#include <Arduino.h>
#include <WiFi.h>
#include <WiFiUdp.h>
#include "unihiker_k10.h"
#include <lvgl.h>

// Experiment-box UNIHIKER K10 remote firmware.
// A = reverse, B = forward, P8 = left, P9 = right.
// Commands are unicast UDP packets to the Maqueen car. Releasing every input
// sends STOP; the car also stops itself if packets stop arriving.

UNIHIKER_K10 k10;
WiFiUDP controlUdp;

const char *WIFI_SSID = "ChinaNet-MGY-2.4G";
const char *WIFI_PASSWORD = "MGY!2024";
const IPAddress CAR_IP(192, 168, 1, 195);
const uint16_t CONTROL_PORT = 5000;
const uint32_t WIFI_RETRY_MS = 10000;
const uint32_t SEND_INTERVAL_MS = 50;
const uint32_t UI_REFRESH_MS = 250;
const int8_t DRIVE_PERCENT = 75;

lv_obj_t *wifiLabel;
lv_obj_t *ipLabel;
lv_obj_t *driveLabel;
lv_obj_t *videoLabel;
uint32_t lastWifiAttemptMs = 0;
uint32_t lastSendMs = 0;
uint32_t lastUiMs = 0;
bool lastWiFiConnected = false;
String lastIpText;
String lastDriveText;

// Local LVGL mutex for thread-safe UI access
static SemaphoreHandle_t xLvglMutex = NULL;

static void connectWiFiIfNeeded();
static uint8_t packetChecksum(const uint8_t *packet);
static void sendDrivePacket(int8_t throttle, int8_t steering);
static void readDriveInputs(int8_t &throttle, int8_t &steering);
static void createRemoteUi();
static void updateRemoteUi(bool force, int8_t throttle, int8_t steering);
static String driveDescription(int8_t throttle, int8_t steering);

static void connectWiFiIfNeeded() {
  if (WiFi.status() == WL_CONNECTED || millis() - lastWifiAttemptMs < WIFI_RETRY_MS) return;
  lastWifiAttemptMs = millis();
  WiFi.disconnect();
  WiFi.begin(WIFI_SSID, WIFI_PASSWORD);
  Serial.println("Connecting to Wi-Fi");
}

static uint8_t packetChecksum(const uint8_t *packet) {
  uint8_t value = 0;
  for (uint8_t i = 0; i < 7; ++i) value ^= packet[i];
  return value;
}

static void sendDrivePacket(int8_t throttle, int8_t steering) {
  // K1 packet layout is kept identical to the proven car receiver protocol.
  uint8_t packet[8] = {'K', '1', 1, 0, (uint8_t)throttle, (uint8_t)steering, 0, 0};
  packet[7] = packetChecksum(packet);
  if (WiFi.status() == WL_CONNECTED) {
    controlUdp.beginPacket(CAR_IP, CONTROL_PORT);
    controlUdp.write(packet, sizeof(packet));
    controlUdp.endPacket();
  }
}

static void readDriveInputs(int8_t &throttle, int8_t &steering) {
  // K10 buttons and the supplied directional inputs are active-low.
  const bool reversePressed = k10.buttonA->isPressed();
  const bool forwardPressed = k10.buttonB->isPressed();
  const bool leftPressed = (digital_read(eP8) == LOW);
  const bool rightPressed = (digital_read(eP9) == LOW);

  throttle = forwardPressed == reversePressed ? 0 : (forwardPressed ? DRIVE_PERCENT : -DRIVE_PERCENT);
  steering = rightPressed == leftPressed ? 0 : (rightPressed ? DRIVE_PERCENT : -DRIVE_PERCENT);
}

static String driveDescription(int8_t throttle, int8_t steering) {
  if (throttle == 0 && steering == 0) return "Drive: STOP\nRelease = stop";
  if (throttle > 0 && steering == 0) return "Drive: FORWARD\nB held";
  if (throttle < 0 && steering == 0) return "Drive: REVERSE\nA held";
  if (throttle == 0 && steering < 0) return "Drive: LEFT\nP8 held";
  if (throttle == 0 && steering > 0) return "Drive: RIGHT\nP9 held";
  if (throttle > 0 && steering < 0) return "Drive: FORWARD LEFT\nB + P8 held";
  if (throttle > 0 && steering > 0) return "Drive: FORWARD RIGHT\nB + P9 held";
  if (throttle < 0 && steering < 0) return "Drive: REVERSE LEFT\nA + P8 held";
  return "Drive: REVERSE RIGHT\nA + P9 held";
}

static void createRemoteUi() {
  // initScreen creates the K10 library's LVGL screen and display task.
  k10.initScreen(2);
  k10.setScreenBackground(0x001020);

  // Create the LVGL mutex if it hasn't been created yet.
  if (xLvglMutex == NULL) {
    xLvglMutex = xSemaphoreCreateMutex();
  }

