Reckless Driver

#include <Arduino.h>
#include <Wire.h>
#include <Adafruit_GFX.h>
#include <Adafruit_SSD1306.h>


struct Obstacle {
  float z;
  float lane;
};


// Forward declarations
int16_t roadCenterAt(int16_t y, float curve);
int16_t roadHalfWidthAt(int16_t y);
void resetObstacle(Obstacle &obstacle, float startZ);
void resetGame();
void drawRoad(float curve);
void drawRoadsidePosts(float curve);
void drawObstacleCar(int16_t x, int16_t y, int16_t size);
void drawObstacles(float curve);
void drawPlayerCar(float curve);
void drawGameOver();
void drawStartScreen();
void drawFrame();
void updateSteering(uint32_t now, bool leftPressed, bool rightPressed);
bool collidedWithObstacle();
void updateObstacles();

constexpr int OLED_SDA = 21;
constexpr int OLED_SCL = 22;
constexpr int LEFT_BUTTON_PIN = 25;
constexpr int RIGHT_BUTTON_PIN = 26;
constexpr uint8_t OLED_ADDRESS = 0x3C;
constexpr int SCREEN_WIDTH = 128;
constexpr int SCREEN_HEIGHT = 64;
constexpr int HORIZON_Y = 19;
constexpr int ROAD_BOTTOM_Y = 63;
constexpr uint32_t FRAME_INTERVAL_MS = 50;
constexpr uint32_t STEER_REPEAT_MS = 140;
constexpr uint8_t OBSTACLE_COUNT = 2;
constexpr uint8_t START_SPEED_MPH = 55;

Adafruit_SSD1306 display(SCREEN_WIDTH, SCREEN_HEIGHT, &Wire, -1);



Obstacle obstacles[OBSTACLE_COUNT];
uint32_t lastFrameMs = 0;
uint32_t lastSteerMoveMs = 0;
float drivePhase = 0.0f;
float playerLane = 0.0f;
float distanceMiles = 0.0f;
uint8_t currentSpeedMph = START_SPEED_MPH;
float nextSpeedMilestoneMiles = 0.1f;
bool gameOver = false;
bool startScreen = true;
bool previousLeftPressed = false;
bool previousRightPressed = false;

int16_t roadCenterAt(int16_t y, float curve) {
  const float depth = float(y - HORIZON_Y) / float(ROAD_BOTTOM_Y - HORIZON_Y);
  return int16_t(64.0f + curve * depth * depth);
}

int16_t roadHalfWidthAt(int16_t y) {
  const float depth = float(y - HORIZON_Y) / float(ROAD_BOTTOM_Y - HORIZON_Y);
  return int16_t(7.0f + 53.0f * depth);
}

void resetObstacle(Obstacle &obstacle, float startZ) {
  obstacle.z = startZ;
  obstacle.lane = float(random(-68, 69)) / 100.0f;
}

void resetGame() {
  playerLane = 0.0f;
  drivePhase = 0.0f;
  distanceMiles = 0.0f;
  currentSpeedMph = START_SPEED_MPH;
  nextSpeedMilestoneMiles = 0.1f;
  // Keep the two cars far apart so the road has time to breathe.
  resetObstacle(obstacles[0], 0.18f);
  resetObstacle(obstacles[1], 0.68f);
  gameOver = false;
}

void drawRoad(float curve) {
  const int16_t horizonCenter = roadCenterAt(HORIZON_Y, curve);
  const int16_t bottomCenter = roadCenterAt(ROAD_BOTTOM_Y, curve);
  const int16_t bottomHalfWidth = roadHalfWidthAt(ROAD_BOTTOM_Y);
  display.drawLine(horizonCenter, HORIZON_Y, bottomCenter - bottomHalfWidth, ROAD_BOTTOM_Y, SSD1306_WHITE);
  display.drawLine(horizonCenter, HORIZON_Y, bottomCenter + bottomHalfWidth, ROAD_BOTTOM_Y, SSD1306_WHITE);

  for (int i = 0; i < 7; ++i) {
    float z = fmodf(drivePhase * 0.48f + i * 0.16f, 1.0f);
    if (z < 0.08f) z += 0.92f;
    const float z2 = z * z;
    const int16_t y = int16_t(HORIZON_Y + z2 * (ROAD_BOTTOM_Y - HORIZON_Y));
    const int16_t dashLength = int16_t(1 + 8 * z2);
    const int16_t center = roadCenterAt(y, curve);
    display.drawLine(center, y, center, min<int16_t>(ROAD_BOTTOM_Y, y + dashLength), SSD1306_WHITE);
  }
}

