This project turns an M5StickS3 into a badminton coaching tool that analyzes your high-clear swing technique. Mount the device on your racket handle, perform a reference swing to establish your form, then execute test swings to receive real-time feedback on your motion consistency. The guide includes a wiring diagram, parts list, complete firmware with WiFi and MQTT connectivity, and step-by-step assembly instructions.

The system captures motion data from the StickS3's built-in sensors and compares each swing against your reference template, scoring your technique on a 0-100 scale. Firmware handles WiFi connection, MQTT communication with a camera system for enhanced analysis, and displays results on the device's screen. Perfect for players looking to refine their stroke mechanics with objective, repeatable measurements.

Wiring diagram

Interactive · read-only

Pan and zoom to explore the wiring. Remix the project to edit it in your own workspace.

Assembly

3 steps

01
Charge and inspect the StickS3
Charge the M5Stack StickS3 through its USB-C port. No external sensor, resistor, or jumper wire is required because the BMI270 motion sensor and display are built into the board.
- Tip: Use the board's built-in screen and two front buttons only.
- ⚠ Do not open the case or connect anything to the exposed header for this project.
02
Mount it on the racket handle
Secure the StickS3 tightly along the racket handle using a non-slip strap, tape, or a small holder. Put the screen facing the same direction every time, preferably facing the player, and keep the board from shifting.
- Tip: Mount it below the grip area so it does not interfere with the hand.
- Tip: A firm mount is essential: a loose board measures vibration rather than racket motion.
- ⚠ Do not cover the USB-C port if charging is needed.
- ⚠ Stop using the setup if it could detach during a swing.
03
Use a consistent reference swing
Stand in a clear area. For both learning and testing, hold the racket and make the ready-racket, backswing, and forward-swing phases in the same orientation and at a safe, controlled pace.
- Tip: Make the learning example your intended good technique; later scores measure similarity to that example.
- ⚠ Leave enough clearance around you before swinging the racket.

Firmware

ESP32

src/main.cppDeploy to device

#include <Arduino.h>
#include <M5Unified.h>
#include <Preferences.h>
#include <WiFi.h>
#include <PubSubClient.h>

// Badminton high-clear motion coach for M5StickS3.
// Secure the device to the racket handle and keep its orientation unchanged.

// ---------- Wi-Fi and MQTT constants ----------

enum ScreenMode { HOME, TRAIN, WAIT_CAMERA, CAPTURING, RESULT };


// Forward declarations
void drawHeader(const char* title);
void drawNetworkStatus();
void drawHome();
void readTemplate();
void saveTemplate();
void beep();
void captureFeatures(float out[4]);
void drawTrainPrompt();
void drawWaitCamera();
int compareStage(const float ref[4], const float test[4]);
void publishFinalScore();
void drawResults();
bool publishStickCode(int code);
void mqttCallback(char* topic, byte* payload, unsigned int length);
void maintainNetwork();
void startCameraCapture();

const char* WIFI_SSID = "Curioo002";
const char* WIFI_PASSWORD = "2024Curioo0808";

const char* MQTT_SERVER = "192.168.0.192";
const uint16_t MQTT_PORT = 1883;
const char* MQTT_CLIENT_ID = "m5stick-s3-clear-coach";
const char* MQTT_USERNAME = "siot";
const char* MQTT_PASSWORD = "dfrobot";

// MQTT coordination protocol.
const char* TOPIC_CAM = "siot/cam";          // Subscribe: camera sends 2, 4, then 6.
const char* TOPIC_STICK = "Siot/stick";      // Publish: StickS3 sends 1, 3, then 5.
const char* TOPIC_SCORE = "siot/score";      // Publish final total score (0 to 100).
const char* TOPIC_AI_SCORE = "siot/ai/score"; // Subscribe: AI confidence, 0.00 to 1.00.
const float AI_CONFIDENCE_THRESHOLD = 0.80f;

const uint16_t SAMPLE_HZ = 50;
const uint16_t CAPTURE_MS = 1400;
const uint16_t BEEP_FREQUENCY_HZ = 2400;
const uint16_t BEEP_DURATION_MS = 120;
const uint8_t STAGES = 3;
const char* stageName[STAGES] = {"1 Ready racket", "2 Backswing", "3 Forward swing"};