  // The K10 display task also uses LVGL, so every UI update must hold its lock.
  xSemaphoreTake(xLvglMutex, portMAX_DELAY);
  lv_obj_t *screen = lv_scr_act();
  lv_obj_set_style_bg_color(screen, lv_color_hex(0x001020), LV_PART_MAIN);
  lv_obj_set_style_bg_opa(screen, LV_OPA_COVER, LV_PART_MAIN);
  lv_obj_set_style_text_font(screen, &lv_font_montserrat_14, LV_PART_MAIN);

  lv_obj_t *title = lv_label_create(screen);
  lv_label_set_long_mode(title, LV_LABEL_LONG_WRAP);
  lv_obj_set_width(title, 220);
  lv_label_set_text(title, "EXPERIMENT BOX\nCAR REMOTE");
  lv_obj_set_style_text_color(title, lv_color_white(), LV_PART_MAIN);
  lv_obj_align(title, LV_ALIGN_TOP_LEFT, 10, 8);

  wifiLabel = lv_label_create(screen);
  lv_label_set_long_mode(wifiLabel, LV_LABEL_LONG_WRAP);
  lv_obj_set_width(wifiLabel, 220);
  lv_obj_align(wifiLabel, LV_ALIGN_TOP_LEFT, 10, 52);

  ipLabel = lv_label_create(screen);
  lv_label_set_long_mode(ipLabel, LV_LABEL_LONG_WRAP);
  lv_obj_set_width(ipLabel, 220);
  lv_obj_align(ipLabel, LV_ALIGN_TOP_LEFT, 10, 78);

  driveLabel = lv_label_create(screen);
  lv_label_set_long_mode(driveLabel, LV_LABEL_LONG_WRAP);
  lv_obj_set_width(driveLabel, 220);
  lv_obj_align(driveLabel, LV_ALIGN_TOP_LEFT, 10, 122);

  videoLabel = lv_label_create(screen);
  lv_label_set_long_mode(videoLabel, LV_LABEL_LONG_WRAP);
  lv_obj_set_width(videoLabel, 220);
  lv_label_set_text(videoLabel, "Video UDP: 5001\nReceiver display: next step");
  lv_obj_set_style_text_color(videoLabel, lv_color_hex(0x9FC5FF), LV_PART_MAIN);
  lv_obj_align(videoLabel, LV_ALIGN_TOP_LEFT, 10, 184);

  // Give all initially-empty labels a visible colour before Wi-Fi starts.
  lv_obj_set_style_text_color(wifiLabel, lv_color_hex(0xFFC13D), LV_PART_MAIN);
  lv_obj_set_style_text_color(ipLabel, lv_color_white(), LV_PART_MAIN);
  lv_obj_set_style_text_color(driveLabel, lv_color_hex(0xFFC13D), LV_PART_MAIN);
  lv_label_set_text(wifiLabel, "WiFi: starting...");
  lv_label_set_text(ipLabel, "Box IP: waiting");
  lv_label_set_text(driveLabel, "Drive: STOP\nRelease = stop");
  lv_refr_now(NULL);
  xSemaphoreGive(xLvglMutex);
}

static void updateRemoteUi(bool force, int8_t throttle, int8_t steering) {
  const bool connected = WiFi.status() == WL_CONNECTED;
  const String ip = connected ? WiFi.localIP().toString() : "";
  const String driveText = driveDescription(throttle, steering);
  if (!force && connected == lastWiFiConnected && ip == lastIpText && driveText == lastDriveText &&
      millis() - lastUiMs < UI_REFRESH_MS) return;

  xSemaphoreTake(xLvglMutex, portMAX_DELAY);
  lv_label_set_text(wifiLabel, connected ? "WiFi: connected" : "WiFi: connecting...");
  lv_obj_set_style_text_color(wifiLabel, connected ? lv_color_hex(0x35D07F) : lv_color_hex(0xFFC13D), LV_PART_MAIN);
  const String ipText = connected ? "Box IP: " + ip + "\nCar UDP: .195:5000" : "Waiting for 2.4 GHz router";
  lv_label_set_text(ipLabel, ipText.c_str());
  lv_label_set_text(driveLabel, driveText.c_str());
  lv_obj_set_style_text_color(driveLabel, (throttle == 0 && steering == 0) ? lv_color_hex(0xFFC13D) : lv_color_hex(0x35D07F), LV_PART_MAIN);
  lv_refr_now(NULL);
  xSemaphoreGive(xLvglMutex);

  lastWiFiConnected = connected;
  lastIpText = ip;
  lastDriveText = driveText;
  lastUiMs = millis();
}

void setup() {
  Serial.begin(115200);
  k10.begin();
  createRemoteUi();

  // P8 and P9 are the experiment-box's active-low external direction inputs.
  pinMode(eP8, INPUT_PULLUP);
  pinMode(eP9, INPUT_PULLUP);

  WiFi.mode(WIFI_STA);
  lastWifiAttemptMs = millis() - WIFI_RETRY_MS;
  connectWiFiIfNeeded();
  controlUdp.begin(0);
  sendDrivePacket(0, 0);
  updateRemoteUi(true, 0, 0);
  Serial.println("Experiment-box UDP remote ready");
}

void loop() {
  connectWiFiIfNeeded();

  int8_t throttle = 0;
  int8_t steering = 0;
  readDriveInputs(throttle, steering);

  if (millis() - lastSendMs >= SEND_INTERVAL_MS) {
    lastSendMs = millis();
    sendDrivePacket(throttle, steering);
  }

  updateRemoteUi(false, throttle, steering);
  lv_timer_handler();
  delay(2);
}
