) {
  while (Serial.available()) {
    char c = tolower((unsigned char)Serial.read());
    if (c == 'd') { mode = DODGE_GAME; state = TITLE; dirty = true; }
    if (c == 'p') { mode = PIXEL_DEMO; dirty = true; }
    if (c == 'j') { controlMode = JOYSTICK_CONTROL; dirty = true; }
    if (c == 't') { if (mpuPresent) { controlMode = TILT_CONTROL; calibrateTilt(); } else Serial.println("MPU absent: joystick retained."); }
    if (c == 'c') calibrateTilt();
    if (c == 'x') { invertX = !invertX; Serial.println("X inversion toggled."); }
    if (c == 'y') { invertY = !invertY; Serial.println("Y inversion toggled."); }
    if (c == 'm') { mirrorMatrixX = !mirrorMatrixX; dirty = true; }
    if (c == 'f') { flipMatrixY = !flipMatrixY; dirty = true; }
    if (c == '?') printMenu();
  }
}
void updateGame(uint32_t now) {
  if (state == COUNTDOWN && now - stateStarted >= COUNTDOWN_MS) beginPlaying(now);
  if (state != PLAYING) return;
  uint32_t interval = fallInterval(now); uint32_t steps = 0;
  while (now - lastFall >= interval && steps++ < MAX_CATCHUP_STEPS && state == PLAYING) {
    lastFall += interval;
    for (auto &o : obstacles) if (o.active) {
      o.y++;
      if (o.y > 7) { o.active = false; ++score; dirty = true; }
    }
    collisionCheck();
    if (state == PLAYING && random(0, 100) < 55) spawnObstacle();
    interval = fallInterval(now);
  }
}
void setup() {
  Serial.begin(115200); delay(100);
  pinMode(JOY_CLICK_PIN, INPUT_PULLUP); pinMode(START_BUTTON_PIN, INPUT_PULLUP);
  analogReadResolution(12); calibrateJoystick();
  // Safe build keeps these potentially unsafe MAX7219 signals high impedance.
  pinMode(MATRIX_CS_PIN, INPUT); pinMode(MATRIX_DIN_PIN, INPUT); pinMode(MATRIX_CLK_PIN, INPUT);
  Wire.begin(I2C_SDA_PIN, I2C_SCL_PIN, 100000);
  oledPresent = i2cExists(OLED_ADDR);
  if (oledPresent) oledPresent = oled.begin(SSD1306_SWITCHCAPVCC, OLED_ADDR);
  mpuPresent = i2cExists(MPU_ADDR);
  if (mpuPresent) { mpuWrite(0x6B, 0); calibrateTilt(); }
#ifdef POCKET_ENABLE_VERIFIED_MATRIX
  matrix.begin(); matrix.control(MD_MAX72XX::INTENSITY, 2); matrix.clear();
#endif
  prefs.begin("pocketarc", false); highScore = prefs.getUInt("high", 0);
  randomSeed((uint32_t)micros()); logicChecks(); printMenu();
  Serial.printf("OLED: %s, MPU-6050: %s, Matrix outputs: %s\n", oledPresent ? "found" : "not found", mpuPresent ? "found" : "not found", MATRIX_OUTPUT_ENABLED ? "ENABLED" : "SAFE/OFF");
}
void loop() {
  uint32_t now = millis(); handleSerial(now);
  if (pressedEdge(START_BUTTON_PIN, lastStartRaw, startStable, startChanged, now) && mode == DODGE_GAME) resetRound(now);
  if (pressedEdge(JOY_CLICK_PIN, lastClickRaw, clickStable, clickChanged, now)) {
    if (mode == PIXEL_DEMO) { mode = DODGE_GAME; state = TITLE; dirty = true; }
    else if (state == PLAYING || state == PAUSED) togglePause(now);
  }
  if (now - lastMove >= REPEAT_MS) {
    int horizontal = controlMode == TILT_CONTROL ? tiltDirection() : joystickDirection();
    if (mode == PIXEL_DEMO) { movePixel(horizontal, joystickVertical()); }
    else if (state == PLAYING) movePlayer(horizontal);
    lastMove = now;
  }
  updateGame(now);
  if (now - lastFrame >= FRAME_MS) { lastFrame = now; drawDisplay(now); }
}