void drawRoadsidePosts(float curve) {
  for (int i = 0; i < 5; ++i) {
    const float z = fmodf(drivePhase * 0.34f + i * 0.23f, 1.0f);
    const float z2 = z * z;
    const int16_t y = int16_t(HORIZON_Y + z2 * (ROAD_BOTTOM_Y - HORIZON_Y));
    const int16_t height = int16_t(2 + 9 * z2);
    const int16_t width = int16_t(1 + 3 * z2);
    const int16_t center = roadCenterAt(y, curve);
    const int16_t edge = roadHalfWidthAt(y);
    display.fillRect(center - edge - 5 - width, y - height, width, height, SSD1306_WHITE);
    display.fillRect(center + edge + 5, y - height, width, height, SSD1306_WHITE);
  }
}

void drawObstacleCar(int16_t x, int16_t y, int16_t size) {
  // A rear-view car silhouette that grows as it approaches.
  const int16_t width = max<int16_t>(5, size * 2 + 2);
  const int16_t height = max<int16_t>(4, size + 3);
  display.drawRoundRect(x - width / 2, y - height / 2, width, height, 1, SSD1306_WHITE);
  display.drawFastHLine(x - width / 2 + 1, y, width - 2, SSD1306_WHITE);
  display.drawPixel(x - width / 2 + 1, y + height / 2 - 1, SSD1306_WHITE);
  display.drawPixel(x + width / 2 - 2, y + height / 2 - 1, SSD1306_WHITE);
}

void drawObstacles(float curve) {
  for (uint8_t i = 0; i < OBSTACLE_COUNT; ++i) {
    const float z2 = obstacles[i].z * obstacles[i].z;
    const int16_t y = int16_t(HORIZON_Y + z2 * (ROAD_BOTTOM_Y - HORIZON_Y));
    const int16_t edge = roadHalfWidthAt(y);
    const int16_t x = roadCenterAt(y, curve) + int16_t(obstacles[i].lane * (edge - 3));
    const int16_t size = max<int16_t>(2, int16_t(2 + 5 * z2));
    drawObstacleCar(x, y, size);
  }
}

void drawPlayerCar(float curve) {
  constexpr int16_t CAR_Y = 56;
  const int16_t roadCenter = roadCenterAt(CAR_Y, curve);
  const int16_t carTravel = roadHalfWidthAt(CAR_Y) - 9;
  const int16_t x = roadCenter + int16_t(playerLane * carTravel);
  display.fillTriangle(x, CAR_Y - 7, x - 8, CAR_Y + 6, x + 8, CAR_Y + 6, SSD1306_WHITE);
  display.drawFastHLine(x - 11, CAR_Y + 7, 23, SSD1306_WHITE);
  display.drawFastVLine(x - 8, CAR_Y + 5, 3, SSD1306_WHITE);
  display.drawFastVLine(x + 8, CAR_Y + 5, 3, SSD1306_WHITE);
}

void drawGameOver() {
  display.clearDisplay();
  display.drawRect(1, 1, 126, 62, SSD1306_WHITE);
  display.setTextColor(SSD1306_WHITE);
  display.setTextSize(2);
  display.setCursor(15, 15);
  display.print("GAME OVER");
  display.setTextSize(1);
  display.setCursor(30, 39);
  display.print("SCORE: ");
  display.print(distanceMiles, 1);
  display.print(" MI");
  display.setCursor(17, 52);
  display.print("PRESS A BUTTON");
  display.display();
}

void drawStartScreen() {
  display.clearDisplay();
  display.setTextColor(SSD1306_WHITE);
  display.setTextSize(2);
  display.setCursor(8, 5);
  display.print("RECKLESS");
  display.setCursor(29, 22);
  display.print("DRIVER");