Preferences prefs;
WiFiClient wifiClient;
PubSubClient mqttClient(wifiClient);
ScreenMode mode = HOME;
uint8_t stage = 0;
float learned[STAGES][4];
float measured[STAGES][4];
int stageScore[STAGES] = {0, 0, 0};
bool templateReady = false;
int pendingCameraCommand = 0;
float pendingAiConfidence = 0.0f;
bool aiConfidenceReceived = false;
uint32_t lastWifiAttempt = 0;
uint32_t lastMqttAttempt = 0;

void drawHeader(const char* title) {
  M5.Display.fillScreen(TFT_BLACK);
  M5.Display.setTextColor(TFT_CYAN, TFT_BLACK);
  M5.Display.setTextSize(2);
  M5.Display.setCursor(4, 3);
  M5.Display.print(title);
  M5.Display.drawFastHLine(0, 24, M5.Display.width(), TFT_DARKGREY);
  M5.Display.setTextColor(TFT_WHITE, TFT_BLACK);
}

void drawNetworkStatus() {
  M5.Display.setTextSize(1);
  M5.Display.fillRect(0, 120, M5.Display.width(), 15, TFT_BLACK);
  M5.Display.setCursor(4, 122);
  M5.Display.setTextColor(WiFi.status() == WL_CONNECTED ? TFT_GREEN : TFT_RED, TFT_BLACK);
  M5.Display.print(WiFi.status() == WL_CONNECTED ? "WiFi: connected" : "WiFi: offline");
  M5.Display.setCursor(133, 122);
  M5.Display.setTextColor(mqttClient.connected() ? TFT_GREEN : TFT_RED, TFT_BLACK);
  M5.Display.print(mqttClient.connected() ? "MQTT: connected" : "MQTT: offline");
  M5.Display.setTextColor(TFT_WHITE, TFT_BLACK);
}

void drawHome() {
  drawHeader("Badminton Trainer");
  M5.Display.setTextSize(1);
  M5.Display.setCursor(4, 34);
  M5.Display.println("Mount firmly; keep orientation.");
  M5.Display.setTextColor(TFT_YELLOW, TFT_BLACK);
  M5.Display.setCursor(4, 57);
  M5.Display.println("A: learn three phases");
  M5.Display.println("B: request camera test");
  M5.Display.setTextColor(templateReady ? TFT_GREEN : TFT_ORANGE, TFT_BLACK);
  M5.Display.setCursor(4, 88);
  M5.Display.println(templateReady ? "Template saved" : "No template: learn first");
  M5.Display.setTextColor(TFT_CYAN, TFT_BLACK);
  M5.Display.setCursor(4, 102);
  M5.Display.println("Test flow: B->1, cam 2/4/6");
  drawNetworkStatus();
}

void readTemplate() {
  prefs.begin("clearcoach", true);
  templateReady = prefs.getBool("ready", false);
  if (templateReady) {
    for (uint8_t s = 0; s < STAGES; s++) {
      for (uint8_t f = 0; f < 4; f++) {
        char key[8];
        snprintf(key, sizeof(key), "t%u%u", s, f);
        learned[s][f] = prefs.getFloat(key, 0.0f);
      }
    }
  }
  prefs.end();
}

void saveTemplate() {
  prefs.begin("clearcoach", false);
  for (uint8_t s = 0; s < STAGES; s++) {
    for (uint8_t f = 0; f < 4; f++) {
      char key[8];
      snprintf(key, sizeof(key), "t%u%u", s, f);
      prefs.putFloat(key, learned[s][f]);
    }
  }
  prefs.putBool("ready", true);
  prefs.end();
  templateReady = true;
}

void beep() {
  M5.Speaker.tone(BEEP_FREQUENCY_HZ, BEEP_DURATION_MS);
}

void captureFeatures(float out[4]) {
  float sumX = 0, sumY = 0, sumZ = 0, peak = 0;
  uint16_t count = 0;
  uint32_t nextSample = millis();
  uint32_t endTime = millis() + CAPTURE_MS;
  while ((int32_t)(millis() - endTime) < 0) {
    M5.update();
    if (mqttClient.connected()) mqttClient.loop();
    if ((int32_t)(millis() - nextSample) >= 0) {
      nextSample += 1000 / SAMPLE_HZ;
      float gx, gy, gz;
      M5.Imu.getGyro(&gx, &gy, &gz);
      sumX += fabsf(gx);
      sumY += fabsf(gy);
      sumZ += fabsf(gz);
      float total = sqrtf(gx * gx + gy * gy + gz * gz);
      if (total > peak) peak = total;
      count++;
      int remain = (int)(endTime - millis());
      M5.Display.fillRect(4, 101, 180, 15, TFT_BLACK);
      M5.Display.setCursor(4, 101);
      M5.Display.setTextSize(1);
      M5.Display.printf("Recording %1.1fs", max(0, remain) / 1000.0f);
    }
    delay(1);
  }
  out[0] = sumX / count;
  out[1] = sumY / count;
  out[2] = sumZ / count;
  out[3] = peak;
}

