Scrolling Hello World Display

#include <Arduino.h>
#include <Wire.h>
#include <LiquidCrystal_I2C.h>

constexpr int SDA_PIN = 21;
constexpr int SCL_PIN = 22;
constexpr uint8_t LCD_COLUMNS = 16;
constexpr int X_PIN = 34;
constexpr int Y_PIN = 35;
constexpr int BUTTON_PIN = 32;
int centerX = 2048;
int centerY = 2048;
constexpr int DEAD_ZONE = 200;
constexpr bool INVERT_X = true;
constexpr bool INVERT_Y = true; // Achsentausch unten: rechts <-> oben, links <-> unten.
constexpr uint32_t UPDATE_INTERVAL_MS = 50;
constexpr uint32_t SHOT_COOLDOWN_MS = 500;
struct Object { int col; uint8_t row; uint8_t shape; bool active; };
Object rocks[8] = {};
Object shots[8] = {};
uint8_t playerRow = 0;
bool gameOver = false;
uint32_t score = 0;
uint32_t lastShot = 0, lastRockMove = 0, lastShotMove = 0, lastSpawn = 0;
uint8_t shipGlyph[8] = {16,24,28,31,28,24,16,0};
uint8_t rockGlyphA[8] = {0,14,31,27,31,14,0,0};
uint8_t rockGlyphB[8] = {4,14,29,31,23,14,4,0};
uint8_t rockGlyphC[8] = {0,10,31,14,31,10,0,0};
LiquidCrystal_I2C lcd(0x27, LCD_COLUMNS, 2);
char previousRows[2][LCD_COLUMNS] = {};
uint32_t lastUpdate = 0;
bool displayReady = false;
bool buttonRaw = false;
bool buttonPressed = false;
uint32_t buttonChangedAt = 0;

void renderRow(uint8_t row, const char* text) {
  const size_t length = strlen(text);
  for (uint8_t column = 0; column < LCD_COLUMNS; ++column) {
    const char nextChar = column < length ? text[column] : ' ';
    if (previousRows[row][column] != nextChar) {
      lcd.setCursor(column, row);
      lcd.write(static_cast<uint8_t>(nextChar));
      previousRows[row][column] = nextChar;
    }
  }
}

int readAxis(int pin) {
  uint32_t sum = 0;
  for (int i = 0; i < 8; ++i) sum += analogRead(pin);
  return static_cast<int>((sum + 4) / 8);
}

void resetGame(uint32_t now) {
  for (auto &r : rocks) r.active = false;
  for (auto &s : shots) s.active = false;
  playerRow = 0;
  score = 0;
  gameOver = false;
  lastShot = now - SHOT_COOLDOWN_MS;
  lastRockMove = lastShotMove = lastSpawn = now;
}

void checkHits() {
  for (auto &r : rocks) {
    if (!r.active) continue;
    for (auto &s : shots) {
      if (s.active && s.row == r.row && s.col == r.col) {
        r.active = s.active = false;
        ++score;
        break;
      }
    }
    if (r.active && r.col == 0 && r.row == playerRow) gameOver = true;
  }
}

void updateGame(uint32_t now) {
  if (gameOver) return;
  int dx = readAxis(X_PIN) - centerX;
  int dy = readAxis(Y_PIN) - centerY;
  if (INVERT_X) dx = -dx;
  if (INVERT_Y) dy = -dy;
  const int swappedX = dy;
  dy = dx;
  dx = swappedX;
  if (dy < -450) playerRow = 1;
  else if (dy > 450) playerRow = 0;
  checkHits();
  if (gameOver) return;
  if (dx > 450 && uint32_t(now - lastShot) >= SHOT_COOLDOWN_MS) {
    for (auto &s : shots) {
      if (!s.active) {
        s = {1, playerRow, 0, true};
        lastShot = now;
        break;
      }
    }
  }
  checkHits();
  if (uint32_t(now - lastShotMove) >= 100) {
    lastShotMove = now;
    for (auto &s : shots) if (s.active && ++s.col > 15) s.active = false;
    checkHits();
  }
  if (uint32_t(now - lastRockMove) >= 700) {
    lastRockMove = now;
    for (auto &r : rocks) if (r.active && --r.col < 0) r.active = false;
    checkHits();
  }
  if (!gameOver && uint32_t(now - lastSpawn) >= 1600) {
    lastSpawn = now;
    for (auto &r : rocks) {
      if (!r.active) {
        r = {15, static_cast<uint8_t>(random(2)), static_cast<uint8_t>(random(2, 5)), true};
        break;
      }
    }
    checkHits();
  }
}