  // Lower side-view car, leaving the title screen free of instructions.
  display.drawRoundRect(23, 49, 82, 9, 3, SSD1306_WHITE);
  display.fillRect(40, 45, 43, 5, SSD1306_WHITE);
  display.drawLine(47, 45, 54, 41, SSD1306_WHITE);
  display.drawLine(54, 41, 72, 41, SSD1306_WHITE);
  display.drawLine(72, 41, 80, 45, SSD1306_WHITE);
  display.fillCircle(39, 58, 4, SSD1306_WHITE);
  display.fillCircle(89, 58, 4, SSD1306_WHITE);
  display.fillCircle(39, 58, 1, SSD1306_BLACK);
  display.fillCircle(89, 58, 1, SSD1306_BLACK);
  display.display();
}

void drawFrame() {
  const float curve = sinf(drivePhase * 0.75f) * 12.0f;
  display.clearDisplay();
  display.drawLine(0, HORIZON_Y, SCREEN_WIDTH - 1, HORIZON_Y, SSD1306_WHITE);
  drawRoad(curve);
  drawRoadsidePosts(curve);
  drawObstacles(curve);
  drawPlayerCar(curve);
  display.setTextColor(SSD1306_WHITE);
  display.setTextSize(1);
  display.setCursor(2, 2);
  display.print(distanceMiles, 1);
  display.print(" MI");
  display.setCursor(91, 2);
  display.print(currentSpeedMph);
  display.print(" MPH");
  display.display();
}

void updateSteering(uint32_t now, bool leftPressed, bool rightPressed) {
  if (leftPressed != rightPressed && now - lastSteerMoveMs >= STEER_REPEAT_MS) {
    playerLane += leftPressed ? -0.12f : 0.12f;
    playerLane = constrain(playerLane, -0.86f, 0.86f);
    lastSteerMoveMs = now;
  }
}

bool collidedWithObstacle() {
  for (uint8_t i = 0; i < OBSTACLE_COUNT; ++i) {
    if (obstacles[i].z > 0.80f && obstacles[i].z < 0.98f && fabsf(playerLane - obstacles[i].lane) < 0.25f) return true;
  }
  return false;
}

void updateObstacles() {
  for (uint8_t i = 0; i < OBSTACLE_COUNT; ++i) {
    obstacles[i].z += 0.010f;
    // Start well beyond the horizon after a pass to create a long clear gap.
    if (obstacles[i].z >= 1.05f) {
      resetObstacle(obstacles[i], float(random(-32, -16)) / 100.0f);
    }
  }
}

void setup() {
  pinMode(LEFT_BUTTON_PIN, INPUT_PULLUP);
  pinMode(RIGHT_BUTTON_PIN, INPUT_PULLUP);
  Wire.begin(OLED_SDA, OLED_SCL);
  if (!display.begin(SSD1306_SWITCHCAPVCC, OLED_ADDRESS)) while (true) delay(1000);
  randomSeed(micros());
  resetGame();
  startScreen = true;
  drawStartScreen();
}

void loop() {
  const uint32_t now = millis();
  const bool leftPressed = digitalRead(LEFT_BUTTON_PIN) == LOW;
  const bool rightPressed = digitalRead(RIGHT_BUTTON_PIN) == LOW;

  if (startScreen) {
    if (leftPressed || rightPressed) {
      resetGame();
      startScreen = false;
      lastFrameMs = now;
      lastSteerMoveMs = now;
    }
    previousLeftPressed = leftPressed;
    previousRightPressed = rightPressed;
    delay(20);
    return;
  }

  if (gameOver) {
    const bool newPress = (leftPressed && !previousLeftPressed) || (rightPressed && !previousRightPressed);
    if (newPress) resetGame();
    else drawGameOver();
    previousLeftPressed = leftPressed;
    previousRightPressed = rightPressed;
    delay(20);
    return;
  }

  if (now - lastFrameMs >= FRAME_INTERVAL_MS) {
    const uint32_t elapsedMs = now - lastFrameMs;
    lastFrameMs = now;
    updateSteering(now, leftPressed, rightPressed);
    distanceMiles += (float(currentSpeedMph) * float(elapsedMs)) / 3600000.0f;
    // Each completed tenth of a mile permanently adds 1 MPH for this run.
    while (distanceMiles >= nextSpeedMilestoneMiles) {
      ++currentSpeedMph;
      nextSpeedMilestoneMiles += 0.1f;
    }
    drivePhase += 0.035f;
    updateObstacles();
    if (collidedWithObstacle()) gameOver = true;
    else drawFrame();
  }
  previousLeftPressed = leftPressed;
  previousRightPressed = rightPressed;
}