void drawTrainPrompt() {
  drawHeader("LEARN MODE");
  M5.Display.setTextSize(2);
  M5.Display.setCursor(4, 35);
  M5.Display.print(stageName[stage]);
  M5.Display.setTextSize(1);
  M5.Display.setCursor(4, 66);
  M5.Display.println("Prepare this pose/motion.");
  M5.Display.println("Press A, then move for 1.4 s.");
  drawNetworkStatus();
}

void drawWaitCamera() {
  drawHeader("CAMERA TEST");
  M5.Display.setTextSize(2);
  M5.Display.setCursor(4, 37);
  M5.Display.print("Waiting cam");
  M5.Display.setTextSize(1);
  M5.Display.setCursor(4, 68);
  M5.Display.printf("Cam %d + AI > %.2f", stage == 0 ? 2 : (stage == 1 ? 4 : 6), AI_CONFIDENCE_THRESHOLD);
  M5.Display.setCursor(4, 83);
  M5.Display.print(stageName[stage]);
  M5.Display.setCursor(4, 96);
  if (aiConfidenceReceived) {
    M5.Display.printf("AI confidence: %.2f", pendingAiConfidence);
  } else {
    M5.Display.print("Waiting AI confidence");
  }
  M5.Display.setCursor(4, 108);
  M5.Display.print("B: cancel test");
  drawNetworkStatus();
}

int compareStage(const float ref[4], const float test[4]) {
  float error = 0;
  for (uint8_t i = 0; i < 4; i++) {
    float scale = max(ref[i], 12.0f);
    error += min(fabsf(test[i] - ref[i]) / scale, 2.0f);
  }
  return constrain((int)lroundf(100.0f - error * 24.0f), 0, 100);
}

void publishFinalScore() {
  if (!mqttClient.connected()) return;
  int total = (stageScore[0] + stageScore[1] + stageScore[2]) / 3;
  char message[4];
  snprintf(message, sizeof(message), "%d", total);
  mqttClient.publish(TOPIC_SCORE, message);
}

void drawResults() {
  drawHeader("SCORE");
  int total = (stageScore[0] + stageScore[1] + stageScore[2]) / 3;
  M5.Display.setTextSize(3);
  M5.Display.setTextColor(total >= 75 ? TFT_GREEN : (total >= 55 ? TFT_YELLOW : TFT_RED), TFT_BLACK);
  M5.Display.setCursor(34, 32);
  M5.Display.printf("%d/100", total);
  M5.Display.setTextSize(1);
  M5.Display.setTextColor(TFT_WHITE, TFT_BLACK);
  for (uint8_t i = 0; i < STAGES; i++) {
    M5.Display.setCursor(4, 70 + i * 13);
    M5.Display.printf("%s: %d", stageName[i], stageScore[i]);
  }
  M5.Display.setTextColor(TFT_CYAN, TFT_BLACK);
  M5.Display.setCursor(4, 110);
  M5.Display.print("Score sent: siot/score");
  drawNetworkStatus();
}

bool publishStickCode(int code) {
  if (!mqttClient.connected()) return false;
  char text[2] = {(char)('0' + code), '\0'};
  return mqttClient.publish(TOPIC_STICK, text);
}

void mqttCallback(char* topic, byte* payload, unsigned int length) {
  if (length == 0 || length > 15) return;
  char message[16];
  memcpy(message, payload, length);
  message[length] = '\0';

  if (strcmp(topic, TOPIC_CAM) == 0) {
    int value = atoi(message);
    if (value == 2 || value == 4 || value == 6) pendingCameraCommand = value;
  } else if (strcmp(topic, TOPIC_AI_SCORE) == 0) {
    char* endPtr = nullptr;
    float confidence = strtof(message, &endPtr);
    if (endPtr != message && confidence >= 0.0f && confidence <= 1.0f) {
      pendingAiConfidence = roundf(confidence * 100.0f) / 100.0f;
      aiConfidenceReceived = true;
      if (mode == WAIT_CAMERA) drawWaitCamera();
    }
  }
}