void updateDisplay() {
  if (gameOver) {
    char line[17];
    snprintf(line, sizeof(line), "Treffer: %lu", static_cast<unsigned long>(score));
    renderRow(0, line);
    renderRow(1, "Knopf: Neustart");
    return;
  }
  char frame[2][17];
  for (int row = 0; row < 2; ++row) {
    memset(frame[row], ' ', 16);
    frame[row][16] = '\0';
  }
  frame[playerRow][0] = 1;
  for (const auto &s : shots) if (s.active) frame[s.row][s.col] = '-';
  for (const auto &r : rocks) if (r.active) frame[r.row][r.col] = r.shape;
  renderRow(0, frame[0]);
  renderRow(1, frame[1]);
}

void setup() {
  Serial.begin(115200);
  pinMode(X_PIN, INPUT);
  pinMode(Y_PIN, INPUT);
  pinMode(BUTTON_PIN, INPUT_PULLUP);
  analogReadResolution(12);
  analogSetPinAttenuation(X_PIN, ADC_11db);
  analogSetPinAttenuation(Y_PIN, ADC_11db);
  // Joystick beim Einschalten loslassen: eigene Mitte fuer jede Achse.
  delay(300);
  uint32_t sumX = 0, sumY = 0;
  for (int i = 0; i < 64; ++i) {
    sumX += readAxis(X_PIN);
    sumY += readAxis(Y_PIN);
    delay(5);
  }
  centerX = constrain(static_cast<int>(sumX / 64), DEAD_ZONE + 1, 4094 - DEAD_ZONE);
  centerY = constrain(static_cast<int>(sumY / 64), DEAD_ZONE + 1, 4094 - DEAD_ZONE);
  buttonRaw = buttonPressed = digitalRead(BUTTON_PIN) == LOW;
  Wire.begin(SDA_PIN, SCL_PIN);
  Wire.setClock(100000);
  Wire.beginTransmission(0x27);
  if (Wire.endTransmission() != 0) {
    Serial.println("Kein LCD an 0x27: Versorgung, SDA/SCL und Adresse pruefen.");
    return;
  }
  lcd.init();
  lcd.backlight();
  lcd.createChar(1, shipGlyph);
  lcd.createChar(2, rockGlyphA);
  lcd.createChar(3, rockGlyphB);
  lcd.createChar(4, rockGlyphC);
  lcd.clear(); // Nur einmal beim Start.
  randomSeed(micros() ^ analogRead(X_PIN));
  resetGame(millis());
  updateDisplay();
  displayReady = true;
  lastUpdate = millis();
}

void loop() {
  const uint32_t now = millis();
  const bool pressed = digitalRead(BUTTON_PIN) == LOW;
  if (pressed != buttonRaw) {
    buttonRaw = pressed;
    buttonChangedAt = now;
  }
  if (static_cast<uint32_t>(now - buttonChangedAt) >= 25 && buttonPressed != buttonRaw) {
    buttonPressed = buttonRaw;
    if (buttonPressed && gameOver) resetGame(now);
  }
  if (!displayReady) return;
  if (static_cast<uint32_t>(now - lastUpdate) >= UPDATE_INTERVAL_MS) {
    lastUpdate = now;
    updateGame(now);
    updateDisplay();
  }
}