void maintainNetwork() {
  uint32_t now = millis();
  if (WiFi.status() != WL_CONNECTED) {
    if (now - lastWifiAttempt >= 5000) {
      lastWifiAttempt = now;
      WiFi.begin(WIFI_SSID, WIFI_PASSWORD);
    }
    return;
  }
  if (!mqttClient.connected() && now - lastMqttAttempt >= 3000) {
    lastMqttAttempt = now;
    bool connected = MQTT_USERNAME[0] ?
      mqttClient.connect(MQTT_CLIENT_ID, MQTT_USERNAME, MQTT_PASSWORD) :
      mqttClient.connect(MQTT_CLIENT_ID);
    if (connected) {
      mqttClient.subscribe(TOPIC_CAM);
      mqttClient.subscribe(TOPIC_AI_SCORE);
      if (mode == HOME) drawHome();
    }
  }
  if (mqttClient.connected()) mqttClient.loop();
}

void startCameraCapture() {
  int expected = stage == 0 ? 2 : (stage == 1 ? 4 : 6);
  if (pendingCameraCommand != expected || mode != WAIT_CAMERA) return;
  if (!aiConfidenceReceived || pendingAiConfidence <= AI_CONFIDENCE_THRESHOLD) return;
  pendingCameraCommand = 0;
  aiConfidenceReceived = false;  // Require a new AI confidence for the next phase.
  pendingAiConfidence = 0.0f;
  mode = CAPTURING;
  drawHeader("CAMERA TEST");
  M5.Display.setTextSize(2);
  M5.Display.setCursor(4, 35);
  M5.Display.print(stageName[stage]);
  M5.Display.setTextSize(1);
  M5.Display.setCursor(4, 66);
  M5.Display.println("Camera confirmed: capture now.");
  captureFeatures(measured[stage]);
  stageScore[stage] = compareStage(learned[stage], measured[stage]);
  beep();

  if (stage == 0) {
    publishStickCode(3);
    stage = 1;
    mode = WAIT_CAMERA;
    drawWaitCamera();
  } else if (stage == 1) {
    publishStickCode(5);
    stage = 2;
    mode = WAIT_CAMERA;
    drawWaitCamera();
  } else {
    mode = RESULT;
    publishFinalScore();
    drawResults();
  }
}

void setup() {
  auto cfg = M5.config();
  M5.begin(cfg);
  M5.Display.setRotation(1);
  mqttClient.setServer(MQTT_SERVER, MQTT_PORT);
  mqttClient.setCallback(mqttCallback);
  WiFi.mode(WIFI_STA);
  WiFi.begin(WIFI_SSID, WIFI_PASSWORD);
  readTemplate();
  drawHome();
}

void loop() {
  M5.update();
  maintainNetwork();

  if (mode == HOME) {
    if (M5.BtnA.wasPressed()) {
      mode = TRAIN;
      stage = 0;
      drawTrainPrompt();
    } else if (M5.BtnB.wasPressed()) {
      if (!templateReady) {
        M5.Display.setTextColor(TFT_RED, TFT_BLACK);
        M5.Display.setCursor(4, 110);
        M5.Display.print("Learn a template first.");
      } else if (!publishStickCode(1)) {
        M5.Display.setTextColor(TFT_RED, TFT_BLACK);
        M5.Display.setCursor(4, 110);
        M5.Display.print("MQTT offline: cannot send 1");
      } else {
        stage = 0;
        pendingCameraCommand = 0;
        pendingAiConfidence = 0.0f;
        aiConfidenceReceived = false;
        mode = WAIT_CAMERA;
        drawWaitCamera();
      }
    }
  } else if (mode == TRAIN && M5.BtnA.wasPressed()) {
    captureFeatures(learned[stage]);
    stage++;
    if (stage == STAGES) {
      saveTemplate();
      mode = HOME;
      drawHome();
    } else {
      drawTrainPrompt();
    }
  } else if (mode == WAIT_CAMERA) {
    if (M5.BtnB.wasPressed()) {
      pendingCameraCommand = 0;
      pendingAiConfidence = 0.0f;
      aiConfidenceReceived = false;
      mode = HOME;
      drawHome();
    } else {
      startCameraCapture();
    }
  } else if (mode == RESULT && M5.BtnB.wasPressed()) {
    mode = HOME;
    drawHome();
  }

  if (mode == HOME && (millis() % 1000) < 10) drawNetworkStatus();
  delay(8);
}

“Deploy to device” opens this project in Schematik, where you can flash it to your board over USB.

Remix this project

Make it yours in one click

Open a full copy of this project in your own Schematik workspace — diagram, code, parts, and assembly steps included. Swap the sensor, add features, or redesign the whole thing with AI. The author's original stays untouched.

Open in Schematik

Wiring diagram

Assembly

Charge and inspect the StickS3

Mount it on the racket handle

Use a consistent reference swing

Firmware

Make it yours in one click
